OVERFILL PREVENTION VALVE
Assembly and Installation Instructions
I
mportant: Read these instructions completely and carefully before attempting to
install and operate this valve. Failure to do so may result in improper valve opera-
tion allowing for a potential storage tank overfill. An overfilled tank can create
extremely hazardous fuel spills which may result in personal injury and property
damage. For further information, please call our Customer Service Department at
(252) 243-0150.
Important: Veuillez lire ces instructions attentivement avant d'installer et d'exploiter
cette vanne. Ne pas le faire peut entraîner un fonctionnement incorrect de la vanne
permettant un potentiel débordement de la citerne de stockage. Un réservoir trop
plein peut créer des déversements de carburant extrêmement dangereuses qui peu-
vent entraîner des blessures et des dommages matériels. Pour plus d'informations,
s'il vous plaît communiquer avec notre service à la clientèle au (252) 243-0150.
Note: All information, illustrations and specifications in this manual are based on the lat-
est product information available. We reserve the right to make changes at any time with-
out notice.
CAUTION: Never disconnect the drop elbow from the tight-fill adapter when the A1100
has reached the positive shut-off level. At this point, the tank truck hose is still full and
must not be disconnected until enough fuel has been removed from the underground stor-
age tank to drain the hose. Premature disconnection will result in a hazardous spill and a
potential for personal injury and property damage.
ATTENTION: Ne jamais déconnecter le coude de baisse de l'adaptateur permet le rem-
plissage étanche lorsque le A1100 a atteint le niveau d'arrêt positive. A ce point, le tuyau
de camion-citerne est encore pleine et ne doit pas être débranché jusqu'à ce que suff-
isamment de carburant a été éliminée du réservoir de stockage souterrain pour vidanger
le tuyau. Déconnexion prématurée entraîne un déversement dangereux et un risque de
blessures et de dommages matériels.
A1100 GUARDIAN
(with 493192 Installation Kit)
Assembly
Tools
Packing List
Procedure
Installation
General Maintenance
Warranty
2-7
2
2
2-6
7
8
8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Emco A1100
Summary of Contents for Emco A1100
- Page 1 ATTENTION: Ne jamais déconnecter le coude de baisse de l'adaptateur permet le rem- plissage étanche lorsque le A1100 a atteint le niveau d'arrêt positive. A ce point, le tuyau de camion-citerne est encore pleine et ne doit pas être débranché jusqu'à ce que suff- isamment de carburant a été...
- Page 2 WARNING: If the underground storage tank is equipped with a ball float vent valve, make sure it is not extended below the positive shut-off point of the A1100, or remove the float vent valve. ATTENTION: Si le réservoir de stockage souterrain est équipé d'un flotteur évent de balle vanne, assurezvous qu'il n'est pas prolongée en dessous du point d'arrêt positive de la...
- Page 3 Figure 1 Riser Pipe With Spill Containment Manhole Figure 2 Riser Pipe Installed Inside Manway...
- Page 4 12.0’ 3.66 14.0" The A1100 Overfill Prevention Valve is not recommended for tanks under 6.5’ in diameter. Step 4: To determine the top tube cut length, C: Add A and B; subtract 2”. A + B - 2 = C Step 5: Place a tape measure at one end of the drop tube and mark length C.
- Page 5 Remove drill fixture and set valve. aside. Step 10: Lubricate the O-ring (p/n Step 11: Insert the A1100 valve 480049, supplied) with the Seal-All into the top tube. Align the holes. and insert into the top groove of the A1100 valve.
- Page 6 BOTTOM TUBE INSTALLATION PROCEDURE Step 14: Lubricate bottom of Step 13: Slide the 572719 Drill A1100 valve with Seal-All and Fixture on drop tube. Drill the four install bottom tube, being careful to holes using the 13/64” drill bit. align holes.
- Page 7 INSTALLATION OF COMPLETED ASSEMBLY INTO THE TANK Step 21: Turn completed assembly upside down and shake vertically to remove any metal chips left from the drilling process. Step 22: Install the O-ring (p/n 561683, supplied) on the top flange. Step 23: Position the completed assembly vertically over the riser pipe with the square cut down.
-
Page 8: Maintenance
(12) months from the date of manufacture. The warranty set forth herein shall be the exclusive warranty made by Emco Wheaton Retail Corporation and in lieu of all other warranties, expressed or implied, (whether written or oral), including but not limited to any implied warran- ty of merchantability or fitness for any particular purpose.
