- Page 1 INFLATOR MANUAL Portable Inflator for general light duty tasks around the home MODEL NO. BR70i For service, spare parts or product information, please contact Smart Marketing Group Pty. Ltd. AUST. 1300 660 457 N.Z. 0800 474 876 Recyclable Cardboard...
-
Page 2: Table Of Contents
10 – 14 listed air tools and accessories above are not included with this inflator. Maintenance Trouble Shooting Technical Information Specifications Parts Diagram Inflator BR70i Contact Information Voltage 240V AC ~ 50Hz Motor 1 HP Wattage 750W Oil Free No Load Speed... -
Page 3: Introduction
INTRODUCTION What is covered. • Manufacturing fault or defect. Dear Customer, How to claim under this warranty. Thank you for purchasing this inflator which has passed through our extensive quality assurance processes. Every • Call customer service, phone number to the left. care has been taken to ensure that it reaches you in perfect •... -
Page 4: Guarantee
COMPLETE WARRANTY STATEMENT – INFLATOR As soon as you have purchased the inflator, we recommend Rust and corrosion are not covered under this warranty. that you check to make sure it is intact and that you read If a warranty fault is found the freight cost will be credited to the operating instructions carefully before using it. - Page 5 LUBRICATION OF INFLATOR WORK AREA This inflator is OIL FREE. Therefore there is NO oil used for Work areas and benches should be kept tidy. Cluttered lubrication. benches and work areas can cause accidents. Floors should be kept clean and free from rubbish. Special care should be taken when the floor is slippery due to sawdust or wax.
- Page 6 DO NOT ABUSE THE POWER CORD REMOVE ADJUSTING KEYS AND WRENCHES Never yank or pull on the power cord to disconnect it from the mains supply socket. Never carry or pull your inflator Form the habit of always checking to see that any adjusting by its power cord.
- Page 7 CHECK DAMAGED PARTS PERSONAL SAFETY Clothing Before using the inflator it should be carefully checked to determine that it will operate properly and perform its Do not wear loose clothing, jewellery or anything that could intended function. get caught in moving machinery. Check for the correct alignment of moving parts ensuring Hair that they do not bind.
- Page 8 IMPORTANT ELECTRICAL DATA This inflator is fitted with a sealed electrical connection plug that is compatible with the mains power supply for Australia / New Zealand and meets the requirements of Australian Standards. This inflator must be connected to a supply voltage that is equal to that stated on the rating label.
-
Page 9: Components And Controls
PIC. 1 COMPONENTS AND CONTROLS Pic. 1 Pressure switch On / Off button - red colour Handle Motor cover Pump Tank Rubber feet Tank drain tap Tank pressure gauge 10. Air filter - plastic 11. ‘Nitto style’ outlet socket fitting 12. -
Page 10: Operating Instructions
OPERATING INSTRUCTIONS PIC. 2 Unpacking Carefully unpack your inflator. Dispose of all packing material in an environmentally responsible manner. When unpacking this inflator always use the handle to lift it and be aware of this inflators weight. Failure to lift correctly may result in personal injury. - Page 11 STARTING AND STOPPING YOUR INFLATOR PIC. 3 Pic. 3 NOTE: Always ensure that you plug your inflator into a Lift button Push button standard 240V AC power point. Never use an extension cord up for on down for off as this can lead to a voltage drop which may cause power loss and over heating.
- Page 12 USING THE INFLATOR TOOL CONFIGURATION The configuration of tools and accessories can be varied to Before starting run through this simple list; suit your particular requirements. A basic recommended set Fully assembled. up is shown in Pic. 4 (accessories not included). Drain tap –...
- Page 13 SAFETY VALVE PIC. 5 Pic. 5 NOTE: When checking the safety valve ALWAYS wear safety glasses. To check the operation of the safety valve the air tank will need to be full. Gently pull the ring outwards. This should release air under pressure. Release the ring and this should stop the air out flow once the pressure has dropped.
-
Page 14: Maintenance
AIR OUTLET FITTING PIC. 7 Pic. 7 This inflator is fitted with a ‘Nitto style’ air fitting. To use: 1. Slide the outer collar down. 2. Push in the male fitting (not included). 3. Release the collar. 4. Fully and completely push the male fitting (not included) into the female until it clicks. -
Page 15: Trouble Shooting
CLEANING STORAGE ENSURE the inflator is NOT running whilst cleaning. To keep When storing ensure the air tank has been emptied as the inflator clean, always wipe down after use. Wear eye per ‘Drain Tap’ above. Always store away from children, protection when cleaning. -
Page 16: Technical Information
TECHNICAL INFORMATION Specifications Inflator BR70i Voltage 240V AC ~ 50Hz Motor 1 HP Wattage 750W Oil Free No Load Speed 2800 RPM Free Air Delivery (FAD) 70L per minute* Tank Size Duty Cycle Max Tank Pressure 115PSI (8BAR) Outlet Pressure...
