Spa Cover Installation Instructions

Required Tools:
Drilling Machine
Drill bit, 3/32"
Phillips screwdriver
Marking Pen
Masking Tape
Using masking tape, tape the drill bit about ½" from the
tip. This will be the limit of the depth of the drilling to
be made.
1.Place cover on the spa.
Be sure it is
correctly positioned.
2.Position the tie-down
hardware with the latch (attached to the straps
of your cover) on the side of the spa.
3.With the straps pulled taut (not overly tight), use a
suitable colored pen to mark the location of the
latch placement.
Owner's Manual
4.Position the latch with reference to the mark.
5.Mark the position of the holes for screw
6.Drill the 2 pilot holes. Do not drill beyond
7.Using the screws provided, attach the latch to the
spa.
8.Keep cover fastened down at all times
when not in use. Locking hardware may be
8
through the latch.
the ½" limit set by the masking tape on the
drill bit.
locked with a key (provided).
