Symetrix SymNet Series Quick Start Manual

Quick Start
SymNet
™
Before You Begin
What Ships in the Box
A SymNet hardware device
R
R SymNet Designer CD-ROM
(Windows)
R A detachable power cable
This Quick Start Guide
R
NOTE - You may complete the
warranty registration online at
www.symetrixaudio.com.
What you'll need to run SymNet
Designer software
A Windows PC with 300MHz or
R
higher Pentium and:
R WIN 98SE, WIN ME, or WIN
2000.
10MB -15MB free storage space
R
R 1024x768 graphics capability
R 16 bit or higher colors
R CD ROM drive or Internet connec-
tion
R 32MB RAM or more as required
by your operating system
R An available serial port capable
of operating at 57.6 or 115.2
kilobaud
R A cable to connect the RS-232
serial port of your PC to the
SymNet's RS-232 input. The
SymNet RS-232 input is a female
DB9 connector.
Getting Help
SymNet Designer, the Windows
application that controls SymNet
hardware includes a help file which
acts as a complete user's guide for
both hardware and software.
If you have questions beyond the
scope of the help file, contact our
Technical Services Group in the
following ways:
Tel (425) 787-3222
8:00 am to 4:30 pm
Pacific Time
Email tech@symetrixaudio.com
Web www.symetrixaudio.com
To download the latest version of SymNet designer, the Windows application that
controls SymNet hardware go to www.symetrixaudio.com/Products/symnet.htm.
Operator Safety Summary
•
Read these instructions.
• Heed all warnings.
• Keep these instructions.
Power Source. SymNet™ Audio Matrix
hardware uses a switching power supply
that automatically adjusts to the applied
voltage. Ensure that your AC mains
voltage is somewhere between 100-
240VAC, 50-60Hz.
Grounding. This product is intended to
operate from a power source that does
not apply more than 250V rms between
the power supply conductors or between
either power supply conductor and
ground. A protective ground connection,
by way of the grounding conductor in
the power cord, is essential for safe
operation.
Do not defeat the safety purpose of
the polarized or gournding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade of the
third prong is provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet.
Fuse. This product contains no user
servicable fuse.
Danger from Loss of Ground. If the
protective ground connection is lost, all
accessible conductive parts, including
knobs and controls that may appear to be
insulated, can render an electric shock.
Proper Power Cord. Use only the
power cord and connector specified for
the product and your operating locale.
Use only a cord that is in good condition.
Protect the power cord from being walked
on or pinched, particularly at the plug,
convenience receptacle, and the point
where the cord exits from the apparatus.
Operating Location. Do not operate
this equipment under any of the following
conditions: explosive atmospheres,
in wet locations, in inclement weather,
improper or unknown AC mains voltage,
or if improperly fused. Do not install near
any heat source such as radiators, heat
registers, stoves, or other apparatus
(including amplifiers) that produce heat.
Unplug this apparatus during lightning
storms or when unused for long periods
of time. Do not use this apparatus near
water. Do not expose this apparatus
Revision A.04
to dripping or splashing. Place no
objects filled with liquids, such as vases,
upon this apparatus. Do not block any
ventilation openings.
Stay Out of the Box. To avoid
personal injury (or worse), do not
remove the product covers or panels.
Do not operate the product without the
covers and panels properly installed.
Only use accessories specified by the
manufacturer. Clean only with dry cloth.
User-Serviceable Parts. There are
no user serviceable parts inside the
SymNet™ Audio Matrix. There are no
adjustments or jumpers to set within
the chassis. Settings are stored in non
-volatile ram and no back-up battery
is required. In case of failure, refer all
servicing to the factory. Servicing is
required when the SymNet™ Audio
Matrix has been damaged in any way,
such as when liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.
Equipment Markings
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF FIRE OR
WARNING:
ELECTRIC SHOCK DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE
AVIS: RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
SEE OWNERS MANUAL. VOIR CAHIER D'INSTRUCTIONS.
No user serviceable parts inside. Refer servicing to qualified service personnel.
Il ne se trouve a l'interieur aucune piece pourvant entre reparée l'usager.
S'adresser a un reparateur compétent.
The lightning flash with arrowhead
symbol within an equilateral triangle is
intended to alert the user of the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute
a risk of electric shock to persons. The
exclamation point within an equilateral
triangle is intended to alert the user of
the presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the product
(i.e., this quick start guide).
Warning
To reduce the risk of fire or
electric shock, do not expose this
apparatus to rain or moisture.
