11.
Storage
11.1. Folding down the backrest
The LEVO KID & JUNIOR has a foldable backrest which allows you to cut down significantly on
the space required to store the wheelchair away. Certain parts are also detachable to warranty the
lowest possible weight.
33
11.2. Removing battery and electronic unit
34
11.3. Removing the rear wheels
With the quick-release you can speedily remove and remount the rear wheels of the LEVO KID &
JUNIOR, thus significantly reducing the volume and weight of the wheelchair.
When removing a wheel, the wheelchair must be unoccupied. The wheelchair has to be supported
that after taking away a wheel it should not fall over or roll away.
35
• Before you fold down the backrest first remove the two skirt
guards (see section 6.6)
• Push up the two folding clasps and at the same time push the
backrest forwards (see photo 33).
The battery and electronic unit is removable.
• Pull out the actuator plug and the plug from the armrest.
• Lift the battery unit at the bottom and take it up and out (see
photo 34).
• To refit it again, attach the two brackets to the cross linkage and
let the two pins lock in the corresponding openings.
• Press the release button in the center of the wheel and pull off or
mount the wheel (see photo 35).
• After mounting the wheel pull and push several times on the
wheel to check that the quick-release axle has definitely locked
in.
29
