I
RIDE-ON TERMINATORS
T-2200PRO
COMPLETE MANUAL
For machines with serial no. format: T2200P-mmyy-XXX
OIPB-I03026-T2200PRO_v3.1

Advertisement

Table of Contents
loading

Related Manuals for Bartell Global Innovatech Terminator T-2200PRO

Summary of Contents for Bartell Global Innovatech Terminator T-2200PRO

  • Page 1 RIDE-ON TERMINATORS T-2200PRO COMPLETE MANUAL For machines with serial no. format: T2200P-mmyy-XXX OIPB-I03026-T2200PRO_v3.1...
  • Page 2 Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. Locations: Florida (West Palm Beach): 561-964-4949 Outside Florida TOLL FREE: 877-690-3101 Need parts? Check out our website at www.discount-equipment.com Can’t find what you need? Click on this link: http://www.discount-equipment.com/category/5443-parts/ and fill out the request form.
  • Page 3 P a g e REV. DATE DESCRIPTION APPROVED BY: 04/17/14 05/18/15 06/16/15 07/01/15 11/14/17 Reformatted and revised text 03/26/18 Updated and added exploded views OIPB-I03026-T2200PRO_v3.1...
  • Page 4 P a g e SAFETY PRECAUTIONS DANGER EXPLOSION HAZARD Never operate the machine in an explosive atmosphere, near combustible materials, or where ventilation does not clear exhaust fumes. WARNING BURN HAZARD Never come into contact with the engine or muffler when engine is operating or shortly after it is turned off.

  • Page 5: Table Of Contents

    P a g e TABLE OF CONTENTS INTRODUCTION ABOUT THIS MANUAL IMPORTANT SAFETY INSTRUCTIONS o 1. S AFETY NSTRUCTIONS FOR OOLS o 2. A DDITIONAL AFETY ULES FOR IDING LOOR CRAPERS ® GENERAL OPERATING INSTRUCTIONS FOR THE TERMINATOR SAFETY FEATURES o 1.
  • Page 6 P a g e BALLAST TRICYCLE OR CASTER WHEELBASE AND TIRES CARBON MONOXIDE INFORMATION o 1. W HAT IS ARBON ONOXIDE o 2. A IKELY TO OISONED o 3. W RE THE YMPTOMS o 4. W BOUT o 5. E MPLOYERS o 6.

  • Page 7: Introduction

    P a g e 1. Introduction ® The Terminator Carpet and Tile Removal Machine is intended for use on large demolition and asbestos abatement projects as well as smaller floor covering removal jobs. Designed and built by experienced floor covering demolition and installation experts, the machine incorporates several design features that are essential for efficient operation: •...

  • Page 8: Important Safety Instructions

    P a g e 3. Important Safety Instructions WARNING: When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the READ ALL INSTRUCTIONS following: 1. Safety Instructions for All Tools •...

  • Page 9: O 2. Additional Safety Rules For Riding Floor Scrapers

    P a g e 2. Additional Safety Rules for Riding Floor Scrapers CAUTION: FAILURE TO HEED THESE WARNINGS MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH AND SERIOUS DAMAGE TO THE ® TERMINATOR ® The Terminator is to be operated only by qualified, trained personnel. DON’T attempt to operate the Terminator ®...

  • Page 10: General Operating Instructions For The Terminator

    P a g e ® 4. General Operating Instructions for the Terminator ® The Terminator is designed to remove carpet, tile and glue residue from floors. • When removing product, position removed product so it rolls to the side of the machine or have someone on the side of the machine remove the product.

  • Page 11: O 5. Safety Instructions

    P a g e | 10 5. Safety Instructions ® The Terminator is designed for safe operation by trained, designated personnel. To help ensure your safety as a designated operator, read these safety instructions before you operate the equipment. Regardless of your experience with machinery, the ®...

  • Page 12: Ventilation Requirements

    P a g e | 11 7. Ventilation Requirements ® The Terminator engine, like all combustion engines, relies on the combustion of fuel and oxygen to produce power. While most of the exhaust produced is in the form of water vapor and carbon dioxide, the engine also produces harmful carbon monoxide (CO).

  • Page 13: Uncrating And Preparing The Terminator

    P a g e | 12 ® 11. Uncrating and Preparing the Terminator for Operation ® When you receive the Terminator , inspect the outside of the crate completely, to detect damage to the crate itself. If it is damaged, notify the carrier immediately and follow his/her instructions to file a claim.

  • Page 14: Operator Controls

    P a g e | 13 • Properly secure the machine with chains, tire chocks, and other necessary tie downs. • Never ride in a moving vehicle next to a Terminator ® . It may tip, causing severe injury. 13. Operator Controls 1.

  • Page 15: O 2. Malfunction Indicator Light

    P a g e | 14 2. Malfunction Indicator Light The Malfunction Indicator Light (MIL) will illuminate when the engine is running out of specification. The illumination of the MIL will typically be accompanied by an error code, which can be accessed and displayed on the information display. 3.

  • Page 16: Ballast

    P a g e | 15 18. Ballast ® The T2200 PRO Terminator can be equipped with weight plates in the front (30 lbs. each) and in the rear (75 lbs. each) to provide traction for tough jobs. These weights can be easily removed to reduce traction or assist in transportation.

  • Page 17: O 3. What Are The Symptoms

    P a g e | 16 Harmful levels of CO are a potential danger to workers of: acetylene workers, blast furnace workers, boiler room workers, brewery workers, carbon black makers, coke oven workers, diesel engine operators, dock workers, garage mechanics, metal oxide reducers, miners, organic chemical synthesizers, petroleum refinery workers, pulp and paper workers, steel workers, toll booth and tunnel attendants, and warehouse workers.

  • Page 18: O 7. Federal Standards

    P a g e | 17 7. Federal Standards The Occupational Safety and Health Administration (OHSA) standard for exposure to CO prohibits workers’ exposure to more than 50 parts of gas per million parts of air (PPM), averaged over an 8-hour work day. There is also a ceiling limit of 200 PPM measured over a 15-minute period.
  • Page 19 P a g e | 18 3. Clean Caster Wheel and Back Tires with wire wheel when necessary. 4. Look for leaks, find and tighten fittings. Do not over-tighten fittings. 5. Check all hoses and clamps once a week. 6. Inspect rear tires and lug bolts. Tighten lug bolts as needed to 70 ft.-lbs. torque. 7.

  • Page 20: Parts List

    P a g e | 19 23. Parts List T2200 PRO Terminator OIPB-I03026-T2200PRO_v3.1...
  • Page 21 P a g e | 20 Jaw & Footrest Breakdown Item No. Part Number Description Qty. 11-0041 Lock Washer, 1/2" Adjustable Clevis Pin, 5/8” x 3” L 11-0045 11-0052 Hitch Pin Clevis Pin, 1/2” x 3” L 11-0236 12-0046 Flange Head Cap Screw, M12-1.75 x 90mm 51-1070 Uni-Frame Pivoting Jaw Weight 53-0117...
  • Page 22 P a g e | 21 Doors & Panels Breakdown Item No. Part Number Description Qty. 11-0023 Nyloc Nut, #10-24 11-0030 SAE Flat Washer, #10 11-0033 USS Flat Washer, 1/4" Lock Washer, 5/16” 11-0040 Hex Head Cap Screw, 1/4"-20 x 1” 11-0059 11-0069 Lock Washer, 1/4"...
  • Page 23 P a g e | 22 Front Wheels & Brake Breakdown Item No. Part Number Description Qty. Nyloc Nut, 5/16”-18 11-0025 USS Flat Washer, 3/8” 11-0035 Hex Head Cap Screw, 5/16”-18 x 1” 11-0132 12-0021-10 Nyloc Nut, M10-1.5 12-0034-40 Hex Head Cap Screw, M10-1.5 x 40mm 13-0027 Brake Cable Clevis 13-0041...
  • Page 24 P a g e | 23 Rear Wheels Breakdown Item No. Part Number Description Qty. Nyloc Nut, 5/16”-18 11-0025 USS Flat Washer, 3/8” 11-0035 Lock Washer, 3/8” 11-0129 Hex Head Cap Screw, 3/8”-16 x 3/4" 11-0130 11-0279-88 Hex Head Cap Screw, 1/4"-20 x 5 1/2" Socket Head Shoulder Screw, 3/8”...
  • Page 25 P a g e | 24 Top Cover & Support Breakdown Item No. Part Number Description Qty. Hex Head Cap Screw, 3/8”-16 x 1” 11-0007 Nyloc Nut, 5/16”-18 11-0025 Nyloc Nut, 3/8”-16 11-0026 USS Flat Washer, 5/16” 11-0034 USS Flat Washer, 3/8” 11-0035 Lock Washer, 5/16”...
  • Page 26 P a g e | 25 OIPB-I03026-T2200PRO_v3.1...
  • Page 27 P a g e | 26 Cylinder & Valve Breakdown Item No. Part Number Description Qty. 11-0024 Nyloc Nut, 1/4"-20 11-0033 USS Flat Washer, 1/4" 11-0052 Hitch Pin 11-0279-48 Hex Head Cap Screw, 1/4"-20 x 3" Hydraulic Fitting, 90 deg 4 JIC – 8 SAE 31-0043 31-0088 Hose Assembly, PRO, Valve to Cylinder 1...
  • Page 28 P a g e | 27 Filter & Fittings Breakdown Item No. Part Number Description Qty. 11-0069 Lock Washer, 1/4" Hex Head Cap Screw, 1/4"-20 x 1” 11-0121 11-0133 Hex Head Cap Screw, 1/4"-20 x 3/4" Hydraulic Fitting, 90 deg 10 JIC – 12 SAE 31-0052 31-0084 Hose Assembly, PRO, Return to Rank 2...
  • Page 29 P a g e | 28 Seat & Joysticks Breakdown Item No. Part Number Description Qty. 11-0134 Button Head Socket Screw, #10-24 x 1/2" Button Head Socket Screw, 1/4"-20 x 1/2” 11-0176 12-0023-12 Low Head Socket Screw, M8-1.25 x 12mm 13-0194 PRO Joystick Boot 13-0257...
  • Page 30 P a g e | 29 OIPB-I03026-T2200PRO_v3.1...
  • Page 31 P a g e | 30 Lockoff Valves Breakdown Item No. Part Number Description Qty. 11-0033 USS Flat Washer, 1/4" 11-0069 Lock Washer, 1/4" Hex Head Cap Screw, 1/4"-20 x 1” 11-0121 Hydraulic Fitting, 90 deg 8 JIC – 10 SAE 31-0053 31-0092 Hose Assembly, PRO, Wheel (Universal)
  • Page 32 P a g e | 31 Engine & Electrical Breakdown Item No. Part Number Description Qty. Lock Washer, 5/16” 1001 11-0040 Hex Head Cap Screw, 1/4"-20 x 1” 1002 11-0059 Hex Head Cap Screw, 5/16”-18 x 3/4" 1003 11-0118 1004 12-0032-16 Hex Head Cap Screw, M8-1.25 x 16mm 1005...
  • Page 33 P a g e | 32 Engine & Muffler Breakdown Item No. Part Number Description Qty. 1101 12-0018-08 Lock Washer, M8 1102 12-0018-10 Lock Washer, M10 1103 12-0018-12 Lock Washer, M12 1104 12-0027-10 Hex Nut, M10-1.5 1105 12-0027-12 Hex Nut, M12-1.75 1106 12-0031-16 Flange Head Cap Screw, M6-1.0 x 16mm, Black...
  • Page 34 P a g e | 33 OIPB-I03026-T2200PRO_v3.1...
  • Page 35 P a g e | 34 Engine & Pump Breakdown Item No. Part Number Description Qty. Lock Washer, 5/16” 1201 11-0040 Hex Nut, 5/16”-18 1202 11-0067 SAE Flat Washer, 3/8” 1203 11-0126 Lock Washer, 3/8” 1204 11-0129 SAE Flat Washer, 5/16” 1205 11-0139 Hex Head Cap Screw, 3/8”-16 x 3”...
  • Page 36 P a g e | 35 OIPB-I03026-T2200PRO_v3.1...
  • Page 37 P a g e | 36 Engine & Air Cleaner Breakdown Item No. Part Number Description Qty. USS Flat Washer, 5/8” 1301 11-0148 Nyloc Nut, 5/8”-18 1302 11-0331 Hex Head Cap Screw, 5/8”-18 x 4” 1303 11-0332-64 1304 12-0021-08 Nyloc Nut, M8-1.25 1305 12-0032-30 Hex Head Cap Screw, M8-1.25 x 30mm...
  • Page 38 P a g e | 37 96-0396 – PRO Right Wheel Assembly Item No. Part Number Description Qty. Hex Head Cap Screw, 1/2"-13 x 3” 1401 11-0013 1402 11-0028 Nyloc Nut, 1/2"-13 1403 11-0029 Nyloc Nut, 1/2"-20 1404 11-0187 Double Ended Stud, 1/2"-13 x 2 1/2" Hex Head Cap Screw, 1/2"-13 x 5”...
  • Page 39 P a g e | 38 96-0395 – PRO Left Wheel Assembly Item No. Part Number Description Qty. Hex Head Cap Screw, 1/2"-13 x 3” 1501 11-0013 1502 11-0028 Nyloc Nut, 1/2"-13 1503 11-0029 Nyloc Nut, 1/2"-20 1504 11-0187 Double Ended Stud, 1/2"-13 x 2 1/2" Hex Head Cap Screw, 1/2"-13 x 5”...
  • Page 40 P a g e | 39 96-0394 – PRO Top Cover Assembly Item No. Part Number Description Qty. 1601 11-0023 Nyloc Nut, #10-24 1602 11-0024 Nyloc Nut, 1/4"-20 Nyloc Nut, 5/16”-18 1603 11-0025 1604 11-0030 SAE Flat Washer, #10 1605 11-0033 USS Flat Washer, 1/4"...
  • Page 41 P a g e | 40 96-0386 – Pivoting Jaw Assembly Item No. Part Number Description Qty. 1701 11-0041 Lock Washer, 1/2" 1702 11-0230 USS Flat Washer, 1/2" 1703 11-0296 Hex Head Cap Screw, 1/2"-13 x 1 1/2" Pin, 1/2" x 3” L 1704 13-0035 1705...
  • Page 42 P a g e | 41 96-0329 – Strobe Light Assembly Kit Item No. Part Number Description Qty. 1801 11-0022 Nyloc Nut, #8-32 1802 11-0023 Nyloc Nut, #10-24 1803 11-0030 SAE Flat Washer, #10 1804 11-0031 SAE Flat Washer, #8 Pan Head Philips Screw, #8-32 x 5/8”...
  • Page 43 P a g e | 42 96-0291 – PRO Right Door Assembly Item No. Part Number Description Qty. 1901 11-0023 Nyloc Nut, #10-24 1902 11-0250-12 Pan Head Philips Screw, #10-24 x 3/4" 1903 13-0231 Concealed Hinge, Type B 1904 13-0337 Door Latch 1905 53-0311...
  • Page 44 P a g e | 43 96-0290 – PRO Left Door Assembly Item No. Part Number Description Qty. 2001 11-0023 Nyloc Nut, #10-24 2002 11-0250-12 Pan Head Philips Screw, #10-24 x 3/4" 2003 13-0230 Concealed Hinge, Type A 2004 13-0337 Door Latch 2005 53-0310...
  • Page 45 P a g e | 44 96-0274 – Engine Assembly Item No. Part Number Description Qty. 2101 11-0133 Hex Head Cap Screw, 1/4"-20 x 3/4" 2102 12-0043-16 Serrated Flange Cap Screw, M6-1.0 x 16mm 2103 13-0274 Hose Clamp, SAE 36 2104 13-0275 Hose Clamp, SAE 12...
  • Page 46 P a g e | 45 96-0177 – Pump & Gearbox Assembly Item No. Part Number Description Qty. Nyloc Nut, 5/16”-18 2201 11-0025 Lock Washer, 5/16” 2202 11-0040 Hex Nut, 5/16”-18 2203 11-0067 Socket Head Cap Screw, #10-24 x 1” 2204 11-0297 Hex Head Cap Screw, 5/16”-18 x 1 3/4"...
  • Page 47 P a g e | 46 96-0140 – PRO Joystick Base Item No. Part Number Description Qty. 2301 11-0024 Nyloc Nut, 1/4"-20 USS Flat Washer, 7/16” 2302 11-0036 2303 11-0055 Hex Head Cap Screw, 1/4"-20 x 1 1/2" 2304 11-0069 Lock Washer, 1/4"...
  • Page 48 P a g e | 47 Rear & Wheel Weights Breakdown Item No. Part Number Description Qty. 2401 11-0019 Hex Nut, 1/2"-13 2402 11-0041 Lock Washer, 1/2" Lock Washer, 3/8” 2403 11-0129 Hex Head Cap Screw, 1/2"-13 x 5” 2404 11-0228 2405 11-0230...

  • Page 49: Warranty

    P a g e | 48 24. Warranty Innovatech warrants to the original buyer, for a period of one (1) year or 300 operating hours (whichever comes first) from the date of delivery, that the Equipment is free from defects in materials and workmanship and that the Equipment conforms to the operating specifications supplied with the Equipment.
