Modern Farmhouse Kitchen Island
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Stock # BH17-021-099-25
ADULT ASSEMBLY REQUIRED
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2017-02-24 Rev. 0001-B Factory: FOCIDI
866-942-5362
LOT NUMBER:
DATE PURCHASED: /
/

Advertisement

loading
Need help?

Need help?

Do you have a question about the BH17-021-099-25 and is the answer not in the manual?

Questions and answers

Related Manuals for Better Homes and Gardens BH17-021-099-25

Summary of Contents for Better Homes and Gardens BH17-021-099-25

  • Page 1 LOT NUMBER: DATE PURCHASED: / Modern Farmhouse Kitchen Island Stock # BH17-021-099-25 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
  • Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOGUE: Modern Farmhouse Kitchen Island (BH17-021-099-25) MADE IN CHINA MAXIMUM LOAD 200 lb.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Side Frame (Qty. 2 C- Stretcher (Qty. 2) D- Bottom Shelf (Qty. 1) E- Adjustable Shelf (Qty.
  • Page 4 Assembly Instructions 1-1/4” Bolt (3 used in this step) ④ Lock Washer (3 used in this step) ⑥ Flat Washer (3 used in this step) ⑦ NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts.
  • Page 5 Assembly Instructions Flat Washer Lock Washer 1-1/4” Bolt (3 used in this step) (3 used in this step) (3 used in this step) ⑥ ④ ⑦ 4. Repeat the same procedure to attach the other Side Frame (B) at the opposite end.
  • Page 6 Assembly Instructions M8 x 30 mm Wood Dowel (8 used in this step) ③ Flat Washer 1-3/4” Bolt Lock Washer (8 used in this step) (8 used in this step) (8 used in this step) ⑥ ⑤ ⑦ 5. Flip the assembled unit upside down. 6.
  • Page 7 Assembly Instructions Flat Washer 1-3/4” Bolt Lock Washer (4 used in this step) (4 used in this step) (4 used in this step) ⑥ ⑤ ⑦ 8. Attach the Side Handles (F) to the Side Frames (B) with four 1-3/4" Bolts (5) and four Washers (6 and...
  • Page 8 Assembly Instructions Cam Bolt (6 used in this step) ② 9. Lay out the Top Panel (A) with the holes facing up. Securely screw the Cam Bolts (2) into the designated small holes.
  • Page 9 Assembly Instructions Cam Lock M8 x 30 mm Wood Dowel (6 used in this step) (4 used in this step) ① ③ 10. Insert four Wood Dowels (3) into the non-threaded holes on the Top Panel (A). 11. Position the previous assembly onto the inserted Wood Dowels (3) and attach to the Top Panel (A) by engaging six Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement).
  • Page 10 Assembly Instructions Flat Washer 1-3/4” Bolt Lock Washer (6 used in this step) (6 used in this step) (6 used in this step) ⑦ ⑥ ⑤ 12. Secure the Side Frames (B) to the Top Panel (A) with six 1-3/4" Bolts (5) and six Washers (6 and 7).
  • Page 11 Assembly Instructions 13. Securely screw the Casters (G and H) to the bottom of the Side Frames (B) with the enclosed open wrench.
  • Page 12 Assembly Instructions Shelf Pin (4 used in this step) ⑧ 14. Ask for assistance to stand the assembled unit upright. 15. Insert four Shelf Pins (8) into the desired holes in the Side Frames (B). Make sure you place the four Shelf Pins in the same level so the shelf is not tilted.

  • Page 13: Quality Guarantee

    Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage your furniture’s finish. Never use water to clean your furniture as it may cause damage to the finish.
  • Page 14 NÚMERO de LOTE: FECHA de COMPRA: / Isla para Cocina Granja Moderna Seri # BH17-021-099-25 ENSAMBLE REQUERIDO POR ADULTO Si tienen alguna pregunta acerca del ensamble o si alguna parte está faltante, no retorne esté producto a la tienda donde lo compró. Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el número de fábrica:...
  • Page 15 M Á X I M A S C A R G A S R E C O M E N D A D A S FABRICANTE: Whalen Furniture Manufacturing CATALOGO: Isla para Cocina Granja Moderna (BH17-021-099-25) HECHO EN CHINA CARGA MÁXIMA 200 lb. (90.7 kg) CARGA MÁXIMA 50 lb.
  • Page 16 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes antes de iniciar el ensamblado. A- Panel superior (Cant. 1) B- Marco lateral (Cant. 2 C- Soporte (Cant. 2) D- Repisa inferior (Cant. 1) E- Repisa ajustable (Cant.
  • Page 17 Instructivo de ensamble Tornillo de 1-1/4” (3 usados en este paso) ④ Arandela de presión (3 usados en este paso) ⑥ Arandela plana (3 usados en este paso) ⑦ NOTA: Por favor no apriete completamente todos los tornillos, hasta que termine con el ensamble de las partes, después asegurese de apretar todos los tornillos, ésto hará...
  • Page 18 Instructivo de ensamble Arandela plana Arandela de presión Tornillo de 1-1/4” (3 usados en este paso) (3 usados en este paso) (3 usados en este paso) ⑥ ④ ⑦ 4. Repetir el mismo procedimiento para adjuntar el otro marco lateral (B) en el lado opuesto.
  • Page 19 Instructivo de ensamble Perno de madera de M8 x 30 mm usados en este paso ③ Arandela plana Tornillo de 1-3/4” Arandela de presión (8 usados en este paso) (8 usados en este paso) (8 usados en este paso) ⑥ ⑤...
  • Page 20 Instructivo de ensamble Arandela plana Tornillo de 1-3/4” Arandela de presión (4 usados en este paso) (4 usados en este paso) (4 usados en este paso) ⑥ ⑤ ⑦ 8. Adjuntar las manijas laterales (F) a los marcos laterales (B) con 4 tornillos de 1-3/4" (5) y 4 arandelas (6 y 7).
  • Page 21 Instructivo de ensamble Tornillo de fijación usados en este paso ② 9. Poner los paneles superiores (A) con los agujeros apuntando hacia arriba. Poner los tornillos de fijación (2) en los agujeros pequeños designados.
  • Page 22 Instructivo de ensamble Tuerca de fijación Perno de madera de M8 x 30 mm usados en este paso usados en este paso ① ③ 10. Insertar 4 pernos de madera (3) en los agujeros no roscados en el panel superior (A). 11.
  • Page 23 Instructivo de ensamble Arandela plana Tornillo de 1-3/4” Arandela de presión (6 usados en este paso) (6 usados en este paso) (6 usados en este paso) ⑦ ⑥ ⑤ 12. Asegurar los marcos laterales (B) al panel superior (A) con 6 tornillos de 1-3/4" (5) y 6 arandelas (6 y...
  • Page 24 Instructivo de ensamble 13. Atornillar las ruedas (G y H) a la parte inferior de los marcos laterales (B) con la llave española.
  • Page 25 Instructivo de ensamble Perno de repisa (4 usados en este paso) ⑧ 14. Pedir asistencia para posicionar la unidad ensamblada en posición vertical. 15. Insertar 4 pernos de repisa (8) en los agujeros deseados en los marcos laterales (B). Asegurar de poner los 4 pernos de repisa en el mismo nivel para que la repisa no esté...
  • Page 26 Mantenimiento y Cuidados Use una toalla suave y limpia para evitar daños y rayaduras. Uso de cera para pulir muebles no es necesario. Si desea usar cera cheque en una area que no sea visible para checar su funcionamiento. Usar solventes de cualquier tipo puede dañar el terminado del mueble. Nunca use agua para limpiar la unidad, ya que le puede dañar el terminado.
