Brodit 513770 Quick Start Manual

5 September, 2016, www.brodit.com, © 2016 Brodit AB
Product 513770
513770 Active holder for fixed installation With tilt swivel, with Molex adapter system. 2A charger. For device
without bumper.
An active holder which is to be connected inside the dashboard, this gives a discreet, neat installation without
cables hanging over the interior!
You can choose to use the holder as an active holder for charging of your device only, or to connect an adapter
to the Molex connector for additional features. Then you can use the holder also for power supply of a GPS
receiver or other own solutions (can not be used for data communication or audio connection).
12/24 Volt. The product is E-approved. Connect the power cable with a 2 A fuse. 2 A charger. Professional
installation recommended. The holder is attached onto a tilt swivel so you can easily adjust your device in order
to avoid light reflection. Attach onto a ProClip Mounting Platform.
Charging specifications:
Input voltage: DC/10-30V
Charging voltage: DC/4.75-5.3V
Output current(Typ): 2.0A
Input & output protection: Input polarity reversal/Output over voltage/Output over current/Output short protection
LED charging indicator: Power input indicator(Green), Ovp/Ocp/Output short(Red)
Operating temperature: 0°C ~ +40°C
Storage temperature: -20°C ~ +80°C
RoHS compliant: ROHS
EAN: 7320285137707
Item no 513770 fits:
CipherLab RS30 Series (For all countries)
1 (2)
