XRS2 STICK READER SETUP GUIDE
This setup guide shows how to connect a 5000 weigh scale indicator to an XRS2 Stick Reader and have recorded weights sent
directly to the stick reader.
The steps required to do this are:
1. Pair the stick reader with a 5000 indicator.
2. Set up the indicator to output weights to the stick reader.
3. Set up the stick reader with a new animal data field for the weight information.
4. Set up the stick reader to receive weight information into the new weight field.
Then you will be ready to use the stick reader with your 5000 indicator.
What you need:
An XRS2 Stick Reader with firmware above V1.4.4.
•
A Tru-Test XR5000 or ID5000 weigh scale indicator.
•
1

Pairing the stick reader with a 5000 indicator

Before you start, turn on the 5000 indicator and check that
1. Press
to switch on the stick reader.
2. Press
and select Settings.
Select Bluetooth.
Select Search for Devices:
Bluetooth
is enabled.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRS2 and is the answer not in the manual?

Questions and answers

Related Manuals for Tru-Test XRS2

Summary of Contents for Tru-Test XRS2

  • Page 1 XRS2 STICK READER SETUP GUIDE This setup guide shows how to connect a 5000 weigh scale indicator to an XRS2 Stick Reader and have recorded weights sent directly to the stick reader. The steps required to do this are: 1. Pair the stick reader with a 5000 indicator.
  • Page 2 XRS2 Stick Reader Setup Guide – Connecting to a 5000 weigh scale indicator Bluetooth symbol on the stick reader’s display will flash while it searches for devices, then the list of available devices will be displayed: 3. Select the 5000 indicator (XR5000 or ID5000).
  • Page 3 XRS2 Stick Reader Setup Guide – Connecting to a 5000 weigh scale indicator Setting up the indicator to output weights to the stick reader Before you start this step, make sure that you have paired the stick reader and the 5000 indicator, as detailed above.
  • Page 4 XRS2 Stick Reader Setup Guide – Connecting to a 5000 weigh scale indicator Setting up the stick reader with a new animal data field for the weight information 1. From the Home screen, select Settings. 2. Select Animal Data. 3. Press to set up a new field: 4.
  • Page 5 XRS2 Stick Reader Setup Guide – Connecting to a 5000 weigh scale indicator Setting up the stick reader to receive the weight information into the new weight field 1. From the Home screen, select Settings. Select Bluetooth. Select Paired devices.
  • Page 6 XRS2 Stick Reader Setup Guide – Connecting to a 5000 weigh scale indicator Using the stick reader with your indicator 1. From the Home screen, select Scan to go to the Scanning screen. 2. Scan an EID tag with the stick reader then press on the indicator.
