Troubleshooting - Storage Motion Automated WardrobeLift Standart Installation Instructions Manual

PROBLEM
Rotating arms are not
stopping at proper points
Lift does not respond or acts
improperly.
(Be sure to cut power and
reconnect)
Switch light out
Lift does not go up straight
Lift runs in reverse
One switch operates two
motors
Trouble Shooting
SOLUTION
Reset the motor limits using the wireless switch. See motor limit step in the instructions.
Press the reset button using a pin until 1 beep then immediately within 2 seconds press the up or
down button on the switch. Unit should respond . If no response then proceed as follows. Press the
reset button for approx. ten seconds using a pin. Hold until 2 beeps and release Wait another 10
seconds or more then re-associate the motor to a switch by pressing the reset button once for 1 beep
then immediately within 2 seconds press the Up or Down button of the switch.
Check battery
Adjust the right side strap which is the non motor side strap . Remove the anchor screw and move
the strap material accordingly and then reinsert the screw. See installation instructions. The left side
(Motor Head)strap CANNOT be adjusted.
Motor head needs to be on left side of tube when facing unit from the front. Lift the black cover on
the switch and press the very small button on the right and hold for 3 seconds. Motor direction
should now be changed
Press the reset button (very small white button on the motor head) for ten seconds using a pin on the
motor you want to disassociate. Hold until 3 beeps then release. Test all switches to make sure they
will not operate the motor.
Associate the motor to the correct switch by pressing the reset button once then immediately within
2 seconds pressing the Up or Down button of the correct switch. Make sure all other switches are not
activated during this procedure. Set the motor limits.
CONTACT PHONE - 704 746 3700
Reset button
must use pin, small screw
or paperclip to activate.
Beeps are very quiet!
