  • Page 1 N550RN...
  • Page 3 Preface Notebook Computer N550RN Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the N550RN se- ries notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Preface Contents Introduction ..........1-1 Main Board ................... A-5 HDD ....................A-6 Overview ..................1-1 LCD ....................A-7 Specifications ..................1-2 Schematic Diagrams......... B-1 External Locator - Top View with LCD Panel Open ......1-4 External Locator - Front & Right Side Views .........1-5 System Block Diagram ..............B-2 External Locator - Left Side &...
  • Page 12 Preface PCH 6/8 ..................B-28 Unzip the downloaded files to a bootable CD/DVD or PCH 7/8 ..................B-29 USB Flash drive ................C-1 PCH 8/8 ..................B-30 Set the computer to boot from the external drive ......C-1 USB 3.0 ..................B-31 Use the flash tools to update the BIOS ...........C-2 M.2 SATA &...

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the N550RN series notebook computer. Information about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri- vers (e.g.

  • Page 14: Specifications

    Introduction Specifications Processor Options Video Adapter Intel® Core™ i7 Processor Intel® Integrated GPU and NVIDIA® Discrete GPU i7-6700HQ (2.60GHz) Supports Microsoft Hybrid Graphics 8MB Smart Cache, 14nm, DDR3L-1600MHz, TDP 45W  Intel Integrated GPU Intel® Core™ i5 Processor Latest Specification Information Intel®...
  • Page 15 Introduction Keyboard Communication Full-size “WinKey” keyboard (with numeric keypad) Built-In Gigabit Ethernet LAN (Factory Option) Full-size “WinKey” Illuminated White-LED 1.0M HD PC Camera Module Keyboard (with numeric keypad) (Factory Option) 2.0M FHD PC Camera Module (Factory Option) M.2 3G or 4G Module Pointing Device WLAN/ Bluetooth M.2 Modules: Built-in Touchpad...

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. PC Camera 2. *PC Camera LED *When the PC camera is in use, the LED will be illuminated. 3. Built-In Array Microphone 4. LCD 5. Speakers 6.

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicator FRONT VIEW Figure 3 Right Side View 1. Multi-in-1 Card RIGHT SIDE VIEW Reader 2. USB 3.0 Ports 3. RJ-45 LAN Jack External Locator - Front & Right Side Views 1 - 5...

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. Security Lock Slot 2. External Monitor Port LEFT SIDE VIEW 3. Headphone-Out Jack 4. Microphone-In Jack 5. S/PDIF-Out Jack 6. USB 2.0 Port 7. USIM Card Reader (for 3G/4G USIM Cards) Figure 5...

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use. External Locator - Bottom View 1 - 7...

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. KBC-ITE IT8587 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. M.2-Card Connector (SSD Module) 2. Mini-Card Connector (WLAN Module) 3. GPU-GTX965M 5. CMOS Battery 6. Memory Slots DDR3L SO-DIMM 7. CPU 8. Mini-Card Connector (3G/ SATA Module) Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 2. Connector 4. Keyboard Cable Connector 5. FAn Cable COnnector 6. DC-In Jack 7. USB Port 3.0 Connector 8. Mini Display Port 9. HDMI-Out Port 10. USB Port 3.0 Connector 11.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. Multi-in-1 Card Reader 2. HDD Connector Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the N550RN series notebook’s parts and subsystems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Keyboard: 1. Remove the keyboard page 2 - 5 To remove the Battery: 1.

  • Page 29: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 1 Keyboard Removal 1. Turn off the computer, turn it over. 2. Remove screws from the bottom of the computer. a. Remove the screws from 3. Open it up with the LCD on a flat surface before pressing at point to release the keyboard module (use the spe- the bottom of the compu- cial eject stick...

  • Page 30: Removing The Battery

    Disassembly Removing the Battery Figure 2 Battery Removal 1. Turn the computer off, and turn it over. 2. Remove the SD card cover and screws (Figure 2a). a. Remove the SD cover 3. Carefully lift the bottom case up from point and remove it (Figure 2b and screws.
  • Page 31 Disassembly 5. Carefully disconnect the cable , then remove screws (Figure 3b Figure 3 6. Lift the battery off the computer (Figure 3e Battery Removal 7. Reinsert the bottom case starting from point as shown (Figure 3f) to avoid damaging the rear eSATA/USB 3.0 (cont’d.) port.

  • Page 32: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive Figure 4 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Removal or 7mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 33 Disassembly 4. Slightly lift and pull the hard disk assembly in the direction of arrow (Figure 5c Figure 5 5. Lift the hard disk assembly out of the bay (Figure 5d HDD Assembly 6. Remove screws and bracket from the hard disk (Figure 5e Removal (cont’d.) 7.

  • Page 34: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 6 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3L up to 1600 MHz. The main memory can be expanded up to 16GB. The total memory size is automatically de- tected by the POST routine once you turn on your computer.

  • Page 35: Removing And Installing The M.2 Ssd Module

    Disassembly Removing and Installing the M.2 SSD Module Figure 7 M.2 SSD Module M.2 SSD Module Removal Procedure Removal 1. Turn off the computer, turn it over, remove the battery (page 2 - 2. The M.2 SSD module will be visible at point on the mainboard (Figure 7a).
  • Page 36 Disassembly M.2 SSD Installation Procedure (for PM951 only) Figure 8 M.2 SSD Module 1. Place the thermal pad on the module as shown (Figure 8a). Installation 2. Insert the module in the computer Figure 8b 3. Tighten the screw to secure it in place (Figure 8c).

  • Page 37: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 9 Wireless LAN 1. Turn off the computer, turn it over, remove the battery (page 2 - Module Removal 2. The Wireless LAN module will be visible at point on the mainboard (Figure 9a).

  • Page 38: Wireless Lan, Combo, 3G & Lte Module Cables

    Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below.

  • Page 39: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 10 3G Module Removal Procedure 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - a. Locate the module. 2. Locate the module, it is visible at point Figure 10a b.
  • Page 40 Disassembly 2 - 16...

  • Page 41: Part Lists

    Appendix A:Part Lists This appendix breaks down the N550RN series notebook’s construction into a series of illustrations. The component part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 42: Part List Illustration Location

    Part List Illustration Location The following table indicates where to find the appropriate part list illustration. Table A - 1 Part List Illustration Part Location page A - 3 Bottom page A - 4 page A - 5 Main Board page A - 6 page A - 7 A - 2...

  • Page 43: Top

    Figure A - 1 Top A - 3...

  • Page 44: Bottom

    Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 45: Main Board

    Main Board Figure A - 3 Main Board Main Board A - 5...

  • Page 46: Hdd

    Figure A - 4 A - 6 HDD...

  • Page 47: Lcd

    Figure A - 5 LCD A - 7...
  • Page 48 A - 8...

  • Page 49: Schematic Diagrams

    Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the N550RN notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Diagram - Page Diagram - Page Diagram - Page Table B - 1...

  • Page 50: System Block Diagram

    Schematic Diagrams System Block Diagram 5V,5VS,3.3V,3VS N550RC Skylake-H System Block Diagram N550RC AUDIO BOARD SHEET 38 6-71-N5508-D02A SHEET 53,54 VDD3,VDD5 N550RC POWER SW BOARD SHEET 39 6-71-N550C-D02A SHEET 52 VDDQ(1.35V),VTT_MEM(0.65VS) N550RC LED BOARD <=4.5" SHEET 40 Skylake-H 1067/1333/1600 MHz 6-71-N5504-D02B SHEET 51 DDR3L / 1.35V N16P-GT GTX950M...

  • Page 51: Processor 1/6

    Schematic Diagrams Processor 1/6 EDP/LVDS IC SKYLAKE_HALO SKYLAKE_HALO EDP_TXP_0 BGA1440 EDP_TXN_0 BGA1440 DDI1_TXP[0] EDP_TXP[0] EDP_TXP_1 EDP_TXN_1 DDI1_TXN[0] EDP_TXN[0] PEG_TX_0 C591 0.22u_10V_X5R_04 PEG_RX0 PEG_RXP[0] PEG_TXP[0] PEG_TX0 14 DDI1_TXP[1] EDP_TXP[1] PEG_TX#_0 C589 0.22u_10V_X5R_04 PEG_RX#0 VGA CON PEG_RXN[0] PEG_TXN[0] PEG_TX#0 14 DDI1_TXN[1] EDP_TXN[1] VGA_LANE0_N DDI1_TXP[2] EDP_TXN[2]...

  • Page 52: Processor 2/6

    Schematic Diagrams Processor 2/6 SKYLAKE_HALO SKYLAKE_HALO M_A_DQ[63..0] M_B_DQ[63:0] BGA1440 BGA1440 M_A_DQ0 M_B_DQ0 BT11 M_A_CLK_DDR0 M_B_CLK_DDR0 DDR0_DQ[0] DDR0_CKP[0] DDR1_DQ[0]/DDR0_DQ[16] DDR1_CKP[0] M_A_DQ1 M_B_DQ1 BR11 DDR0_DQ[1] DDR0_CKN[0] M_A_CLK_DDR#0 DDR1_DQ[1]/DDR0_DQ[17] DDR1_CKN[0] M_B_CLK_DDR#0 M_A_DQ2 M_B_DQ2 DDR0_DQ[2] DDR0_CKN[1] M_A_CLK_DDR#1 DDR1_DQ[2]/DDR0_DQ[18] DDR1_CKN[1] M_B_CLK_DDR#1 M_A_DQ3 M_B_DQ3 DDR0_DQ[3] DDR0_CKP[1] M_A_CLK_DDR1 DDR1_DQ[3]/DDR0_DQ[19] DDR1_CKP[1]...

  • Page 53: Processor 3/6

    Schematic Diagrams Processor 3/6 CFG[0]: Stall reset sequence after PCU NEAR CPU PLL lock until de-asserted: — 1 = (Default) Normal Operation; 1.0V_VCCST No stall. VCCIO — 0 = Stall. CFG[1]: Reserved configuration lane. SKYLAKE_HALO CFG9 R369 *1K_04 CFG[2]: PCI Express* Static x16 Lane BGA1440 Numbering Reversal.

  • Page 54: Processor 4/6

    Schematic Diagrams Processor 4/6 SKYLAKE_HALO VCORE VCORE SKYLAKE_HALO BGA1440 The power is for the BGA1440 AA13 w/OPC processor. AA31 BJ17 +VCCEDRAM VCCOPC AA32 BJ19 VCCOPC AA33 BJ20 VCCOPC AA34 BK17 VCCOPC AA35 BK19 VCCOPC AA36 BK20 VCCOPC AA37 BL16 VCCOPC AA38 BL17 VCCOPC...

  • Page 55: Processor 5/6

    Schematic Diagrams Processor 5/6 VCCSA SKYLAKE_HALO VDDQ SKYLAKE_HALO BGA1440 BGA1440 VCCSA VDDQ AE12 BM33 11.1A 2.8A TP_SKL_D1 TP_SKL_BM33 VCCSA VDDQ RSVD_TP RSVD_TP TP_SKL_E1 BL33 TP_SKL_BL33 VCCSA VDDQ RSVD_TP RSVD_TP TP_SKL_E3 VCCSA VDDQ RSVD_TP BJ14 TP_SKL_E2 TP_SKL_BJ14 VCCSA VDDQ RSVD_TP RSVD_TP BJ13 TP_SKL_BJ13 VCCSA...

  • Page 56: Processor 6/6

    Schematic Diagrams Processor 6/6 SKYLAKE_HALO SKYLAKE_HALO SKYLAKE_HALO SKYLAKE_HALO SKYLAKE_HALO VCCGT +VCCGTU VCCGT VCCGT BGA1440 BGA1440 BGA1440 BGA1440 AK30 AJ29 AF29 BG34 BGA1440 AV29 VCCGT VCCGTX VCCGT VCCGT AK29 AJ30 AF30 BG35 AV30 VCCGT VCCGTX VCCGT VCCGT AJ31 AF31 BG36 AV31 VCCGT VCCGTX VCCGT...

  • Page 57: Ddr3 Cha So-Dimm

    Schematic Diagrams DDR3 CHA SO-DIMM Channel A SO-DIMM 0 RVS TYPE J_DIMMA_1B H=5.2mm 3.3VS VDDQ R239 *10K_04 TS#_DIMM0_1 VDD1 VSS16 VDD2 VSS17 J_DIMMA_1A R442 10K_04 CHA_SA0_DIM0 M_A_A[15..0] M_A_DQ[63..0] VDD3 VSS18 M_A_A0 M_A_DQ4 R124 10K_04 CHA_SA1_DIM0 VDD4 VSS19 M_A_A1 M_A_DQ1 VDD5 VSS20 M_A_A2 M_A_DQ6...

  • Page 58: Ddr3 Chb So-Dimm

    Schematic Diagrams DDR3 CHB SO-DIMM Channel B SO-DIMM 1 STD TYPE J_DIMMB_1B H=5.2mm 3.3VS VDDQ R205 10K_04 CHB_SA1_DIM1 VDD1 VSS16 R206 10K_04 CHB_SA0_DIM1 VDD2 VSS17 J_DIMMB_1A M_B_B[15:0] M_B_DQ[63:0] VDD3 VSS18 M_B_B0 M_B_DQ0 VDD4 VSS19 M_B_B1 M_B_DQ4 VDD5 VSS20 M_B_B2 M_B_DQ2 VDD6 VSS21 M_B_B3...

  • Page 59: Ps8625

    Schematic Diagrams PS8625 PS8625 (eDP to LVDS) *20mil_short_04 GND_PS8625 VDDIO VDDRX VDDIO single PCB trace 6-19-31001-247 GND_PS8625 3.3VS VDDIO HCB1005KF-121T20 VR23 VR22 0.1u_10V_X7R_04 0.1u_10V_X7R_04 0.01u_50V_X7R_04 0.1u_10V_X7R_04 4.7u_6.3V_X5R_06 10K_04 10K_04 0.47u_10V_Y5V_04 1u_6.3V_X5R_04 22u_6.3V_X5R_08 PIN50 PIN38 PIN6 PIN6 PIN6 PS8625_PD# GND_PS8625 GND_PS8625 RST# VDDIO GND_PS8625...

  • Page 60: Panel, Inverter

    Schematic Diagrams Panel, Inverter PANEL CONNECTOR LED PANEL (LVDS Dual Channel). PANEL POWER LVDS DEFAULT SHORT 3904+2N7002 J_LCD1 PJ54 *OPEN-2mm DRX0# VR19 0_04 VLED PLVDD LVDS-L0N DRX0 VR17 0_04 LVDS-L0P C680 1u_6.3V_X5R_04 DRX1# VR20 0_04 C733 C732 LVDS-L1N DRX1 VR18 0_04 Q26A LVDS-L1P...

  • Page 61: Mini Dp Port

    Schematic Diagrams Mini DP Port mini-Display Port PLEASE CLOSE TO CONNECTOR R325 *10mil_short_04 3.3VS 3.3VS_MDP 20mils C522 0.1u_10V_X7R_04 D_MDP_B#3 MDP_B#3 VOUT C523 0.1u_10V_X7R_04 D_MDP_B3 MDP_B3 SY6288DAAC *DVI2012F2SF-900T05_08 R326 *10mil_short_04 *10u_6.3V_X5R_06 10u_6.3V_X5R_06 R323 *10mil_short_04 C520 0.1u_10V_X7R_04 D_MDP_B#2 uP7549UMA5-20 MDP_B#2 13,38,40,41 SUSB PCB Footprint = M-SOT23-5A C521 0.1u_10V_X7R_04 D_MDP_B2...

  • Page 62: Hdmi Ps8201

    Schematic Diagrams HDMI PS8201 HDMI CONNECTOR HDMI_5VS HDMI_5VS HDMI_5VS 20mils HDMI_5VS J_HDMI1 EMC2 EMC3 16-A1030-1003-0 PCB Footprint = 116b-xx002-21x R320 R319 100p_50V_NPO_04 0.1u_16V_Y5V_04 VOUT 6-21-14230-019 C509 C508 2.2K_04 2.2K_04 SY6288DAAC 22u_6.3V_X5R_08 22u_6.3V_X5R_08 HDMI_SCL-C HDMI_SDA-C 12,38,40,41 SUSB HDMI_HPD-C HOT PLUG DETECT uP7549UMA5-20 HDMI_HPD-C PCB Footprint = M-SOT23-5A...

  • Page 63: Vga Frame Buffer Interface

    R348 *4.99K_1%_04 6-03-10877-0S0 *10K_04 VGA_STRAP4 R345 *45.3K_1%_04 Title Title Title [14] VGA Frame Buffer Interface [14] VGA Frame Buffer Interface [14] VGA Frame Buffer Interface N550RN 15,43 PEX_VDD 20,25,43 3V3_AON VRAM 6-04-48032-E30 U19 , U23 20,43,44 3V3_RUN Size Size Size...

  • Page 64: Vga Frame Buffer Interface

    Schematic Diagrams VGA Frame Buffer Interface Frame Buffer Interface U13C U13D U13B GM107-750-A2 GM107-750-A2 GM107-750-A2 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 COMMON COMMON COMMON FBVDDQ 3/17 FBB 14/17 FBVDDQ 2/17 FBA 1.35V R360 AA27 FBVDDQ ALL PINS NC FOR GF117/GK208 FBVDDQ AA30 18,19 FBB_D[63:0] AB27 10K_04...

  • Page 65: Vga Frame Buffer A

    Schematic Diagrams VGA Frame Buffer A U19B U19C INS126147984 INS126149725 BGA170 BGA170 COMMON COMMON Normal 15,17 FBA_CMD[31:0] FBA_CMD12 FBA_CMD15 FBA_SOE0 MF_VSS/SOE* FBA_CLK0 FBA_CMD5 add 1k to VSS FBA_CLK0# FBA_CMD0 FBVDDQ FBA_D[31:0] FBA_CMD8 U19D U19A INS126148531 INS126148996 FBA_CMD10 A0_A10 BGA170 BGA170 FBA_CMD11 A1_A9 COMMON...

  • Page 66: Vga Frame Buffe A

    Schematic Diagrams VGA Frame Buffe A 1K_04 FBVDDQ U23B U23C *1K_04 <HDL_POWER> INS126208961 INS126208627 BGA170_MIRR BGA170_MIRR COMMON COMMON Mirrored 15,16 FBA_CMD[31:0] FBA_CMD28 FBA_CMD31 FBA_SOE3 SOE*/MF_VDD FBA_CLK1 FBA_CMD21 add 1k to VDD FBA_CLK1# FBA_CMD16 FBVDDQ FBA_D[63:32] FBA_CMD24 U23D U23A INS126209050 INS126209130 FBA_CMD26 A0_A10 BGA170_MIRR...

  • Page 67: Vga Frame Buffer B

    Schematic Diagrams VGA Frame Buffer B U15B U15C INS126058188 INS126540016 BGA170 BGA170 COMMON COMMON Normal 15,19 FBB_CMD[31:0] FBB_CMD12 FBB_CMD15 FBB_SOE0 MF_VSS/SOE* FBB_CLK0 FBB_CMD5 FBB_CLK0# add 1k to VSS FBB_CMD0 FBVDDQ FBB_D[31:0] FBB_CMD8 U15D U15A INS126449412 INS126045494 FBB_CMD10 A0_A10 BGA170 BGA170 FBB_CMD11 A1_A9 COMMON...
  • Page 68 Schematic Diagrams VGA Frame Buffer B 1K_04 FBVDDQ U16B U16C *1K_04 <HDL_POWER> INS118067408 INS124898714 BGA170_MIRR BGA170_MIRR COMMON COMMON Mirrored 15,18 FBB_CMD[31:0] FBB_CMD28 FBB_CMD31 FBB_SOE3 FBB_CLK1 SOE*/MF_VDD FBB_CMD21 FBB_CLK1# add 1k to VDD FBB_CMD16 FBVDDQ FBB_D[63:32] FBB_CMD24 U16D U16A INS118068289 INS118067645 FBB_CMD26 A0_A10 BGA170_MIRR...

  • Page 69: Vga I/O

    Schematic Diagrams VGA I/O U13M GM107-750-A2 GPU_PEX_RST# *0_04 BGA_0908_P080_P085_P100_290X290 COMMON *0_04 8/17 IFPEF 3V3_AON ALL PINS NC FOR GF117 *2SK3018S3 GPIO9_THERM_ALERT GPIO9_THERM_ALERT_EC DVI-DL DVI-SL/HDMI *0_04 GPU_PEX_RST# *0_04 IFPE_AUX I2CY_SDA I2CY_SDA I2CY_SCL I2CY_SCL IFPE_AUX *0_04 3V3_AON IFPEF_PLLVDD IFPE_L3 *2SK3018S3 IFPEF_RSET IFPE_L3 OVERT dGPU_GPIO8_OVERT 3V3_AON...

  • Page 70: Vga Nvvdd Decoupling

    Schematic Diagrams VGA NVVDD Decoupling U13F U13G U13H U13I U13K U13J GM107-750-A2 GM107-750-A2 GM107-750-A2 GM107-750-A2 GM107-750-A2 GM107-750-A2 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 BGA_0908_P080_P085_P100_290X290 COMMON COMMON COMMON COMMON COMMON COMMON NVVDD 15/17 GND_1/2 13/17 NVVDD 9/17 XVDD 6/17 IFPC 5/17 IFPAB 16/17 GND_2/2 AM25 ALL PINS NC FOR GF117...

  • Page 71: Pch 1/8

    Schematic Diagrams PCH 1/8 BOOT HALT JTAG ODT ENABLE:LOW DISABLE:LOW (INTERNAL WEAK PD) (INTERNAL WEAK PU) 3.3VA 3.3VA R561 R559 *20K_04 *20K_04 SPI_SI_R SPI_SO_R U30A SPT-H_PCH R529 R532 R524 *0_04 BD17 BB27 PLT_RST# 33,35 LAN_W AKEUP# GPP_A11/PME# GPP_B13/PLTRST# PLT_RST# *4.7K_04 *4.7K_04 AG15 RSVD...
  • Page 72 Schematic Diagrams PCH 2/8 DFX TEST MODE XTAL INPUT IS SINGLE ENDED SPT-H_PCH IF SAMPLED LOW ELSE DIFFERENTIAL U30B USB_OC3# DMI_MT_IR_0_DN DMI_RXN0 USB2N_1 USB_PN1 USB3 PORT1, RIGHT1, CHARGER DMI_MT_IR_0_DP DMI_RXP0 USB2P_1 USB_PP1 USB_PN2 DMI_IT_MR_0_DN DMI_TXN0 USB2N_2 R445 NGFF 3G DMI_IT_MR_0_DP USB_PP2 DMI_TXP0 USB2P_2...

  • Page 73: Pch 3/8

    Schematic Diagrams PCH 3/8 U30C SPT-H_PCH SATA HDD PORT2 PCIE_RXN9_SATA0A_SSD CL_CLK1 CL_CLK PCIE9_RXN/SATA0A_RXN PCIE_RXP9_SATA0A_SSD J_HDD1 CL_DATA1 CL_DATA PCIE9_RXP/SATA0A_RXP CLINK C657 0.22u_10V_X5R_04 PCIE_TXN9_SATA0A_SSD 51824-0227A-001 CL_RST#1 CL_RST# PCIE9_TXN/SATA0A_TXN C658 0.22u_10V_X5R_04 PCIE_TXP9_SATA0A_SSD PCB Footprint = 50887-0220A-XXX PCIE9_TXP/SATA0A_TXP GPP_G8/FAN_PWM_0 PCIE_RXN10_SSD SATATXP2 C787 0.01u_50V_X7R_04 SATA_TXP2 GPP_G9/FAN_PWM_1 PCIE10_RXN/SATA1A_RXN PCIE_RXP10_SSD...
  • Page 74 Schematic Diagrams PCH 4/8 Flash Descriptor Security Overide Low = Disabled-(Default) U30D SPT-H_PCH High = Enabled R247 PJ18 R236 BB17 ISH_GP_6_R HDA_BITCLK HDA_BCLK GPP_A12/BMBUSY#/ISH_GP6/SX_EXIT_HOLDOFF# *1K_04 *CV-40mil 1K_04 AW22 PM_CLKRUN# HDA_RST# HDA_RST# GPP_A8/CLKRUN# 3.3V ME_W E HDA_SDIN0 HDA_SDI0 AR15 LAN_DISABLE_N HDA_SDI1 GPD11/LANPHYPC RB751S-40H HDA_SDOUT...

  • Page 75: Pch 5/8

    Schematic Diagrams PCH 5/8 U30E SPT-H_PCH R201 3.3VS 100K_04 HDMI_CTRLCLK HDMI_CTRLCLK GPP_I7/DDPC_CTRLCLK HDMI_CTRLDATA 2.2K_8P4R_04 HDMI_CTRLDATA GPP_I0/DDPB_HPD0 GPP_I8/DDPC_CTRLDATA HDMI_CTRLCLK HDMI_HPD GPP_I1/DDPC_HPD1 GPP_I5/DDPB_CTRLCLK HDMI_CTRLDATA MDP_B_HPD GPP_I2/DDPD_HPD2 GPP_I6/DDPB_CTRLDATA MDP_B_CLK MDP_B_CLK VGA_HPD GPP_I3/DDPE_HPD3 GPP_I9/DDPD_CTRLCLK MDP_B_CLK USB3.0 MDP_B_DATA MDP_B_DATA MDP_B_DATA GPP_I10/DDPD_CTRLDATA DGPU_RST#_PCH R122 10K_04 GPP_F14 H_SKTOCC_N DGPU_PW R_EN RIGHT 1, Charger...
  • Page 76 Schematic Diagrams PCH 6/8 C665 12p_50V_NPO_04 FSX3M_24MHZ R431 FSX3M 1M_04 6-22-24R00-1B9 6-22-24R00-1BA C666 12p_50V_NPO_04 U30G SPT-H_PCH R426 *22_04 GCLK_24M_PCH AR17 GPP_A16/CLKOUT_48 PCH_XDP_CLK_DN CLKOUT_ITPXDP PCH_XDP_CLK_DP CPU_24MHZ_R_DP CLKOUT_CPUNSSC_P CLKOUT_ITPXDP_P R506 *0_04 GCLK_32K CPU_24MHZ_R_DN CLKOUT_CPUNSSC PCH_CPU_PCIBCLK_R_DN CLKOUT_CPUPCIBCLK PCH_CPU_BCLK_R_DP CLKOUT_CPUBCLK_P CLKOUT_CPUPCIBCLK_P PCH_CPU_PCIBCLK_R_DP C742 12p_50V_NPO_04 PCH_CPU_BCLK_R_DN CLKOUT_CPUBCLK CLKOUT_PCIE_N0...
  • Page 77 Schematic Diagrams PCH 7/8 R168 VDD1.0 *20mil_short_04 R229 VDD3 *20mil_short_04 R223 3.3VA *20mil_short_04 R214 3.3VA *20mil_short_04 C434 *0.1u_10V_X7R_04 CLOSE TO PCH (1-3 mm) R175 3.3VA *20mil_short_04 U30H SPT-H_PCH C409 DEFAULT SHORT +VCCPRIM_1P0 2.899A AA23 *0.1u_10V_X7R_04 VDD1.0 VCCPRIM_1P0 AA26 AL22 0.0908A +VCCFHV_2P8 CLOSE TO PCH VCCPRIM_1P0...
  • Page 78 Schematic Diagrams PCH 8/8 SPT-H_PCH SPT-H_PCH SPT-H_PCH U30I U30L U30J BOOT BIOS STARP (BIT BBS) DFX TEST MODE QUALIFIER FOR OTHER DFX STRAP WHEN SAMPLED LOW HIGH: LPC (WEAK INTERNAL PU) AC18 AB11 LOW: SPI AR22 R180 *1K_04 (INTERNAL WEAK PD) RSVD AN10 AB14...
  • Page 79 Schematic Diagrams USB 3.0 USB3.0 PORT1 USB3.0 PORT3 (MB RIGHT1) (MB RIGHT2) USBVCC_CH USBVCC3.0_3 100mils 100mils VDD5 VOUT VOUT C402 C352 C349 C335 10u_6.3V_X5R_06 *0.1u_16V_Y5V_04 10u_6.3V_X5R_06 *0.1u_16V_Y5V_04 USB_DD_ON# uP7549UMA5-20 uP7549UMA5-20 30,37,38,40 DD_ON# PCB Footprint = M-SOT23-5A PCB Footprint = M-SOT23-5A C356 22u_6.3V_X5R_08 C343 22u_6.3V_X5R_08 USB3.0 Max Trace...

  • Page 80: M.2 Sata & Ssd

    Schematic Diagrams M.2 SATA & SSD 3G CARD / M.2 SATA CURRENT2A ,DON'T DROP BELOW 3.135V 3G_3.3V 80mils J_3G1 C710 220u_6.3V_6.3*6.3*4.2 C763 0.1u_16V_Y5V_04 CLK_PCIE_3G CONFIG_2 3.3V4 GND10 3.3V3 C762 0.1u_16V_Y5V_04 CLK_PCIE_3G# GND9 3.3V2 R271 *80.6_1%_04 SUS_CLK 25,32 CONFIG_1 SUSCLK(32Khz)(O) R250 *0_04 3G_RST# Reset#(O)1.8V...

  • Page 81: M.2 Wlan, Ssd

    Schematic Diagrams M.2 WLAN, SSD WLAN+BT (PCIE) 40mils J_W LAN1 W LAN_EN W LAN_3.3V 3.3V BT_EN C705 C765 C706 PJ53 *OPEN-2mm W LAN_PW R_EN GND10 3.3V3 VDD3 W LAN_3.3V W LAN_3.3V Reserved/REFCLKN1 3.3V2 0.1u_16V_Y5V_04 22u_6.3V_X5R_08 22u_6.3V_X5R_08 Reserved/REFCLKP1 UIM_Power_In/Gpio1/PEWake1# CLOSE TO J_WLAN1 GND9 UIM_Power_Out/CLKREQ1# VOUT...

  • Page 82: Kbc It8587E

    KBC IT8587E IT8587(Follow IT8991 PIN Define) VDD3 MODEL_ID RB (PL) RA (PH) Voltage KBC_AVDD MODEL_ID R263 *10K_04 N550RC HCB1005KF-121T20 R270 10K_04 VDD3 VDD3 N550RN 3.3V C448 C494 C497 C489 C471 C470 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 *0.1u_16V_Y5V_04 C485 KBC_AGND HCB1005KF-121T20 0.1u_16V_Y5V_04...

  • Page 83: Audio Codec, Alc269Vc2

    Schematic Diagrams Audio Codec, ALC269VC2 PCB Footprint ALC269 VC2-QFN48-6X6M EMI Require PVDD1_2 HCB1005KF-121T20 HCB1005KF-121T20 AUDG C481 0.1u_16V_Y5V_04 DVDD_IO C805 C806 Layout note: For 3.3V HDA Link. C462 0.1u_16V_Y5V_04 R602 *20mil_short_04 10u_6.3V_X5R_06 0.1u_16V_Y5V_04 GND and AUDG space is 3.3VS_AUD 60mils ~ 100mils C477 0.1u_16V_Y5V_04 C820...

  • Page 84: Lan Rtl8411B

    Schematic Diagrams LAN RTL8411B 2 IN 1 SOCKET LAN (RTL8411B) RSET R211 2.49K_1%_04 Switching Regulator close to PIN48 J_CARD1 CS1R-201-H-N R474 *0_04 R504 0_06 PCB Footprint = CS1R-201-H-N GCLK_25M_GLAN 20mils VDD10 SD_D2/MS_CLK_R 20mils SD_DATA2 R210 *1K_04 XTAL2 REGOUT VDD10 SD_D3/MS_D3_R SD_DATA3 R492 *10K_04...

  • Page 85: Fan, Kb, Led Tpm, Ccd

    Schematic Diagrams Fan, KB, LED TPM, CCD CPU FAN CONTROL SLB9665TT 26,33 LPC_AD0 LAD0 VDD1 3.3VS 26,33 LPC_AD1 LAD1 VDD2 VOUT 26,33 LPC_AD2 LAD2 VDD3 C689 C694 VSET 26,33 LPC_AD3 LAD3 VDD4 1u_6.3V_X5R_04 *4.7u_6.3V_X5R_06 NCT3940S-A PCLK_TPM C460 C465 C461 C468 PCLK_TPM LCLK CPU_FAN...

  • Page 86: Connector

    Schematic Diagrams Connector LED BOARD TOUCH PAD CONN AUDIO BOARD CONN (USB3.0x1,CRT,SIM/PHONE/MIC/SPDIF JACK) J_LED1 TP SMBUS address : 0x2C FP225H-012S10M J_AUD1 PCB Footprint = fp225-012g TP_VCC FP201H-040S10M PCB Footprint = FP201-040X1-0M LED_ACIN R287 0_04 6-20-94K20-140 3.3VS LED_PW R LED_BAT_CHG R290 *0_04 LED_BAT_FULL LED_NUM#...

  • Page 87: 5V, 5Vs, 3.3V, 3.3Vs, 3.3Va

    Schematic Diagrams 5V, 5VS, 3.3V, 3.3VS, 3.3VA VIN1 VIN1 C668 C378 C389 C671 C670 C673 C675 R157 10K_04 R147 100K_04 USB_CHARGE_EN 33,39 VIN1 R443 1_1%_06 R148 *100K_04 DD_ON DD_ON_LATCH R142 10K_04 R141 10K_04 M_BTN# VDD3 M_BTN# PWR_SW# USB_CHARGE_EN R146 *1K_04 R140 1K_04 INSTANT-ON...

  • Page 88: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF PR65 PR67 *0_04 *20mil_short_04 PC193 1u_6.3V_X5R_04 PC184 PR227 PR248 EN_3V EN_5V 1000p_50V_X7R_04 130K_1%_04 130K_1%_04 PC181 PC30 PC185 PC206 PC26 PC27 PC31 PC170 PU13 VREG3 1000p_50V_X7R_04 PC183 1u_6.3V_X5R_04 PR244 *10K_04 LDO3 SYS5V VDD3 VDD5 PC186 PC205 0.1u_10V_X7R_04 BOOT2 BOOT1...

  • Page 89: Ddr 1.35V, 0.65Vs

    Schematic Diagrams DDR 1.35V, 0.65VS DDR3L 1.35V/0.65VS PQ26 PC158 PC226 PC155 MDU1516 ULTRASO-8 PU11 RB0540S2 UP6163 VTT_MEM(0.65VS) VDDQ_R PC168 0.1u_10V_X7R_04 VLDOIN VBST VDDQ(1.35V) PC164 10u_6.3V_X5R_06 DEFAULT SHORT EMR2 0_06 VTT_MEM DRVH VDDQ_R PJ52 *OPEN-2mm BCIHP0730-1R0M DEFAULT SHORT PC167 PC166 PC165 PR210 VDDQ VTTGND...

  • Page 90: Vdd1.0, Vccio

    Schematic Diagrams VDD1.0, VCCIO PR202 820K_1%_06 PJ10 *CV-40mil PC169 PC152 PC151 PC150 PR56 10K_04 PU10 VDD3 PR203 PC156 0_06 0.1u_10V_X7R_04 VDD1.0_EN 30,33,38,39 DD_ON EN_PSV *OPEN-1mm VDD5_PW R PJ11 DEFAULT SHORT VTT_SELECT VTT VR Output Voltages VDD1.0 25,33,38,42 1.1 V SLP_SUS# high (V1.1S_VTT) 1.05 V *OPEN-1mm...

  • Page 91: Vccstg, Vccsfr_Oc

    Schematic Diagrams VCCSTG, VCCSFR_OC VCCSFR_OC 1.0DX_VCCSTG DEFAULT SHORT DEFAULT SHORT 1.0DX_VCCSTG VCCSFR_OC VDD1.0 VDDQ *OPEN-1mm *OPEN-1mm PJ35 PJ37 VOUT VOUT 1.35VS PC100 PC99 PC94 PC110 PC112 PC98 VOUT VOUT PR148 PR151 VOUT VOUT *200_04 *200_04 VOUT VOUT M5938BRD1U M5938BRD1U PR145 PR152 10K_04 0_04...

  • Page 92: Gpu Power 1/2

    Schematic Diagrams GPU Power 1/2 3V3_AON 3V3_RUN PEX_VDD 3.3V 3.3V PEX_VDD EM5209 VDDQ C550 PCB Footprint = TDFN14-2X3MM-A C553 0.1u_16V_Y5V_04 0.1u_16V_Y5V_04 C635 C661 C611 DEFAULT SHORT DEFAULT SHORT DEFAULT SHORT 3V3_AON OUT1 OUT2 3V3_RUN OUT1 OUT2 PJ31 *OPEN-2mm C543 C573 PJ32 *OPEN-2mm PJ44...
  • Page 93 Schematic Diagrams GPU Power 2/2 Cold boot/Optimus: 3V3_AON 3V3_RUN NVVDD PEX_VDD FBVDDQ NVVDD PHASE 1 and 2 The ramp time for any rail must be more than 40us and is recommended to be less than 2ms 3V3_RUN GC6 2.0 Exit: 3V3_RUN NVVDD, PEX_VDD PJ45 PR196 *CV-40mil...

  • Page 94: Ac_In, Charger

    Schematic Diagrams AC_In, Charger SMART CHARGER PR245 PC203 470K_04 0.1u_50V_Y5V_06 PR75 300K_1%_04 V_BAT BAT_VOLT 33 PC219 PC218 EMB20P03V PR235 PR73 PR74 PC40 MTE1K0P15KN3 0.1u_50V_Y5V_06 1500p_50V_04 20K_04 100K_04 60.4K_1%_04 0.1u_16V_Y5V_04 *RB0540S2 PQ10 EMB20P03V EMB20P03V VDD3 HCB2012KF-800T80 2SK3018S3 PRS1 PRS2 *0.01_1%_32 *0.01_1%_32 J_DC_JACK1 EMB20P03V HCB2012KF-800T80...

  • Page 95: Vcore, Vccsa

    Schematic Diagrams VCore, VCCSA ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( VCORE_PROG 3.3VS 3.3VS CONFIGURATION PR130 PR120 PR105 PR12 100K_04 47K_04 2.2_06 1K_1%_04 1.0V_VCCST 13K_1%_04 PC63 PC69 PC62 PC60 PC66 PJ29 PR116 PR108 PR112 *CV-40mil *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 4.7u_6.3V_X5R_06 NCP81203PMNTXG 0.01u_50V_X7R_04 1u_6.3V_X5R_04 6X6 52PIN QFN...

  • Page 96: Vcore Output Stage

    Schematic Diagrams VCore Output Stage VCORE & VCCSA OUTPUT STAGE VCCVIN DEFAULT SHORT PC43 PC85 PC65 *OPEN-5mm PR79 2.2_06 2.2_06 0.22u_16V_Y5V_04 NCP81151MNTBG PR77 2.2_1%_06 INS127457098 INS127462925 MLP08 MLP08 PR81 10K_06 PW M11 COMMON COMMON CMME063T-R15MS0R907 46,47 DRVON1 VCORE PCB Footprint = BCIHP0735A 0.55V~1.52V PR97 PC42...

  • Page 97: Vccgt

    Schematic Diagrams VCCGT ,QWHO 6.</$.( ,093 32:(5 &.7   3+$6( 3.3VS 3.3VS PR37 PR185 PR44 PR186 100K_04 47K_04 2.2_06 1K_1%_04 1.0V_VCCST VDD_PU8 VRMP_PU8 PC130 PC21 PC134 PC131 PR48 PR46 PR47 PC22 *CV-40mil *0.1u_10V_X7R_04 *0.1u_10V_X7R_04 4.7u_6.3V_X5R_06 NCP81203PMNTXG 0.01u_50V_X7R_04 6X6 52PIN QFN *100_04 *45.3_1%_04 *45.3_1%_04...

  • Page 98: Vccgt Output Stage

    Schematic Diagrams VCCGT Output Stage VGTVIN DEFAULT SHORT 2.5A PC102 PC101 PC96 PC104 SW PU12 *OPEN-3mm PR159 PR153 PC20 2.2_06 2.2_04 0.22u_16V_Y5V_04 NCP81151MNTBG BSTPU12 HG_PU12 PR149 1_1%_06 PQ16 SW _PQ43 PR146 10K_06 MDU5693 0.55V~1.5V PW M12 DUAL-PDFN56-5X6mm CMME063T-R15MS0R907 Sheet 49 of 72 DRVON2 VCCGT PCB Footprint = BCIHP0735A...

  • Page 99: Click Board

    Schematic Diagrams Click Board RIGHT KEY T_TP_BTN_R TSW2 TO T/P board T4BJB10-Q-T/R PCB Footprint = T4BJB16-Q TJ_TP1 FP226H-004S10M 0.1u_16V_Y5V_04 PCB Footprint = JXT_FP226H-004XXAM_R 6-53-35100-B40 T_TP_BTN_L T_TP_BTN_R TGND TGND TGND LIFT KEY Sheet 50 of 72 T_TP_BTN_L Click Board TSW1 T4BJB10-Q-T/R PCB Footprint = T4BJB16-Q 0.1u_16V_Y5V_04 6-53-35100-B40...

  • Page 100: Led Board

    Schematic Diagrams LED Board LJ_LED1 AC IN/POWER ON LED BAT CHARGE/FULL LED FP225H-012S10M PCB Footprint = fp225-012g LLED_ACIN LLED_PWR LLED_BAT_FULL LLED_PWR LLED_ACIN LLED_BAT_CHG LLED_BAT_CHG LLED_BAT_FULL LLED_NUM# LLED_CAP# LLED_SCROLL# 2K_1%_04 2K_1%_04 LLED_AIRPLAN# 2K_1%_04 2K_1%_04 LLED_SATA# LED_GND Orange LED White LED Orange LED White LED L_3.3VS Vf=1.8V...

  • Page 101: Power Board

    Schematic Diagrams Power Board POWER SWITCH LED LID SWITCH IC PSU1, PSU2 B5VS B5VS BVDD3 20mils 20mils 100K_04 AH9249NTR-G1 ( 0603 SIZE ) 1K_1%_04 1K_1%_04 BLID_SW# 20mils 20mils White LED White LED *1u_16V_Y5V_06 0.1u_16V_Y5V_04 *100p_50V_NPO_04 FSL-3810060W-FASNL1930LT FSL-3810060W-FASNL1930LT 6-52-57001-024-1 6-52-57001-024-1 BGND BGND BGND BGND...

  • Page 102: Audio Board 1/2

    Schematic Diagrams Audio Board 1/2 USB2.0 A_3.3V A_3.3V *0_04 AR39 *4.7K_04 AR47 *4.7K_04 AC12 AC11 AC13 AR49 *4.7K_04 AR11 *2K_1%_04 AR50 *4.7K_04 AR12 *0_04 *0.01u_50V_X7R_04 *0.1u_16V_Y5V_04 *1u_6.3V_X5R_04 AGND AGND AGND To USB3.0 CONN. To AUDIO BOARD CONN. A_5V AUSBVCC3.0_5 AI2C_SDA_P5 AI2C_SCK_P5 100mils AUSB3_TX5_N...
  • Page 103 Schematic Diagrams Audio Board 2/2 AUDIO BOARD ALANE1_N AC21 0.1u_10V_X7R_04 Mode Configure Table(Power On Latch) AVGA_LANE1_N ALANE1_P AC22 0.1u_10V_X7R_04 AVGA_LANE1_P ALANE0_N AC23 0.1u_10V_X7R_04 AVGA_LANE0_N ALANE0_P AC24 0.1u_10V_X7R_04 RTD2168 Supports three operation mode for system design. RTD2168-CG (DP to CRT) AVGA_LANE0_P ARRX AR53 12K_1%_04...

  • Page 104: Power Sequence

    Schematic Diagrams Power Sequence N550RC POWER ON SEQUENCE VDD3 rise : 1.67ms DD_ON 3.3V 858.8us rise : 515.15us VDD5 2.516ms rise : 1.54ms 2.578ms rise : 670.2us SLP_SUS# 23.2us VDD1.0 1.35ms rise : 753.97us 3.3VA 860.1us rise : 499.26us RSMRST# 41.66ms PWR_BTN# 20.815ms...

  • Page 105: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 106: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “EFI Shell”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by EFI Shell.
