Hynix Semiconductor GMS82512 Series User Manual

8-bit single-chip microcontrollers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
8-BIT SINGLE-CHIP MICROCONTROLLERS
GMS81508B
GMS81516B
GMS81524B
User's Manual (Ver. 2.0)
http://www.xinpian.net
HYNIX SEMICONDUCTOR
提供单片机解密、IC解密、芯片解密业务 010-62245566
GMS82512
GMS82516
GMS81524
13810019655

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMS82512 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hynix Semiconductor GMS82512 Series

Summary of Contents for Hynix Semiconductor GMS82512 Series

  • Page 1 HYNIX SEMICONDUCTOR 8-BIT SINGLE-CHIP MICROCONTROLLERS GMS81508B GMS82512 GMS81516B GMS82516 GMS81524B GMS81524 User’s Manual (Ver. 2.0) http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...
  • Page 2 Hynix Semiconductor reserves the right to make changes to any information here in at any time without notice. The information, diagrams and other data in this manual are correct and reliable; however, Hynix Semiconductor is in no way responsible for any violations of patents or other rights of the third party generated by the use of this manual.

  • Page 3: Table Of Contents

    GMS81508B/16B/24B, GMS82512/16/24 Table of Contents 1. OVERVIEW ...........1 The Serial I/O operation by SRDY pin .... 53 The method of Serial I/O ......... 54 Description ............1 The Method to Test Correct Transmission ..54 Features .............1 14. PWM OUTPUT .........55 Development Tools ..........2 15.

  • Page 4: Overview

    GMS81508B/16B/24B, GMS82512/16/24 GMS81508B/16B/24B GMS82512/16/24 CMOS SINGLE-CHIP 8-BIT MICROCONTROLLER WITH A/D CONVERTER 1. OVERVIEW 1.1 Description The GMS81508B/16B/24B are advanced CMOS 8-bit microcontrollers with 8K/16K/24K bytes of ROM and 64pin package. And the GMS82512/16/24 are the same except for 12K/16K/24K bytes of ROM and 42pin package. The GMS825xx is a cut-down product of GMS815xxB microcontroller, that is, the function and package are reduced.

  • Page 5: Development Tools

    For more detail, Refer to “22. OTP PROGRAMMING” on page 76. Macro assembler operates under the MS-Windows 95/98 Please contact sales part of Hynix Semiconductor. 1.4 Ordering Information Device name ROM Size...

  • Page 6: Block Diagram

    GMS81508B/16B/24B, GMS82512/16/24 2. BLOCK DIAGRAM 2.1 GMS81508B/GMS81516B/GMS81524B(64 pin package) ADC Power Supply R00~R07 R10~R17 R20~R27 R30~R37 Stack Pointer Data Memory (448 bytes) Program Interrupt Controller Memory Data Table 8-bit Basic System controller Interval Timer System Clock Controller 8-bit 8-bit serial 8-bit 8-bit PWM Timing generator...
  • Page 7 GMS81508B/16B/24B, GMS82512/16/24 2.2 GMS82512/GMS82516/GMS82524(42 pin package) ADC Power Supply R00~R07 R20~R27 R30~R37 Stack Pointer Data Memory (448 bytes) Program Memory Interrupt Controller Data Table 8-bit Basic System controller Interval Timer System Clock Controller 8-bit 8-bit Timer/ Timing generator Watchdog Counter Timer Clock Generator Buzzer...

  • Page 8: Pin Assignment

    GMS81508B/16B/24B, GMS82512/16/24 3. PIN ASSIGNMENT 3.1 GMS81508B/GMS81516B/GMS81524B(64 pin package) 64SDIP TEST (Top View) PWM1 PWM0 WDTO SRDY SCLK SOUT INT3 INT2 INT1 INT0 RESET XOUT 64MQFP (Top View) GMS81508B/16B/24B XOUT TEST RESET INT0 INT1 INT2 MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务...
  • Page 9 GMS81508B/16B/24B, GMS82512/16/24 64LQFP (Top View) GMS81508B/16B/24B XOUT TEST RESET INT0 INT1 INT2 INT3 MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...
  • Page 10 GMS81508B/16B/24B, GMS82512/16/24 3.2 GMS82512/GMS82516/GMS82524(42 pin package) 42SDIP (Top View) TEST WDTO INT3 INT2 INT1 INT0 RESET XOUT 44MQFP (Top View) GMS82512/16/24 TEST XOUT RESET N .C . : N o C onnection MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...

  • Page 11: Package Diagram

    GMS81508B/16B/24B, GMS82512/16/24 4. PACKAGE DIAGRAM 4.1 GMS81508B/GMS81516B/GMS81524B(64 pin package) 64SDIP UNIT: INCH 2.280 2.260 0.750 Typ. 0.680 0.660 0.070 Typ. 0.050 0.022 0-15° 0.016 0.030 64MQFP 24.15 UNIT: MM 23.65 20.10 19.90 0-7° SEE DETAIL “A” 1.03 0.73 3.18 max. 1.95 1.00 Typ.
  • Page 12 GMS81508B/16B/24B, GMS82512/16/24 64LQFP 12.00 Typ. 10.00 Typ. UNIT: MM 0-7° SEE DETAIL “A” 0.75 0.45 1.60 max. 1.00 0.50 Typ. 0.38 0.22 DETAIL “A” MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...
  • Page 13 GMS81508B/16B/24B, GMS82512/16/24 4.2 GMS82512/GMS82516/GMS82524(42 pin package) 42SDIP UNIT: INCH 1.465 1.455 0.600 Typ. 0.545 0.535 0.070 Typ. 0.022 0.045 0-15° 0.016 0.035 44MQFP 13.45 12.95 10.10 9.90 UNIT: MM 0-7° SEE DETAIL “A” 1.03 0.73 2.35 max. 1.60 Typ. 0.80 Typ. 0.45 0.30 DETAIL “A”...

  • Page 14: Pin Function

    GMS81508B/16B/24B, GMS82512/16/24 5. PIN FUNCTION R50~R53, R56, R57 are NOT served on GMS825xx. : Supply voltage. : Circuit ground. In addition, R5 serves the functions of the various follow- ing special features. TEST: Used for Test Mode. For normal operation, it should be connected to V Port pin Alternate function...
  • Page 15 GMS81508B/16B/24B, GMS82512/16/24 Function PIN NAME In/Out Basic Alternate Supply voltage Circuit ground Controls test mode of the chip, TEST For normal operation, it should be connected at V RESET Reset signal input Oscillation input Oscillation output R00~R07 8-bit general I/O ports 8-bit general I/O ports R10~R17 R20~R27...

  • Page 16: Port Structures

    GMS81508B/16B/24B, GMS82512/16/24 6. PORT STRUCTURES R00~R07, R10~R17, R20~R27, R30~37 R52/SCLK Selection Data Reg. SCK Output M U X Dir. Reg. Data Reg. Direction M UX Reg. M U X exck M U X R40/INT0, R41/INT1, R42/INT2, R43/INT3, R44/ EC0, R45/EC2, R50/SIN SCK Input PMR Selection Data Reg.
  • Page 17 GMS81508B/16B/24B, GMS82512/16/24 R60/AN0 ~ R63/AN3 RESET RESET Data bus To A/D converter R64/AN7 ~ R67/AN7 TEST OTP version: disconnected Mask version: connected Data Reg. TEST Dir. Reg. M U X To A/D converter XOUT Stop MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务...

  • Page 18: Electrical Characteristics

    GMS81508B/16B/24B, GMS82512/16/24 7. ELECTRICAL CHARACTERISTICS 7.1 Absolute Maximum Ratings Supply voltage ..........-0.3 to +7.0 V Maximum current (ΣI ) ........100 mA Storage Temperature ........-40 to +125 °C Maximum current (ΣI )........50 mA Voltage on any pin with respect to Ground (V Note: Stresses above those listed under “Absolute Maxi- ..............-0.3 to V +0.3...

  • Page 19: Dc Electrical Characteristics

    GMS81508B/16B/24B, GMS82512/16/24 Specifications Max. Parameter Symbol Unit Min. Typ. =4MHz =8MHz 0.9V 1.1V Analog Power Supply Input Range 1. Data in “Typ” column is at 25°C unless otherwise stated. These parameters are for design guidance only and are not tested. 7.4 DC Electrical Characteristics =-20~85°C, V =2.7~5.5V, Ta= -20~85°C, f...

  • Page 20: Ac Characteristics

    GMS81508B/16B/24B, GMS82512/16/24 7.5 AC Characteristics =-20~+85°C, V =5V±10%, V =0V) Specifications Parameter Symbol Pins Unit Min. Typ. Max. Operating Frequency 10.0 Oscillation Stabilizing Time External Clock Pulse Width External Clock Transi- RCP, tion Time Interrupt Pulse Width INT0, INT1, INT2, INT3 RESET Input Width RESET Event Counter Input...

  • Page 21: Serial Interface Timing Characteristics

    GMS81508B/16B/24B, GMS82512/16/24 7.6 Serial Interface Timing Characteristics =-20~+85°C, V =5V±10%, V =0V, f =8MHz) Specifications Parameter Symbol Pins Unit Min. Typ. Max. +200 Serial Input Clock Pulse SCLK SCYC Serial Input Clock Pulse Width SCLK SCKW Serial Input Clock Pulse Transition FSCK SCLK Time...

  • Page 22: Typical Characteristic Curves

    GMS81508B/16B/24B, GMS82512/16/24 7.7 Typical Characteristic Curves This graphs and tables provided in this section are for de- The data presented in this section is a statistical summary sign guidance only and are not tested or guaranteed. of data collected on units from different lots over a period of time.
  • Page 23 GMS81508B/16B/24B, GMS82512/16/24 −V XIN, RESET, −V R4, R5, R6 pins R0, R1, R2, R3 pins =8MHz =8MHz Ta=25°C Ta=25°C −V −V Operating Area STOP Normal Operation Stop Mode (MHz) Ta= -20~85°C Ta=25°C (mA) (µA) 85°C 25°C = 8MHz -20°C 4MHz MAY.

  • Page 24: Memory Organization

    GMS81508B/16B/24B, GMS82512/16/24 8. MEMORY ORGANIZATION The GMS81508B/16B/24B and GMS82512/16/24 have to. It can be up to 24K bytes of Program memory. Data separate address spaces for Program memory and Data memory can be read and written to up to 448 bytes includ- Memory.
  • Page 25 GMS81508B/16B/24B, GMS82512/16/24 [Zero flag Z] or data transfer is “0” and is cleared by any other result. This flag is set when the result of an arithmetic operation V G B H RESET VALUE: 00 CARRY FLAG RECEIVES NEGATIVE FLAG CARRY OUT OVERFLOW FLAG ZERO FLAG...
  • Page 26 GMS81508B/16B/24B, GMS82512/16/24 At execution of At acceptance At execution At execution a CALL/TCALL/PCALL of interrupt of RET instruction of RET instruction Push 01FE 01FE 01FE 01FE down Push 01FD 01FD 01FD 01FD down 01FC 01FC 01FC 01FC 01FB 01FB 01FB 01FB SP before 01FE...

  • Page 27: Program Memory

    GMS81508B/16B/24B, GMS82512/16/24 8.2 Program Memory A 16-bit program counter is capable of addressing up to it is more useful to save program byte length. 64K bytes, but this device has 24K bytes program memory Table Call (TCALL) causes the CPU to jump to each space only physically implemented.
  • Page 28 GMS81508B/16B/24B, GMS82512/16/24 Address Program Memory PCALL Area Memory Address 0FFC0 0FF00 TCALL 15 TCALL 14 TCALL 13 TCALL 12 TCALL 11 TCALL 10 TCALL 9 TCALL 8 PCALL Area (256 Bytes) TCALL 7 TCALL 6 TCALL 5 TCALL 4 TCALL 3 TCALL 2 TCALL 1 TCALL 0 / BRK *...
  • Page 29 GMS81508B/16B/24B, GMS82512/16/24 Example: The usage software example of Vector address for GMS81524B. 0FFE0H NOT_USED NOT_USED ; Serial Interface BIT_TIMER ; Basic Interval Timer WD_TIMER ; Watchdog Timer ; ADC TIMER3 ; Timer-3 TIMER2 ; Timer-2 TIMER1 ; Timer-1 TIMER0 ; Timer-0 INT3 ;...

  • Page 30: Data Memory

    GMS81508B/16B/24B, GMS82512/16/24 8.3 Data Memory Figure 8-8 shows the internal Data Memory space availa- Note that unoccupied addresses may not be implemented ble. Data Memory is divided into four groups, a user RAM, on the chip. Read accesses to these addresses will in gen- control registers, Stack, and LCD memory.
  • Page 31 GMS81508B/16B/24B, GMS82512/16/24 Initial Value Address Register Name Symbol Page 7 6 5 4 3 2 1 0 00C0 R0 port data register Undefined page 34 00C1 R0 port I/O direction register R0DD 0 0 0 0 0 0 0 0 page 34 R1 port data register Undefined...
  • Page 32 GMS81508B/16B/24B, GMS82512/16/24 Initial Value Address Register Name Symbol Page 7 6 5 4 3 2 1 0 PWM0 duty register PWMR0 Undefined page 55 00F0 PWM1 duty register PWMR1 Undefined page 55 00F1 PWM control register PWMCR 0 0 0 0 0 0 0 0 page 55 00F2 00F4...

  • Page 33: Addressing Mode

    GMS81508B/16B/24B, GMS82512/16/24 8.4 Addressing Mode The GMS800 series MCU uses six addressing modes; Example: G=1 • Register addressing E45535 35H,#55H • Immediate addressing • Direct page addressing • Absolute addressing 0135H data data ¨ 55H • Indexed addressing • Register-indirect addressing þ...
  • Page 34 GMS81508B/16B/24B, GMS82512/16/24 (4) Absolute Addressing → → → → !abs ADC, AND, CMP, EOR, LDA, OR, SBC, STA, XMA Absolute addressing sets corresponding memory data to Example; X=15 , G=1 Data, i.e. second byte (Operand I) of command becomes ;ACC←RAM[X]. lower level address and third byte (Operand II) becomes upper level address.
  • Page 35 GMS81508B/16B/24B, GMS82512/16/24 Example; G=0 C645 45H+X 3F35 [35H] data à À À → data þ 0E550H þ 0E30AH NEXT jump to 0E551H address 0E30AH 45H+0F5H=13AH 0FA00H Y indexed direct page (8 bit offset) → → → → dp+Y This address value is the second byte (Operand) of com- X indexed indirect →...
  • Page 36 GMS81508B/16B/24B, GMS82512/16/24 Example; G=0 1725 [25H]+Y 1F25E0 [!0C025H] PROGRAM MEMORY À þ 0E025H 0E005H + Y(10) 0E015H data = 0E015H 0E026H À jump to address 0E30AH 0FA00H 0E725H NEXT þ Ã → A + data + C 0FA00H Absolute indirect → → → → [!abs] The program jumps to address specified by 16-bit absolute address.

  • Page 37: I/O Ports

    GMS81508B/16B/24B, GMS82512/16/24 9. I/O PORTS The GMS815xxB and GMS825xx have four input ports R1 and R1DD register: R1 is an 8-bit CMOS bidirection- and fifty two input/output ports(R00~R67) and the al I/O port (address 0C2 ). Each I/O pin can independently GMS825xx has thirty five input/output ports.
  • Page 38 GMS81508B/16B/24B, GMS82512/16/24 R3 and R3DD register: R3 is an 8-bit CMOS bidirection- al I/O port (address 0C6 ). Each I/O pin can independently Regardless of the direction register R4DD, PMR4 is select- used as an input or an output through the R3DD register ed to use as alternate functions, port pin can be used as a (address 0C7 corresponding alternate features.
  • Page 39 GMS81508B/16B/24B, GMS82512/16/24 R5 and R5DD register: R5 is an 8-bit CMOS bidirection- al I/O port (address 0CA ). Each I/O pin can independent- R6 and R6DD register: R6 is an 8-bit CMOS bidirection- ly used as an input or an output through the R5DD register al I/O port (address 0CC ).

  • Page 40: Basic Interval Timer

    GMS81508B/16B/24B, GMS82512/16/24 10. BASIC INTERVAL TIMER The GMS815xxB and GMS825xx have one 8-bit Basic In- generated. The Basic Interval Timer is controlled by the terval Timer that is free-run and can not stop. Block dia- clock control register (CKCTLR) shown in Figure 10-2. gram is shown in Figure 10-1.
  • Page 41 GMS81508B/16B/24B, GMS82512/16/24 ADDRESS: 0D3 CKCTLR BTCL BTCL BTS2 BTS1 BTS0 WDTON ENPCK INITIAL VALUE: --01 0111 Basic Interval Timer source clock select ÷ 000: f ÷ 001: f ÷ 010: f ÷ 011: f ÷ 100: f ÷ 101: f ÷...

  • Page 42: Timer/Event Counter

    GMS81508B/16B/24B, GMS82512/16/24 11. TIMER/EVENT COUNTER The GMS815xxB and GMS825xx have four Timer/ (EC2 are NOT served on GMS825xx.) Counter registers. Each module can generate an interrupt In addition the “capture” function, the register is incre- to indicate that an event has occurred (i.e. timer match). mented in response external or internal clock sources same Timer 0 and Timer 1 are can be used either two 8-bit Tim- with timer or counter function.
  • Page 43 GMS81508B/16B/24B, GMS82512/16/24 A D D R E S S : 0E 2 C A P 0 T1S T T1S L1 T1S L0 B TC L T0S T T0C N T0S L1 T0S L0 IN ITIA L V A LU E : 00 Bit Name Bit Position Description...

  • Page 44: 8-Bit Timer / Counter Mode

    GMS81508B/16B/24B, GMS82512/16/24 11.1 8-bit Timer / Counter Mode The GMS815xxB and GMS825xx have four 8-bit Timer/ T3SL1, T3SL0 of TM2 should not set to zero. These timers Counters, Timer 0, Timer 1, Timer 2, Timer 3. The Timer have each 8-bit count register and data register. The count 0, Timer 1 are shown in Figure .
  • Page 45 GMS81508B/16B/24B, GMS82512/16/24 In counter function, the counter is increased every 1-to-0 Note: The contents of Timer data register TDRx should be (falling edge) transition of EC0 or EC2 pin. In order to use initialized 1 , not 0 , because it is undefined after re- counter function, the bit 4, bit 5 of the Port mode register set.
  • Page 46 GMS81508B/16B/24B, GMS82512/16/24 8-bit Timer Mode Maximum Time Resolution Value of Clock Setting In the timer mode, the internal clock is used for counting (At f =8 M H z) TM[1:0] Source (At f =8 M H z) up. Thus, you can think of it as counting internal clock in- ×...
  • Page 47 GMS81508B/16B/24B, GMS82512/16/24 8-bit Event Counter Mode In order to use event counter function, the bit 4, 5 of the Port Mode Register PMR4(address 0D0 ) is required to be In this mode, counting up is started by an external trigger. set to “1”.

  • Page 48: 16-Bit Timer / Counter Mode

    GMS81508B/16B/24B, GMS82512/16/24 11.2 16-bit Timer / Counter Mode The Timer register is being run with all 16 bits. A 16-bit Even if the Timer 0 (including the Timer 1) is used as a 16- timer/counter register T0, T1 are incremented from 0000 bit timer, the Timer 2 and Timer 3 can still be used as either until it matches TDR0, TDR1 and then resets to 0000 two 8-bit timer or one 16-bit timer by setting the TM2.

  • Page 49: 8-Bit Capture Mode

    GMS81508B/16B/24B, GMS82512/16/24 11.3 8-bit Capture Mode The Timer 0 capture mode is set by bit CAP0 of timer causes the current value in the Timer counter register mode register TM0 (bit CAP2 of timer mode register TM2 (T0,T2), to be captured into registers CDRn (CDR0, for Timer 2) as shown in Figure 21.

  • Page 50: 16-Bit Capture Mode

    GMS81508B/16B/24B, GMS82512/16/24 11.4 16-bit Capture Mode 16-bit capture mode is the same as 8-bit capture, except that the Timer register is being run will 16 bits. ADDRESS: 0E2 CAP0 T1ST T1SL1 T1SL0 BTCL T0ST T0CN T0SL1 T0SL0 INITIAL VALUE: 00 X means don’t care T0SL[1:0] Edge Detector...
  • Page 51 GMS81508B/16B/24B, GMS82512/16/24 Example 1: TDR0,#250 TM0,#0111_1111B Timer0 = 16-bit timer mode, 0.5s at 8MHz SET1 TDR2,#40H Timer2 = 2ms 8-bit timer mode at 8MHz TDR3,#2AH Timer3 = 250us 8-bit timer mode at 8MHz TM2,#1111_1111B SET1 TDR0,#23H IEDS,#XX11_XXXXB TDR1,#0F4H PMR4,#XXXX_X1XXB TM0,#0FH SET1 INT2E TDR2,#249...

  • Page 52: Analog Digital Converter

    GMS81508B/16B/24B, GMS82512/16/24 12. ANALOG DIGITAL CONVERTER R60 ~ R63 are NOT served on GMS825xx. The analog-to-digital converter (A/D) allows conversion of an analog input signal to a corresponding 8-bit digital How to Use A/D Converter value. The A/D module has eight analog inputs, which are multiplexed into one sample and hold.
  • Page 53 GMS81508B/16B/24B, GMS82512/16/24 ADDRESS: 0E8 ADCM BTCL ADEN ADS2 ADS1 ADS0 ADST ADSF INITIAL VALUE: --00 0001 A/D status bit 0: A/D conversion is in progress 1: A/D conversion is completed A/D start bit Setting this bit starts an A/D conversion. After one cycle, bit is cleared to “0”...

  • Page 54: Serial Communication

    GMS81508B/16B/24B, GMS82512/16/24 13. SERIAL COMMUNICATION - This function is NOT served on the GMS825xx. The serial iterface is used to transmit/receive 8-bit data se- trolled by the Serial Mode Register. The contents of the Se- rially. This consists of serial I/O data register, serial I/O rial I/O data register can be written into or read out by mode register, clock selection circuit octal counter and software.
  • Page 55 GMS81508B/16B/24B, GMS82512/16/24 Serial I/O Mode Register(SIOM) controls serial I/O func- Serial I/O Data Register(SIOR) is an 8-bit shift register. tion. According to SCK1 and SCK0, the internal clock or First LSB is send or is received. external clock can be selected. ADDRESS: 0EA SIOM BTCL...

  • Page 56: Transmission/Receiving Timing

    GMS81508B/16B/24B, GMS82512/16/24 13.1 Transmission/Receiving Timing The serial transmission is started by setting SIOST(bit1 of is latched at rising edge of SCLK pin. When transmission SIOM) to “1”. After one cycle of SCK, SIOST is cleared clock is counted 8 times, serial I/O counter is cleared as automatically to “0”.

  • Page 57: The Method Of Serial I/O

    GMS81508B/16B/24B, GMS82512/16/24 13.3 The method of Serial I/O 1. Select transmission/receiving mode. Note: When external clock is used, the frequency should 2. In case of sending mode, write data to be send to SIOR. be less than 1MHz and recommended duty is 50%. If both transmission mode is selected and transmission is per- 3.

  • Page 58: Pwm Output

    GMS81508B/16B/24B, GMS82512/16/24 14. PWM OUTPUT - This function is NOT served on the GMS825xx. The GMS815xxB have two channels of built-in pulse The input clock is selected by PWM Control Register width modulation outputs. PWM outputs data are multi- (PWMCR, address F2 ) and the width of pulse is deter- plex to the R56 and R57 port.
  • Page 59 GMS81508B/16B/24B, GMS82512/16/24 ADDRESS: 0F0 RESET VALUE: Undefined PWMR0 Duty data ADDRESS: 0F1 RESET VALUE: Undefined PWMR1 Duty data Figure 14-2 PWM Duty Register ADDRESS: 0F2 PWMCR BTCL P1CK1 P1CK0 P0CK1 P0CK0 POL1 POL0 INITIAL VALUE: 0000 0000 PWM0 output polarity 0: Active low 1: Active high PWM1 output polarity...
  • Page 60 GMS81508B/16B/24B, GMS82512/16/24 active high enable PWMCR fixed fixed ÷ ÷ ÷ ÷ 8MHz 61.035Hz 8MHz 122.07Hz 16.384ms 8.192ms 5.728ms 3.264ms PWM1 PWM0 PWMR0 PWMR1 × × ------------ - ------------ - 16.384 3.264ms 8.192 5.728ms Figure 14-4 Example of Register Setting MAY.

  • Page 61: Buzzer Function

    GMS81508B/16B/24B, GMS82512/16/24 15. BUZZER FUNCTION The buzzer driver block consists of 6-bit binary counter, The bit 0 to 5 of BUR determines output frequency for buzzer register, and clock source selector. It generates buzzer driving. square-wave which has very wide range frequency (500Hz Equation of frequency calculation is shown below.
  • Page 62 GMS81508B/16B/24B, GMS82512/16/24 The 6-bit counter is cleared and starts the counting by writ- Note: BUR is undefined after reset, so it must be initialized ing signal at BUR register. It is incremental from 00 until to between 1 and 3F by software.

  • Page 63: Interrupts

    GMS81508B/16B/24B, GMS82512/16/24 16. INTERRUPTS IRQH and IRQL) except Power-on reset and software The GMS815xxB and GMS825xx interrupt circuits con- sist of Interrupt enable register (IENH, IENL), Interrupt re- BRK interrupt. Below table shows the Interrupt priority. quest flags of IRQH, IRQL, Priority circuit, and Master enable flag (“I”...
  • Page 64 GMS81508B/16B/24B, GMS82512/16/24 Internal bus line [0F6 I-flag is in PSW, it is cleared by “DI”, set by Interrupt Enable “EI” instruction. When it goes interrupt service, IENH I-flag is cleared by hardware, thus any other Register (Higher byte) IRQH interrupt are inhibited. When interrupt service is completed by “RETI”...

  • Page 65: Interrupt Sequence

    GMS81508B/16B/24B, GMS82512/16/24 16.1 Interrupt Sequence An interrupt request is held until the interrupt is accepted 2. Interrupt request flag for the interrupt source accepted is or the interrupt latch is cleared to “0” by a reset or an in- cleared to “0”. struction.

  • Page 66: Brk Interrupt

    GMS81508B/16B/24B, GMS82512/16/24 16.2 BRK Interrupt area for saving registers. Software interrupt can be invoked by BRK instruction, The following method is used to save/restore the general- which has the lowest priority order. purpose registers. Interrupt vector address of BRK is shared with the vector Example: Register save using push and pop instructions of TCALL 0 (Refer to Program Memory Section).

  • Page 67: Multi Interrupt

    GMS81508B/16B/24B, GMS82512/16/24 16.3 Multi Interrupt If two requests of different priority levels are received si- However, multiple processing through software for special multaneously, the request of higher priority level is ser- features is possible. Generally when an interrupt is accept- viced.
  • Page 68 GMS81508B/16B/24B, GMS82512/16/24 activated mode: rising edge, falling edge, and both edge. spondingly. Example: To use as an INT0 and INT2 INT0 pin INT0IF ;**** Set port as an input port R40,R42 INT0 INTERRUPT R4DD,#1111_1010B ;**** Set port as an external interrupt port INT1 pin INT1IF PMR4,#05H...
  • Page 69 GMS81508B/16B/24B, GMS82512/16/24 ADDRESS: 0D0 PMR4 EC2S EC0S INT3S BTCL INT2S INT1S INT0S INITIAL VALUE: 00 0: R40 0: R47 1: INT0 1: T3O 0: R41 0: R46 1: INT1 1: T1O 0: R42 0: R45 1: INT2 1: EC2 0: R44 0: R43 1: INT3 1: EC0...

  • Page 70: Watchdog Timer

    GMS81508B/16B/24B, GMS82512/16/24 17. WATCHDOG TIMER When the watchdog timer is not being used for malfunc- The watchdog timer rapidly detects the CPU malfunction such as endless looping caused by noise or the like, and re- tion detection, it can be used as a timer to generate an in- sumes the CPU to the normal state.
  • Page 71 GMS81508B/16B/24B, GMS82512/16/24 Example: Sets the watchdog timer detection time to 0.5 sec at 4.19MHz ;Select 1/2048 clock source, WDTON ← 1, Clear Counter CKCTLR,#3FH WDTR,#04FH ;Clear counter WDTR,#04FH Within WDT detection time ;Clear counter WDTR,#04FH Within WDT detection time ;Clear counter WDTR,#04FH Enable and Disable Watchdog Watchdog Timer Interrupt...

  • Page 72: Power Down Operation

    GMS81508B/16B/24B, GMS82512/16/24 18. POWER DOWN OPERATION GMS815xxB has a power-down mode. In power-down STOP Mode is entered by STOP instruction. mode, power consumption is reduced considerably that in battery operation. Battery life can be extended a lot. 18.1 STOP Mode For applications where power consumption is a critical Note: Since the X pin is connected internally to GND to...

  • Page 73: Minimizing Current Consumption

    GMS81508B/16B/24B, GMS82512/16/24 Release the STOP mode the on-chip RAM. External interrupts allow both on-chip RAM and Control registers to retain their values. The exit from STOP mode is using hardware reset or exter- nal interrupt. Start-up is performed to acquire the time for stabilizing os- cillation.
  • Page 74 GMS81508B/16B/24B, GMS82512/16/24 is external pull-down register, it is set to low. INPUT PIN INPUT PIN internal pull-up OPEN Very weak current flows OPEN Weak pull-up current flows When port is configure as an input, input level should be closed to 0V or 5V to avoid power consumption. Figure 18-2 Application Example of Unused Input Port OUTPUT PIN OUTPUT PIN...

  • Page 75: Oscillator Circuit

    GMS81508B/16B/24B, GMS82512/16/24 19. OSCILLATOR CIRCUIT The GMS815xxB has two oscillation circuits internally. tively, inverting amplifier which can be configured for be- and X are input and output for frequency, respec- ing used as an on-chip oscillator, as shown in Figure 19-1. Open 8MHz External Clock...

  • Page 76: Reset

    GMS81508B/16B/24B, GMS82512/16/24 20. RESET The GMS815xxB have two types of reset generation pro- dog timer reset. Table 20-1 shows on-chip hardware ini- cedures; one is an external reset input, the other is a watch- tialization by reset action. On-chip Hardware Initial Value On-chip Hardware Initial Value...

  • Page 77: Power Fail Processor

    GMS81508B/16B/24B, GMS82512/16/24 21. POWER FAIL PROCESSOR The GMS815xxB and GMS825xx have an on-chip power Note: If power fail voltage is selected to 3.0V on 3V oper- fail detection circuitry to immunize against power noise. A ation, MCU is freezed at all the times. configuration register, PFDR, can enable or disable the power fail detect circuitry.
  • Page 78 GMS81508B/16B/24B, GMS82512/16/24 RESET VECTOR PFS =1 RAM CLEAR INITIALIZE RAM DATA PFS = 0 Skip the INITIALIZE ALL PORTS initial routine INITIALIZE REGISTERS FUNTION EXECUTION Figure 21-2 Example S/W of RESET flow by Power fail 64mS Internal RESET When PFR = 1 64mS Internal t <64mS...

  • Page 79: Otp Programming

    A000H grammer or third party universal programmer shown as listed below. 4. Mount the socket adapter on the programmer. 5. Start program/verify. Hynix own programmer list Hynix Semiconductor Inc. Manufacturer: 22.2 Pin Function Programmer: Choice-Sigma, Stand-alone Gang4 (Program Voltage) is the input for the program voltage for programming Choice-Sigma is a Hynix universal single programmer for the EPROM.
  • Page 80 GMS81508B/16B/24B, GMS82512/16/24 64SDIP OPEN 64MQFP GMS815016BT/24BT OPEN Table 22-1 Socket Adapter Pin Assignment for GMS81516BT/24BT MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...
  • Page 81 GMS81508B/16B/24B, GMS82512/16/24 64LQFP GMS81516BT/24BT OPEN Table 22-2 Socket Adapter Pin Assignment for GMS81516BT/24BT MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...
  • Page 82 GMS81508B/16B/24B, GMS82512/16/24 42SDIP (Top View) N.C. 44QFP (Top View) GMS82524T N.C. N.C. : No Connection Table 22-3 Socket Adapter Pin Assignment for GMS82524T MAY. 2001 Ver 2.0 http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...

  • Page 83: Programming Specification

    GMS81508B/16B/24B, GMS82512/16/24 22.3 Programming Specification DEVICE OPERATION MODE = 25°C ± 5°C) Mode A0~A15 O0~O7 Read Mode 5.0V DOUT Output Disable Mode 5.0V Hi-Z Programming Mode Program Verify DOUT 1. X = Either V or V 2. See DC Characteristics Table for V and V voltage during programming.
  • Page 84 GMS81508B/16B/24B, GMS82512/16/24 SWITCHING WAVEFORMS WAVEFORM INPUTS OUTPUTS Must be steady Will be steady May change Will be changing from H to L from H to L May change Will be changing from L to H from L to H Do not care any Changing state change permitted unknown...
  • Page 85 GMS81508B/16B/24B, GMS82512/16/24 PROGRAMMING ALGORITHM WAVEFORMS Program Program Verify Addresses Addresses Valid High-Z Data In/Out Data out valid Data in Stable 12.75V 6.25V 5.0V 1. The input timing reference level is 1.0V for a V and 4.0V for a V at V =5.0V.
  • Page 86 GMS81508B/16B/24B, GMS82512/16/24 AC READING CHARACTERISTICS =0V, T = 25°C ± 5°C) Symbol Item Unit Test condition µs Address setup time Quick Pulse Programming supply current Note: V must be applied simultaneously or before V and removed simultaneously or after V AC PROGRAMMING CHARACTERISTICS =0V, T = 25°C ±...
  • Page 87 GMS81508B/16B/24B, GMS82512/16/24 START ADDRESS=FIRST LOCATION =6.0V =11.75 PROGRAM ONE 100µs PULSE INCREMENT X X=25? FAIL VERIFY FAIL VERIFY BYTE ONE BYTE PASS PASS LAST INCREMENT ADDRESS? ADDRESS =5.0V COMPARE FAIL ALL BYTES TO ORIGINAL DATA PASS DEVICE DEVICE PASSED FAILED Table 22-4 Programming Algorithm MAY.
  • Page 88 APPENDIX http://www.xinpian.net 提供单片机解密、IC解密、芯片解密业务 010-62245566 13810019655...

  • Page 89: Control Register List

    GMS81508B/16B/24B, GMS82512/16/24 A. CONTROL REGISTER LIST Initial Value Address Register Name Symbol Page 7 6 5 4 3 2 1 0 00C0 R0 port data register Undefined 00C1 R0 port I/O direction register R0DD 0 0 0 0 0 0 0 0 R1 port data register Undefined 00C2...
  • Page 90 GMS81508B/16B/24B, GMS82512/16/24 Initial Value Address Register Name Symbol Page 7 6 5 4 3 2 1 0 PWM control register PWMCR 0 0 0 0 0 0 0 0 00F2 00F4 Interrupt enable register low IENL 0 0 0 0 - - - - 00F5 Interrupt request flag register low IRQL...

  • Page 91: Software Example

    UP/DOWN S/W CLEAR S/W R21/INT1 4.7kΩ 2N2222 4.7kΩ 2N2222 GMS81516BT ;***************************************************************************** Title: GMS81516BT (GMS800 Series) Demonstration Program Company: Hynix Semiconductor Contents: Decimal Up/Down Counter Programmer: Hynix MCU application team ;***************************************************************************** ;******** DEFINE I/O PORT & FUNCTION REGISTER ADDRESS ********* 0C0H ;port R0 register...
  • Page 92 GMS81508B/16B/24B, GMS82512/16/24 6,0D0H ;timer1 selection EC2S 5,0D0H ;event counter 2 selection EC0S 4,0D0H ;event counter 0 selection INT3S 3,0D0H ;external int.3 selection INT2S 2,0D0H ;external int.2 selection INT1S 1,0D0H ;external int.1 selection INT0S 0,0D0H ;external int.0 selection PMR5 0D1H ;port R5 mode register BUZS 5,0D1H ;buzzer selection...
  • Page 93 GMS81508B/16B/24B, GMS82512/16/24 PUSH ENDM REG_RESTORE MACRO ;Restore Register from Stacks ENDM ;*********** CONSTANT DEFINITION *********** SEG_PORT ;7-Segment Output Port STROBE_PORT ;Strobe Signal Port ;************************************************************************** ALLOCATION ;************************************************************************** DIGIT10 ;DIG10 Display Data DIGIT1 ;Seg1 Display Data STROBE ;Strobe Signal Data TMR_500mS ;500ms Time Counter FLAGS ;Function Flags UP_F...
  • Page 94 GMS81508B/16B/24B, GMS82512/16/24 Loop: F_500ms == 1 clr1 F_500ms call INC_DEC ENDIF Loop ;*********************************************** Subject: Inc. or Dec. two digits ;*********************************************** Entry: UP_F Return: UP_F=1, Increment two digits UP_F=0, Decrement two digits ;*********************************************** INC_DEC: UP_F,DOWN ;Check Down mode or Up mode ;************************** Up Count ;**************************...
  • Page 95 GMS81508B/16B/24B, GMS82512/16/24 ;************************************************************************** EXTERNAL INTERRUPT 1 (CLEAR KEY) ;************************************************************************** INT_1: DIGIT1,#0 ;INT1 Service routine DIGIT10,#0 TMR_500MS,#0 ;0.5Sec Restart RETI ;*********************************************************************** Subject: Seven Segment Display (DSPLY) ;*********************************************************************** Entry: DIGIT10 or DIGIT1 Return: Output SEG_PORT (R00~R07), Strobe_port (R22,R23) Scratch: STROBE ;*********************************************************************** Description: After read internal RAM data, output data to the port * ;*********************************************************************** DSPLY:...

  • Page 96: Instruction

    GMS81508B/16B/24B, GMS82512/16/24 C. INSTRUCTION C.1 Terminology List Terminology Description A - Register X - Register Y - Register Program Status Word Carry Flag of PSW Overflow Flag of PSW Negative Flag of PSW Master Interrupt Enable Flag of PSW Zero Flag of PSW Half Carry Flag of PSW Break Flag of PSW (software interrupt) G flag of PSW(Direct Page)

  • Page 97: Instruction Map

    GMS81508B/16B/24B, GMS82512/16/24 C.2 Instruction Map 33333 33334 33343 33344 33433 33434 33443 33444 34333 34334 34343 34344 34433 34434 34443 34444 3< 3& +,*+ 6(74 $'& $'& $'& $'& 7&$// 6(7$4 386+ GS1ELW $1ELW/UHO GS1ELW/UHO &LPP GS.; $DEV 1ELW 6%& 6%&...

  • Page 98: Alphabetic Order Table Of Instruction

    GMS81508B/16B/24B, GMS82512/16/24 C.3 Alphabetic order table of instruction BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC ADC #imm Add with carry. A ← A + (M) + C ADC dp ADC dp + X ADC !abs NV - - H - ZC ADC !abs+Y ADC [dp+X] ADC [dp]+Y...
  • Page 99 GMS81508B/16B/24B, GMS82512/16/24 BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC CBNE dp,rel Compare and branch if not equal ; - - - - - - - - CBNE dp + X, If A ≠ (M), then PC ← PC + rel. Clear bit : (M.bit) ←...
  • Page 100 GMS81508B/16B/24B, GMS82512/16/24 BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC (M) ← (M) + 1 INC dp INC dp + X INC !abs N - - - - - Z - INC X INC Y Increment memory pair : (dp+1)(dp) ← {(dp+1)(dp)} + 1 INCW dp N - - - - - Z - JMP !abs...
  • Page 101 GMS81508B/16B/24B, GMS82512/16/24 BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC 138 POP A Pop from stack SP ← SP + 1, Reg. ← M(SP) 139 POP X - - - - - - - - 140 POP Y 141 POP PSW (restored) 142 PUSH A Push to stack...
  • Page 102 GMS81508B/16B/24B, GMS82512/16/24 BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC Transfer accumulator contents to X-register : X ← A 186 TAX N - - - - - Z - Transfer accumulator contents to Y-register : Y ← A 187 TAY N - - - - - Z - 188 TCALL n Table call : ), SP ←...

  • Page 103: Instruction Table By Function

    GMS81508B/16B/24B, GMS82512/16/24 C.4 Instruction Table by Function Arithmetic/Logic Operation BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC ADC #imm Add with carry. A ← A + (M) + C ADC dp ADC dp + X ADC !abs NV - - H - ZC ADC !abs+Y ADC [dp+X] ADC [dp]+Y...
  • Page 104 GMS81508B/16B/24B, GMS82512/16/24 BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC EOR #imm Exclusive OR A ← A ⊕ (M) EOR dp EOR dp + X EOR !abs N - - - - - Z - EOR !abs + Y EOR [ dp + X] EOR [dp] + Y EOR {X} INC A...
  • Page 105 GMS81508B/16B/24B, GMS82512/16/24 Register / Memory Operation BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC LDA #imm Load accumulator A ← (M) LDA dp LDA dp + X LDA !abs LDA !abs + Y N - - - - - Z - LDA [dp + X] LDA [dp]+Y LDA {X}...
  • Page 106 GMS81508B/16B/24B, GMS82512/16/24 16-Bit Operation BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC 16-bits add without carry : YA ← YA + (dp+1)(dp) ADDW dp NV - - H - ZC CMPW dp Compare YA contents with memory pair contents : N - - - - - ZC YA - (dp+1)(dp) Decrement memory pair : (dp+1)(dp) ←...
  • Page 107 GMS81508B/16B/24B, GMS82512/16/24 Branch / Jump Operation BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC BBC A.bit,rel Branch if bit clear : - - - - - - - - if(bit) = 0, then PC ← PC + rel BBC dp.bit,rel BBS A.bit,rel Branch if bit clear : - - - - - - - - if(bit) = 1, then PC ←...
  • Page 108 GMS81508B/16B/24B, GMS82512/16/24 Control Operation & etc. BYTE CYCLE FLAG MNENONIC OPERATION CODE NVGBHIZC Software interrupt: B ← “1”, M(SP) ← (PC ), SP ← SP - 1, - - - 1 - 0 - - M(s) ← (PC ), SP ← S - 1, M(SP) ← PSW, SP ←...

  • Page 109: Mask Order Sheet

    D. MASK ORDER SHEET MASK ORDER & VERIFICATION SHEET GMS81508B GMS81516B GMS81524B Customer should write inside thick line box. 1. Customer Information 2. Device Information Company Name Package 64SDIP 64MQFP 64LQFP Internet Hitel Chollian Application File Name ) .OTP YYYY Order Date ROM Size (bytes) Tel:...
  • Page 110 MASK ORDER & VERIFICATION SHEET GMS82512 GMS82516 GMS82524 Customer should write inside thick line box. 1. Customer Information 2. Device Information Company Name Package 42SDIP 44MQFP Internet Hitel Chollian Application File Name ) .OTP YYYY Order Date ROM Size (bytes) Tel: Fax: Check Sum...
