Installation and Operation Manual
Wireless Indoor Bell
Part # H004579MAN
Rev. 3
January 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SiteSync IQ and is the answer not in the manual?

Questions and answers

Related Manuals for American Time SiteSync IQ

Summary of Contents for American Time SiteSync IQ

  • Page 1 Installation and Operation Manual Wireless Indoor Bell Part # H004579MAN Rev. 3 January 2013...
  • Page 2 For additional support on the Wireless Bell or on any of the American Time products, please call or visit our web site. American Time 140 3rd St. So. PO Box 707 Dassel, MN 55325-0707 Toll Free Phone: 800-328-8996 Toll Free Fax: 800-789-1882 american-time.com...
  • Page 3 Wireless Bell The SiteSync IQ® Wireless Bell is a device which is triggered wirelessly by the SiteSync IQ System Controller. This Wireless Bell may be triggered by programmed events in the system controller, on demand using the MAN button on the system controller or the Circuit tab of the Remote Connect web interface (using a SiteSync IQ system controller with the Ethernet option and a computer with internet access).

  • Page 4: Specifications

    1. Remove antenna from bag and install onto antenna jack on top of bell. Hand tighten only. 2. The Wireless Bell can be easily mounted to a wall using the two mounting ears on the outside of the enclosure. Mounting screws not provided. 6.050” ” ” 4.805” © American Time...

  • Page 5: Installation Instructions

    Once the Wireless Bell is wired and powered up, it may be tested or activated by using the MAN button on the system controller or via the Circuit Tab of the Remote Connect web interface (using a SiteSync IQ system controller with the Ethernet option and a computer with internet access).
  • Page 6 Wireless Bell To manually activate the Wireless Bell using the Remote Connect web interface: 1. Enter your SiteSync IQ system controller IP address into a web browser (such as Internet Explorer) 2. Log in with your User name and Password 3.
