TTS Easi-Speak User Manual

Easi-Speak Bluetooth

User Guide

www.tts-group.co.uk
Easi-Speak Bluetooth
Using Your Product
To turn the Easi-Speak on, move the slide switch to the ON position. The LED's will light
green to indicate the device is on.
Recording
To make a recording press and release the red record button, a single beep will be
heard and the LED's will cycle red to indicate recording has started. To stop recording
press and release the record button, a double beep will be heard and the LED's will
change to solid green to indicate recording has stopped.
Playback
To playback a recording press and release the green play button. The LED's will cycle
green and playback will begin. To pause playback, press and release the green play
button, the LED's will flash amber. To stop playback, press the green play button (1-2
seconds) and release. The LED's will change to solid green and playback will stop.
When audio is played back, it can be heard through the internal speaker, headphones or
through a Bluetooth connection.
Track Skip
To skip forward to the next track, press and release the skip forward button. To skip back
to the start of a track or a previous track, press the skip back button.
Fast Forward/Rewind
To fast forward within a track, press and hold the skip forward button. The LED's will fast
cycle green. To rewind within a track, press and hold the skip back button. The LED's will
fast cycle green.
Deleting files
To delete a single recording, pause the track as it is playing, then long press the record
button (5 seconds) until the LED's flash red, then release the button. When the track has
been deleted the LED's will change to solid green.
To delete all tracks, ensure the device is playing, then long press the record button (5
seconds) until the LED's flash red, then release the button. When the track has been
deleted the LED's will change to solid green.
Files can also be deleted when Easi-Speak BT is connected to a PC using USB.
®
Important Information
¥ Please retain the information in this User Guide for future reference.
¥ Please read all instructions fully before using.
¥ To clean, wipe the surface with a clean damp cloth.
¥ Do not allow the product to come into contact with water or any other liquids.
¥ Keep the product away from direct sunlight and heat.
¥ If your product malfunctions please switch it off and then back on again to reset it.
Pack Contents
¥ Easi-Speak BT
¥ User Guide
¥ 1 x USB (type A female to type A male) charging cable
¥ Lanyard with quick release
Know Your Product
On/Off/Bluetooth
Switch
1
®
Volume Controls
To increase or decrease the volume, use the volume control buttons. This will change the
volume of audio played back through the internal speaker, headphones or Bluetooth.
Bluetooth
The Bluetooth function is capable of playing audio through a Bluetooth speaker or
headphones. It allows audio to be recorded via Bluetooth and allows files to be
managed through a Bluetooth connection.
To switch Bluetooth on move the slide switch to the Bluetooth position.
To use with a Bluetooth Speaker
When the microphone is switched into Bluetooth mode, it will default to mode 2. This is
used for connecting to Bluetooth speakers. The LED's will flash blue on and off slowly to
indicate mode 2 is active.
To connect to a Bluetooth speaker, press and hold the play button until three consecutive
beeps are heard. This puts the microphone in pairing mode. Ensure the speaker you
are trying to pair to, is switched on and also in pairing mode. After a few seconds the
microphone will connect to the speaker and the LED's will change to solid blue.
NB: The above steps will need to be completed every time you wish to connect to a
Bluetooth speaker.
To playback a recording through the speaker, press and release play on the
microphone. The LED's will flash blue/green.
To talk live through the speaker press and release record on the microphone. The LED's
will flash red/blue.
To record live to an external device
Ensure the microphone is in Bluetooth mode 1. This is done by moving the on/off switch
into the Bluetooth position, then pressing the play button until a single beep is heard. The
LED's will flash blue in sequences of 3 flashes to indicate mode 1 has been selected.
Once the microphone is in mode 1, press and hold the play button until three beeps are
heard. This puts the microphone in pairing mode.
3
Record Play Pause
Volume Up/Down Headphone Port
Skip Buttons
Wrist Strap Loop
2
4
