4. Main menu
LNB Configuration
Single LNB
1. Connect signal input with RF4.
2. In the menu „Preferences -> Server Settings -> LNB Configuration" you set One
User per RF.
3. Click „Apply" and restart the server. Now you can use one SAT>IP client on the server.
Twin LNB
1. Connect signal input with RF3 and RF4.
2. In the menu „Preferences -> Server Settings -> LNB Configuration" you set One
User per RF.
3. Click „Apply" and restart the server. Now you can use two SAT>IP client on the server.
Multiswitch with DiSEqC
1. Connect signal input with RF1 to RF4.
2. In the menu „Preferences -> Server Settings -> LNB Configuration" you set One
User per RF.
3. Click „Apply" and restart the server. Now you can use four SAT>IP client on the server.
Quad LNB or Multiswitch without DiSEqC
1. Connect signal input with RF1 to RF4.
2. In the menu „Preferences -> Server Settings -> LNB Configuration" you set Quad.
3. Click „Apply" and restart the server. Now you can use four SAT>IP client on the server.
Quattro LNB
1. Connect signal input with RF1 to RF4.
- RF1 (Horizontal - Low)
- RF2 (Horizontal - High)
- RF3 (Vertical - High)
- RF4 (Vertical - Low)
2. In the menu „Preferences -> Server Settings -> LNB Configuration" you set Quattro.
3. Click „Apply" and restart the server. Now you can use eight SAT>IP client on the server.
