Summary of Contents for TMC Aquarium V2iLumenAir 900
- Page 1 LumenAir 900/1200...
- Page 2 900/1200 INSTRUCTIONS FOR INSTALLATION AND USE Important Safety Information - Please Read Carefully • Caution: Do not use any other power supply unit with the V iLumenAir as the light unit may not work and this may cause irreparable damage to the light unit. If the PSU supplied with the unit needs to be replaced then please obtain an authentic V iLumenAir PSU supplied by one of Tropical Marine Centre’s local stockists.
-
Page 3: Product Specification
Product Specification Product Specification Model: V iLumenAir 900 Model: V iLumenAir 1200 Size: 690 x 260 x 40mm Size: 812 x 260 x 40mm Suitable for tanks 730 -1200mm long Suitable for tanks 840 -1300mm long x 300 - 880mm wide x 300 - 880mm wide Input: 100-240V 50/60Hz Input: 100-240V 50/60Hz... -
Page 4: Installation
Installation The V iLumenAir can be mounted via the tank mounting kit (supplied) or wire suspension kit iLumenAir 900 - sold separately). a. Tank Mounting - V iLumenAir 900 b. Tank Mounting V iLumenAir 1200 X = L + 25mm... - Page 5 c. Wire Suspension Press Remove the clear plastic tab from the remote control...
-
Page 6: Display Screen
Display Screen shows when in daytime phase shows when in sunrise or sunset phase shows when in dawn or moonlight phase shows when the light is off • In run mode the display shows the time in either 24 or 12 hour clock format. •... - Page 7 Operating Instructions Quick start 1. Ensure the clear plastic battery protection tab is removed from the bottom of the remote control (see page 4). 2. To use the remote control, point it at the infrared sensor at the cable entry to the light unit. 3.
- Page 8 Programming 1. Press to set the start time for your photoperiod. Press once to adjust the hour and twice to START adjust the minute. Use to adjust up or down. 2. Press to save your settings. SAVE 3. Press to set the dawn phase duration. Press once to adjust the hours and twice to adjust the minutes.
-
Page 9: Factory Settings
CYCLE Once you have set your program, you can see a demo of your settings by pressing . This will run DEMO through the 24 hour photoperiod in just over 2 minutes (1 second = 10 minutes of the cycle. NOTE: If the total number of hours in your photoperiod is less than 24 hours then the light will turn off after the moonlight phase and will come on again at the start time. -
Page 10: Over Temperature Protection
Over Temperature Protection The smart fans will start to work when the lights are on full, or the temperature of the light is over 38°C (100°F) and will stop when it cools to around 34°C (93°F). If the unit gets too hot, at around 60°C (140°F), the light will shut down and the display will show Blue LED Trim Operation To control the blue LED trim, point the remote control at the infrared sensor on the light unit at the... - Page 11 Tropical Marine Centre, Solesbridge Lane, Chorleywood, Hertfordshire,WD3 5SX, UK Technical Information Lines Tel: +44 (0) 1923 284151 Fax: +44 (0) 1923 285840 Open between 9am - 5pm Monday to Thursday/9am - 12pm Friday. www.tropicalmarinecentre.co.uk tmc@tropicalmarinecentre.co.uk v.2/2014...
