Saramonic CaMixer Manual

Mini Preamp Audio Mixer Kit
The Saramonic CaMixer is a compact audio interface with phantom
power and preamplifier, ideal for DSLR camera video production.
CaMixer
Introduction Manual
Introductions
The Saramonic CaMixer is a compact audio interface with phantom power
and preamplifier, ideal for DSLR camera video production.
The mixer features one mini XLR input for balanced microphones and two
microphone/line inputs for the included condenser microphones or other
user-supplied microphones. A volume control knob and level meter allow
easy adjustment of the input level. A headphone monitor output allows you
to monitor the input and playback signal.
The audio quality and versatile operation of the CaMixer make it ideal for
both professional and in-home applications.
Highlights
• Two 1/8"(3.5 mm) stereo line/mic inputs
• One mini XLR microphone input
( a mini-XLR to standard-XLR cable included)
• +48V phantom power
• One 1/8"(3.5 mm) stereo line output to camera
• One 1/8"(3.5 mm) headphone monitor output
• PLAY/REC monitor switch
• Independent L/R level meters
• Volume control knob
• Includes two plug-in power condenser microphones
• Power provided by 9V battery
Specifications
Frequency Response
Noise
Distortion
20 Hz to 20 Khz (+/-0.5 dB)
82 dB @ 1 kHz, -30 dBu input
less than 0.03% @ 1 kHz, -30 dBu input
INPUT 1 GAIN 15 dB
INPUT 2 GAIN & MINI XLR Jack 15 dB
INPUT 1 & INPUT 2 Power 5V power supplies
MINI Jack Phantom Power 48V power supplies
Level Meter -18 dB to +3 dB in 3 dB increments
Power Requirements 9V alkaline or lithium battery
Dimensions L 95 x W 35 x H 65 mm
Weight 156 g (5.5 oz.)
Components
48V Phantom Power/
Power On / Power Off
PLAY / REC
Monitor Switch
Level Meter
Headphone Jack
Audio Output
Condenser
Microphones
Cold Shoe
Volume Control Knob
Mini XLR
Microphone Input
Microphone Input
