Technibel CSCV 152 LL Installation Instructions Manual

Console type split system for low temperature rooms

Advertisement

Quick Links

INSTALLATION INSTRUCTIONS
CSCV - LL
CSCV 152 LL
CSCV 202 LL
CSCV 302 LL
CSCV 402 LL
CONSOLE TYPE SPLIT SYSTEM
FOR LOW TEMPERATURE ROOMS
R 407 C refrigerant
April 2004
10 11 388 - GB - 04
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSCV 152 LL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Technibel CSCV 152 LL

  • Page 1 INSTALLATION INSTRUCTIONS CSCV - LL CSCV 152 LL CSCV 202 LL CSCV 302 LL CSCV 402 LL CONSOLE TYPE SPLIT SYSTEM FOR LOW TEMPERATURE ROOMS R 407 C refrigerant April 2004 10 11 388 - GB - 04...
  • Page 2: Table Of Contents

    MARKING This product marked conforms to the essential requirements of the Directives : - Low voltage no. 73/23 EEC, modified 93/68 EEC, - Electromagnetic Compatibility no. 89/336 EEC, modified 92/31 and 93/68 EEC. SUMMARY 1 - General ........................2 2 - Presentation ......................3 3 - Installation of the units ...................
  • Page 3: Presentation

    2 - PRESENTATION 2.1 - DESCRIPTION INDOOR UNIT - TAV TAV 152 L 1 - Outlet grille. TAV 202 L 2 - Removable panel. TAV 302 L 3 - Front panel. TAV 402 L 4 - Inlet grille. 5 - Rear support. Materials: 6 - Door.
  • Page 4: Installation Of The Units

    OUTDOOR UNIT - GRV GRV 72 L GRV 92 L GRV 122 L GRV 180 L Packed Unit Length Height Depth GRV 72 L GRV 92 L GRV 122 L GRV 180 L 3 - INSTALLATION OF THE UNITS 3.1 - INSTALLATION OF THE INDOOR UNIT •...
  • Page 5: Installation Of The Outdoor Unit

    3.1.6 - HORIZONTAL BLOWING • Remove the cabinet (see page 4). 1 - Remove the outlet grille (1): undo the two clips (A) by turning them a quarter of a turn (using a screw driver or a coin). 2 - Remove the door (9) by pressing on the side to release the hinge pin (B). 3 - Remove the control panel (7) by taking out the two fastening screws (C).
  • Page 6: Connections

    GRV above be added Liquid A (m) level B (m) (g/m) CSCV 152 LL 3/8" 1/4" CSCV 202 LL 3/8" 1/4" CSCV 302 LL 1/2" 1/4" 1 660 1-phase CSCV 402 LL 1/2"...
  • Page 7: Electrical Connection

    4.2.1 - INSULATION OF PIPES • Insulate the 2 tubes separately. • Use polyethylene sheathing at least 8 mm thick. • Pay particular attention to water entering along the pipes through the wall. 4.2.2 - CONNECTION TO THE INDOOR UNIT •...
  • Page 8 GRV 92 L connexion diagram. GRV 122 L GRV 180 L 4.3.5 - CONNECTION DIAGRAM A - CSCV 152 LL CSCV 202 LL CSCV 302 LL B - CSCV 402 LL in 230/1/50 C - CSCV 402 LL in 400/3N/50...
  • Page 9: Indoor Unit Accessories

    5 - INDOOR UNIT ACCESSORIES 5.1 - CEILING SUPPORT • To make the unit easier to handle, we recommend that you remove the cabinet as well as the fan assembly (see page 4). FIXING: • Drill eight 10 mm dia. holes in the places indicated. •...
  • Page 10 • Wall mounting: - Secure the unit at a height of approximately 1.5 m from the floor in a location representative of normal convection currents, while avoiding: - wall which are poorly insulated or liable to vibrate, - the proximity of parasitic heat sources (sunshine, heating appliances, lamps, fireplaces, televisions, etc.), - currents of air from doors or windows, - sheltered locations such as shelves or behind curtains, - near electrical outlets.
  • Page 11: Outdoor Unit Accessories

    • Note: If a hydrothermostat is used, the electric heater Type HYG 7001 accessory is obligatory. • Theory of operation: - This remote control contains both a thermostat (settings: 10/35°C) and a hygrostat (settings: 35/ 100% relative humidity). The hygrostat is used for the "dehumidification" function.
  • Page 12: Connecting Accessories

    K 70 A 02 AT K 70 A 004 T CSCV 302 LL K 70 A 04 AT K 70 A 005 T CSCV 152 LL CSCV 402 LL K 70 A 08 AT K 70 A 006 T CSCV 202 LL...
  • Page 13: Maintenance Instructions

    9 - MAINTENANCE INSTRUCTIONS IMPORTANT Before doing any work on the installation, make sure it is switched off and put out of bounds. All operations must be carried out by personnel that are approved and qualified for this type of equipment. •...
  • Page 14 TAV 402 L - 230/1/50 10 05 716 - 02 Power supply 230/1/50 Remote control (accessory) 230 V Heating Heating control Cooling Anti-frost thermostat HS MS LS Speed connection External unit control 1 2 3 4 5 6 7 GRV 72 L - GRV 92 L - GRV 122 L - 230/1/50 Earth SEC1...
  • Page 15 GRV 180 L - 230/1/50 Power supply 230/1/50 LOAD LINE GRV 180 L - 400/3N/50 LINE LOAD T 13 a/A1 W 14 b/A2 8/95 7/96...
  • Page 16 Due to our policy of continuous development, our products are liable to modification without notice. R.D. 28 Reyrieux BP 131 01601 Trévoux CEDEX France Tel. 33 4 74 00 92 92 - Fax 33 4 74 00 42 00 R.C.S. Bourg-en-Bresse B 759 200 728...
