INSTALLATION INSTRUCTIONS
FACEPLATES
AC01020, AC01021, AC01022
AC01020
AC01021
AC01022
WARNING :
The faceplate should never come into contact with masonry products such as cement, acid or
any other product containing abrasives. Damages and discolouration caused by these products
will void the warranty.
45939A
Printed in Canada
14-11-2018
Advertisement
Related Manuals for Osburn AC01021
Summary of Contents for Osburn AC01021
- Page 1 INSTALLATION INSTRUCTIONS FACEPLATES AC01020, AC01021, AC01022 AC01020 AC01021 AC01022 WARNING : The faceplate should never come into contact with masonry products such as cement, acid or any other product containing abrasives. Damages and discolouration caused by these products will void the warranty.
- Page 2 Dimensions : AC01020 AC01021 AC01022...
- Page 3 Installation Instruction – AC01020 1. Align the clips on the faceplate with the notches on the insert. Push the front panel onto the insert until it snaps onto it. 2. Make sure the fan cord is out on the side, in the opening between the front and the insert.
- Page 4 Installation Instruction – AC01021 1. This faceplate can be cut according to the size of the hearth hole. To do this, two solutions are available to you. a) Place the faceplate temporarily where it will be installed. Draw the outline of your chimney to guide you in cutting your facade.
- Page 5 2. Align the clips on the faceplate with the notches on the insert. Push the front panel onto the insert until it snaps onto it.
- Page 6 3. Make sure the fan cord is out on the side, in the opening between the front and the insert.
- Page 7 Installation Instruction – AC01022 1. Wedge the decorative bracket between the bottom of the insert and the insert jacket. 2. Align the clips on the faceplate with the notches on the insert. Push the front panel onto the insert until it snaps onto it.
- Page 8 3. Make sure the fan cord is out on the side, in the opening between the front and the insert.
