RETEKESS T118 Wireless Calling System Manual
Functional Diagram
Power
Mute
Parameter
Host
Power input
DC5V/3A
Transmitting frequency
433.92MHz
Transmit power
13dBm
Standby power
150mW
Button mode
Mechanical button
Max number of pagers
998
Shell material
ABS
Dimensions
110*165*50mm
Number of charging
10
pagers
Instructions for use
A. Preparation for use
Connect the power supply of the transmitter, put the pagers on charging base and connect the power
source. After charging for 10 minutes, then start to program.
History
Up
Down
Program
Delete
Call
Pager
Operating Voltage
3.7V
Receiving frequency
433.92MHz
Stand-by current
30mA
Standby duration
10h
Receiving sensitivity
-115dBm
Transmission distance
500m-800m
Vibration / buzzer
Prompt mode
/ flashing light
Reminder time
30s
Charger Power
DC 5V/3A
1
B. Program
When all the pagers under power charging, press P, the screen will display "P---", then press "999" and
press CALL, all pagers will be flashing to show program state.
Note: we must input P999 within 20 seconds in the charging state.
Input a number, and press CALL. For example: input 98, the host displays P098. Then press CALL, all
numbers on charging pagers will change to 98 and flash. Move the top pager away from the base, the
pager will long beep, and number 98 stops flashing. Program is done.
Repeat above operation to program other pagers.
If no operation within 1 minute, the device will quit program state. 1 pager can program 1 number only,
new number will replace the old one.
C. Use
Input number and press CALL, the corresponding pager will alarm to remind. If input wrong numbers,
press ← to delete.
Pressing DELETE button several times will return to calling mode.
D. Charging reminder:
The red light flashes in the charging state. When the RED light turns to always-on, it shows the pager is
fully charged
Silent mode
Buttons pressed
Display on LCD
MUTE+999+CALL
S999
MUTE+000+CALL
S000
In SILENT mode, pagers vibrate and flash only when receives a call, no beep.
Pagers not in charging state will not change mode.
Pressing DELETE button several times will return to calling mode.
Call history
Press H, the LCD displays H and the last call number. Press UP/DOWN to check the last 10 number records.
Pressing DELETE button several times will return to calling mode.
Warnings
Before using this radio, read this guide which contains
important operating instructions for safe usage and RF
energy awareness and control for compliance with
applicable standards and regulations.
Local Government Regulations
When the radios are used as a consequence of employment, the Local Government Regulations requires
users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure
awareness can be facilitated by the use of a product label directing users to specific user awareness
information. Your Retekess radio has a RF Exposure Product Label. Also, your user manual, or separate
safety booklet includes information and operating instructions required to control your RF exposure and to
satisfy compliance requirements.
Compliance with RF Exposure Standards (If appropriate, Reference to the actual product's
Safety Marking)
Your Retekess radio is designed and tested to comply with a number of national and International standards
and guidelines (listed below) for human exposure to radio frequency electro-magnetic energy.
Function
Remark
All charging pagers
Pagers must in
change to SILENT
charging state
mode
All charging pagers
Pagers must in
change to NORMAL
charging state
mode
2
