USER GUIDE TB-9015
Static Monitor 790
Installation, Operation and Maintenance
Figure 1. SCS Static Monitor
Description
The SCS Static Monitor 790 is designed to monitor the
operation of two wrist strap grounding systems and the
ground connection of a specified equipment chassis.
2300VM Series and SCS Dual Conductor Ground Cord
2300 Series. The monitor operates from a 120VAC
adaptor that is included in the North America version.
adapter meeting the specifications. The product has not
2300VM Series are required for use with the Static
Monitor 790, ordered separately.
Meets requirements of ANSI/ESD S20.20 and
AC Adapter
SCS Static Monitor 790
Figure 2. SCS Static Monitor
TB-9015 Page 1 of 7
June 2015
790.
Mounting
Chassis/
Ground
Cords with
Connector
790
Kit.
SCS
Theory of Operation
The SCS Static Monitor 790 is designed to continuously
high impedance voltage measurement circuit. The
measured operator's voltage is compared to one of four
voltages. An alarm will sound with a corresponding
contact detection circuit is also employed to let the user
The ground connection of the Static Monitor 790 is
continuously monitored through a low DC current-loop
measurement circuit. The ground connection of an
connected in series with the monitor's ground
measurement circuit. An alarm will sound with
corresponding red lamps, when this loop resistance
If all monitored components are operating within the
selected operating parameters of the Static Monitor 790,
a green lamp will illuminate.
The Static Monitor 790 uses a modified version of the
*Voltage alarm levels ±15%
**Ground disconnect ±20%
installation.
StaticControl.com
© 2015 DESCO INDUSTRIES, INC.
Employee Owned
