- Page 1 Installation and operating instructions Low water level limiter SMLC1 With level electrode EL 030 / EL 19-2 D-08-B-16644-1 Edition 07/11...
-
Page 2: Table Of Contents
-Table of contents- Risks and Safety precautions General safety instructions ............3 Exclusion of liability ..............4 Use in compliance with regulations Function SMLC1 Operating principle ..............6 Design Installation dimensions and descriptions........7 Installation Configuration Fitting the electrode 9-11 Fixing elements for receiving electrodes ....... -
Page 3: Risks And Safety Precautions
General safety instructions 1. Avoidance of risks to persons and property • Only use the device supplied in accordance with the intended planning. • Extensions and modifications to the device must only be carried out with our approval. • Observe accident prevention regulations and system-specific safety instructions. •... -
Page 4: Exclusion Of Liability
Exclusion of liability IGEMA GmbH Mess- und Regelsysteme will assume no liability if the above-mentioned regulations, instructions and safety precautions are not noted and followed. -
Page 5: Use In Compliance With Regulations
2. Use in compliance with regulations The self-monitoring low water level limiter SMLC1 in combination with the level electrodes EL 030 or EL 19-2 is a multi-dynamic limiter of a special type in accordance with DIN VDE 0116 and Wasserstand 100. The self-monitoring control system (SMC) enables first failure identification at the time of occurrence and immediately switches off the downstream relays. -
Page 6: Operating Principle
3.1 Operating principle SMLC1 The SMC system is capable of identifying any possible first failure the moment it occurs and switching off the downstream relays. Failure to detect a fault is therefore impossible. As further dynamic monitoring, the periodic overall test of the device takes place every 2 minutes for one second as a fully automatic process. -
Page 7: Design
4. Design The SMLC1 is supplied in a plastic plug-in housing for fitting into switch cabinets. The housing is designed for quick fitting with a spring catch for the DIN EN 50022 standard 35 mm carrier rail and for screw fixing on a mounting plate. 4.1 Installation dimensions and descriptions SMLC1 Base Front view... -
Page 8: Installation
5. Installation Secure with protection class in accordance with current regulations With snap fastening for standard 35 mm carrier rail according to DIN EN 50022 • Fix device on standard carrier rail by means of the snap fastening (4). • Release fixing screws (3) and pull hood (7) from holder (5). Without snap fastening •... -
Page 9: Fitting The Electrode
7. Fitting the electrode It is essential to remove the protective tube for transport before installation! If several electrodes are screwed into a flange the electrode plug (2) and the associated electrodes should be labelled to prevent confusion! Fixing the electrode extension (9) 1 Screw Push the electrode extension (9) approx. -
Page 10: Fixing Elements For Receiving Electrodes
7.1 Fixing elements for receiving the electrodes The flanges, seals, screws and nuts listed in the table below are laid out in accordance with the Technical Rules for Steam Boilers (TRD) and tested by the Technischen Überwachungsverein (TÜV) [Technical Inspection Agency]. Flange according to DIN Sealing Form... - Page 11 DIN screws Numbe Dimension Material M16 x 75 1.7709 M20 x 100 100/160 M24 x 110 M20 x 90 1.7709 M24 x 110 100/160 2510 LM27 x 145 Ck 35 DIN nuts Numbe Dimension Material 1.7258 24032 100/160 1.7258 24032 100/160 2510 NFM27...
-
Page 12: Mounting In Mounting Housing
7.2 Mounting in mounting housing The approval is only valid if shut off valves are mounted between the process connections of the mounting house and the boiler supports and a relief valve is fitted on the mounting housing! Illustration Mounting Housing... - Page 13 Construction dimensions Construction dimensions min. [ [ [ [ mm]] ∅ ∅ ∅ ∅ d 60.3 114.3 Materials Flanges 1.0460 Pipes St35.8 / 16 Mo 3 (according to pressure range) Process connection M1 Sealing form DIN 2635 2526 Form C 2637 2526 Form E 2638...
-
Page 14: Adjusting The Electrode Plugs
7.3 Adjusting the electrode plugs (see sketch page 9) If insertion of the electrode plugs (2) is not possible because of the position of the contact carrier (4), take the following steps: • Keep releasing the threaded ring (5) until the contact carrier (4) can be lifted. •... -
Page 15: Power Connection
Power connection Carry out connection according to the SMLC1 wiring diagram on the back plate of the hood (see page 7 item 7) or according to the wiring diagram illustrated. 8.1 Wiring diagram (EL 030, EL 19-2) See name plate of supply voltage Safety chain Alarm Power connection:... -
Page 16: Procedure
8.2 Procedure • Pierce or pull out cable feedthrough (6) and feed connection cable through. Check supply voltage. See name plate for allowable voltage. Use shielded connection cable to the electrode 2 x 2 STP, e.g. LIHF/GLS, 4 x 0.75 mm². •... -
Page 17: Maximum Ratings Of Potential Free Contacts
Electrode EL 030 EL 19-2 Nominal pressure Max. allowable pressure PS [bar] Max. allowable temperature TS [°C] Construction dimensions Y > 125 > 130 [mm] Mechanical connection Thread G ½ Power connection Plug connection with screw terminals, strain relief Screw cable connection M16X1.5 Protection class in accordance with DIN IP 65... -
Page 18: Appendix
10. Attachment Warranty We give a guarantee period on our product of 24 months. The condition for this is proper handling in accordance with the assembly and operating instructions. For worn and replacement parts the warranty is limited to defects of material and manufacture. - Page 19 LECOS GmbH J.G. Merckens Mess- und Regelsysteme GmbH & Co. KG Zieglerstraße 10-16 D-52078 Aachen declare as the IGEMA Group that the product “NW water level limiter” as pressure accessory Product type: Control device “SMLC1” with Electrode “EL030” or “EL19-2”...
-
Page 20: Ec Declarations Of Conformity
This high-quality IGEMA product was designed, manufactured and tested with the application of the QM System guidelines in accordance with DIN EN ISO 9001:2000. If the device supplied shows transport damage or gives cause for complaint in spite of our final quality control please contact our SERVICE department by return.
