LEVO active-easy LAE
INSTRUCTION- and
SERVICE MANUAL
Please read the Instruction Manual carefully
before attempting to use your wheelchair.
The Service Manual is provided for the use of
Agents and Authorized Technicians.
Alterations in constructional and technical manner
or to the electronic require the written authorisation
of LEVO AG, otherwise no warranty or product
liability will be accepted.
In case of difficulty contact:
Manufacturer:
LEVO AG
Anglikerstrasse 20
CH-5610 Wohlen
Tel:+41 (0)56 618 44 11
Fax:+41 (0)56 618 44 10
Internet: http://www.levo.ch
Agent:
Advertisement
Table of Contents
Related Manuals for Levo AG active-easy LAE
Summary of Contents for Levo AG active-easy LAE
-
Page 1: Service Manual
The Service Manual is provided for the use of Agents and Authorized Technicians. Alterations in constructional and technical manner or to the electronic require the written authorisation of LEVO AG, otherwise no warranty or product liability will be accepted. In case of difficulty contact: Manufacturer:... - Page 2 As a LEVO customer, you have a valuable contribution to make to the on-going further development of our products. We put great store by your suggestions, which ensure that LEVO still offers the most comprehensive service available and provides for the widest possible range of needs. Yours faithfully, LEVO AG...
-
Page 3: Table Of Contents
Contents Seating and Standing Assessment......................5 Declaration of Conformity ........................7 INSTRUCTIONMANUAL .......................8 Important points to note before operating the LEVO active-easy LAE........9 Warranty .............................9 Sitting / Driving........................10 3.1. The rear wheels ........................10 3.2. Seat inclination........................10 3.3. Position of the rear wheels.....................10 3.4. - Page 4 SERVICEMANUAL ........................23 Introduction ..........................24 Accident prevention & safety....................24 Adjustments – general instructions ..................24 Repairs – general instructions ....................24 Tools & torques ........................25 Important notes .........................25 Recommended safety checks....................25 Adjustments ..........................26 8.1. The backrest and seat upholstery ...................26 8.2. Rear wheel position........................26 8.3.
-
Page 5: Seating And Standing Assessment
Seating and Standing Assessment Seat depth: correct Seat depth: too long Seat depth: too short Knee support attachment Knee support attachment Knee support attachment screw even with center of knee screw beyond center of knee screw short of center of knee Ankle/Knee/Hip joint straight Knee joint hyper extended Incomplete knee extension... - Page 6 Correct position Seat cushion too high Back too deep/thick Backrest cushion Seat cushion Cushion for pressure relief Backrest cushion or solid in seated position back for more comfort or stability Backrest Spine cushion physiological Hyper Lordosis Hyper extended spine Seat cushion Pelvis tilt incomplete hip...
-
Page 7: Declaration Of Conformity
Moreover we declare valid the correspondence of this products with following norms / nominal documents: ISO 7176-1 ISO 7176-3 ISO 7176-8 ISO 7176-15 ISO 7176-16 EN 12183 UNI 14971 Type of stand-up wheelchairs: LEVO active-easy LAE S/M/L/XL Wohlen, July 1, 2004 Dr. Kurt H. Fischer Thomas Räber... -
Page 8: Instructionmanual
LEVO active-easy LAE INSTRUCTIONMANUAL Please read this Instruction Manual carefully before you start to use your wheelchair... -
Page 9: Important Points To Note Before Operating The Levo Active-Easy Lae
Your LEVO product is guaranteed from the date of purchase for two years covering all material and manufacturing defects of mechanical parts. LEVO AG will not repair or replace free of charge any part or parts found to be defective due to abuse, misuse or lack of maintenance. -
Page 10: Sitting / Driving
Sitting / Driving In the LEVO active-easy you will enjoy all the handling qualities and comfort of an active wheelchair. This section will tell you how to adapt the LEVO active-easy to suit your particular needs. Before attempting adjustments yourself, please consult your LEVO dealer. 3.1. -
Page 11: Position Of The Front Castors
3.4. Position of the front castors The correct positioning of the front castors depends on the height of the rear wheels and is crucial in ensuring a safe standing position. Please consult your LEVO dealer! 3.5. Backrest angle The standard pre-set angle between backrest and seat is 90°. It is possible to re-set this angle either 5°... -
Page 12: The Seat Cushion
3.8. The seat cushion There is a choice of various different seat cushions, governed by your individual needs. The velcro fasteners fitted to the surface of your seat should allow you to attach the majority of seat cushions securely. The velcro fasteners prevent the cushion from slipping out of place even when you are standing up. -
Page 13: Gradients
4.2. Gradients When turning on a gradient, bear in mind you will have to sit square on to the slope before finally swiveling around to face straight downhill. In this side-on position there is a risk of slipping sideways down the slope. Either you or your accompanying person should take this risk into account and steer accordingly to compensate. -
Page 14: Braking With The Pressure Brakes
To descend down over an obstacle (e.g. driving down from the kerb into the street), first tilt the wheelchair up onto the rear wheels, then push on and let the wheelchair down over the edge of the obstacle on two wheels (see diagram, above right). Should you have to be carried over three steps or more, request the assistance of at least two able- bodied persons. -
Page 15: Picking Up Objects From The Wheelchair
After driving through a puddle, keep in mind that wet tires reduce braking efficiency as water on the surface of the tires acts as a lubricant. 4.5. Picking up objects from the wheelchair Always remember that picking up objects from the wheelchair will alter your center of gravity and effect stability. -
Page 16: Transport In A Motor Vehicle
4.7. Transport in a motor vehicle When transporting the wheelchair in a motor vehicle make sure that the wheelchair is so secured as to prevent it sliding about or tipping over. Use should be made of licensed fastening systems which secure the wheelchair’s rear axle and at the front the lower frame tubes from below. -
Page 17: Standing
Standing Your LEVO active-easy isn’t just an active wheelchair. It is also a standing aid which enables you to stand up simply and quickly, right there, when and where you need to. General tips Standing up stresses your body in ways you may not be used to. For this reason, please consult your doctor or physical therapist before using the LEVO active-easy to make sure you do not suffer from any conditions (e.g. -
Page 18: The Chest Strap
7.2. The chest strap The chest strap holds the upper body in place. Check that the chest strap is secure on the backrest (velcro fastening). Close the catch on the chest strap and pull it to (not too tight, see photo). To release the chest strap, simply press the red button in the center of the catch. -
Page 19: Sitting Down
8.2. Having raised yourself up as far as your arms will allow, let go of the gas spring-release levers to lock the gas springs once more in place (see photo above right). By using the two armrest-release levers found further toward the front of the armrests, you can bring the armrests up to the appropriate height. -
Page 20: The Gas Springs
The gas springs The gas springs are specially adjusted to hold your weight in the balance. With minimal arm work, i.e. pushing lightly on the armrests, you can stand yourself up. Similarly, by pulling lightly you can sit yourself back down in your seat, equally effortlessly. There is a range of spring strengths to suit the body weight of different wheelchair users. -
Page 21: The Castors
12.2. Having mounted the wheel, push and pull it several times to ensure the quick-release axle has definitely locked in. The castors To remove the front castor together with the front forks, depress the quick-release axle from underneath, then pull off the forks (see photo). Maintenance To keep your LEVO active-easy in good condition, it is advisable to adhere to the following guidelines and to carry out maintenance work on a regular basis, as detailed below. -
Page 22: Disposal
If the gas springs are sluggish on release, have them adjusted by a qualified technician. He will have to loosen the counter nut and turn the adjustment screw one turn to the left (anti-clockwise), (see photo, over). If the gas springs are not locking properly, have them adjusted by a qualified technician. He will have to loosen the counter nut and turn the adjustment screw one turn to the right (clockwise), (see photo). -
Page 23: Servicemanual
This service manual must be read in connection with the instruction manual. Alterations in constructional and technical manner or to the electronic require the written authorisation of LEVO AG, otherwise no warranty or product liability will be accepted. -
Page 24: Introduction
Replacement parts: Factory replacement components should be used in all repairs, these are available from LEVO AG. To order parts see the parts list drawings at the end of this manual. Caution: check that the LEVO active-easy is not in the sitting position before carrying out any maintenance or repair work on the wheelchair’s stand-up mechanism! Risk of accident! -
Page 25: Tools & Torques
• Always use recommended components and parts available from LEVO AG. • Do not modify or repair the frame. • LEVO AG is responsible for any repairs on gas springs, motors and electronic parts. Recommended safety checks Please note that the following safety checks should be carried out at least on an annual basis. -
Page 26: Adjustments
Adjustments 8.1. The backrest and seat upholstery The surface flexibility of the backrest upholstery can be adjusted using the velcro fasteners. The backrest can be tightened (for a more upright seated posture) or relaxed (for more back support). The seat upholstery can be similarly tightened or relaxed by use of velcro fasteners. As a rule it should be as taut as possible. -
Page 27: The Castor Axle
8.3. The castor axle Having made adjustments to the rear axle, be sure to adjust the castor height and angle accordingly. When carrying out these adjustments, it is important to bear the following points in mind: • The castor axle should stand at a right angle to the ground. •... -
Page 28: Backrest Angle
8.5. Backrest angle The backrest sits at an angle of 90° to the seat as standard but can be adjusted in either direction by 5°. This adjusting mechanism is not stepless. • Remove the rear wheels, then remove the skirt guards (see Instruction Manual, section 3.1.). -
Page 29: Adjusting The Gas Spring Release
The footrest angle is set as standard at 14° to the horizontal. With the footrest in the lowest possible setting, an angle of 4° is the only practicable variation as the footrest otherwise touches the ground before the leg supports (hence no standing stability!). With the second lowest setting the only potential variations are 4°... -
Page 30: Repairing The Inner Tube
9.2. Repairing the inner tube • Remove inner tube and tire following the steps described under 9.1. • Repair the hole using a bicycle puncture repair kit and follow the manufacturer’s instructions (clean the area around the hole and roughen the tube surface (see photo 12) before applying the vulcanized solution. -
Page 31: Replacing The Gas Springs
9.4. Replacing the gas springs Should you have to replace the gas springs, for example, to boost or reduce their resistance, ensure first that they are not extended (too long, i.e. the wheelchair should be in half seated or almost upright position, but not in the fully upright standing position). - Page 32 • Loosen and remove the screw (E) on the gas spring release lever (F) using a 3 mm Allen key (see photo 19).Take the gas spring release lever off the armrest and pull the cable out. • Loosen the threaded pin (G) on the trigger lever (H) in the front gas spring holder (B) using a 3 mm Allen key and pull the cable out.
-
Page 33: Testing The Wheelchair
Testing the wheelchair After having carried repairs on a wheelchair, you should always check all functions for correct operation before returning the wheelchair to your customer. The wheelchair should only be returned after all defects have been rectified. Cleaning Before you return the wheelchair to your customer, make sure that the wheelchair is clean and dry: •... -
Page 34: Technical Data
Technical Data Measurements Model Seat width Total width Total length Total height (with backrest) Back upholst. height Seat upholst. height front 51 / 54 54 / 57 Seat upholst. height rear 47 / 50 49 / 52 Seat upholst. depth Footrest - seat 35 - 42 38 - 45 / 41 - 48...
