User Guide | Interface, EKC 366
Operation
Display
The values will be shown with three digits, and with a setting you
can determine whether they are to be shown in °C or in °F.
LED's on the front panel
There is one LED on the front panel which will light up when
power is sent to the pilot valve.
There are furthermore three LED's which will flash if there is an
error in the regulation. In this situation you can show the error
code on the display and cut out the alarm by giving the upper
button a brief push.
The controller can give the following messages:
E1
Errors in the controller
E11
Valve's actuator temperature outside its range
E12
Input signal outside its range
The buttons
When you want to change a setting, the two buttons will give you
a higher or lower value depending on the button you are push-
ing. But before you change the value, you must have access to the
menu. You obtain this by pushing the upper button for a couple
of seconds - you will then enter the column with parameter codes.
Find the parameter code you want to change and push the two
buttons simultaneously. When you have changed the value, save
the new value by once more pushing the two buttons simultane-
ously.
Gives access to the menu
Gives access to changes
Saves a change
Examples of operations
Set the valve's basic temperature reference
1. Push the two buttons simultaneously
2. Push one of the buttons and select the new value
3. Push both buttons again to conclude the setting
Read the valve's regulating reference
1. Push the lower button
(After approx. 20 seconds the controller automatically returns
to its setting, and it again shows the valve's actual temperature)
Set one of the other menus
1. Push the upper button until a parameter is shown
2. Push one of the buttons and find the parameter you want to
change
3. Push both buttons simultaneously until the parameter value is
shown
4. Push one of the buttons and select the new value
5. Push both buttons again to conclude the setting
© Danfoss | DCS (ADAP-KOOL®) | 2015-11
Menu survey
Function
Read valve's actual temperature (standard display)
Set valve's basic temperature reference
Read valve's regulation reference
Select temperature unit (°C/°F)
Input signal's temperature influence
Controller's address
ON/OFF switch (service-pin message)
Define input signal
0: no signal
1: 4 - 20 mA
2: 0 - 20 mA
3: 0 - 10 V
4: 2 - 10 V
Language (0=English, 1=German, 2=french, 3=Danish,
4=Spanish, 6=Swedish). When you change this setting
you must also activate o04.
Set supply voltage frequency
Service information
Read value of external current signal
Read value of external voltage signal
*) This setting will only be possible if a data communication module has been
installed in the controller.
Factory setting
If you need to return to the factory-set values, it can be done in this way:
- Cut out the supply voltage to the controller
- Keep both buttons depressed at the same time as you recon nect the supply voltage
SW =1.2x
Para-
Min.
Max.
meter
°C
-
-
40.0°C
140°C
°C
-
r05
°C
°F
r06
-99.9 K 99.9 K
o03*
1
60
o04*
-
-
o10
0
4
011*
0
6
o12
50 Hz
60 Hz
mA
u06
u07
V
DKRCI.PS.RP0.C1.02 | 4
