8. Mount RIGHT side idler bracket for the motor tube using the 2 #10 screws supplied on right
hand side at the top. Use the sticky foam to assist in placement of the bracket and to reduce
vibration. See Fig 2 and photo 6 for where to position. The motor must be on the left side
for lifting straps to be correct as they must lift from the top of the tube as opposed to the
bottom of the tube
9 Mount LEFT side bracket with 2 # 10 screws provided, Use the sticky foam to assist in
placement of the bracket and to reduce vibration. . See Fig 3 and photo 6 for where to
position.
10. Place tube with motor into square opening in left bracket and then place right side tube into
right side bracket (SEE photo 4 and 5) Make sure that straps are coming from the top of the
tube as opposed to the bottom of the tube
side bracket.
11 Ensure that motor tube is parallel with what will be the position of the clothes rod. Motor side of
.
tube with cord must be on the left side
12. Manually unwrap the straps and attach
rotating arm using the #6 machine screws and nuts . Do this while the arms are in the complete
down position (Horizontal). Make sure that strap clips are secure and that straps are NOT
twisted and that they line up with the arms. See Fig 4 for strap clip position.
13. If not being hardwired by an electrician, connect the plug to the motor cord. The brass terminal
goes with the black wire and the green screw head goes with the green wire (ground).
14. Plug in the unit . The top button on the transmitter is for UP, the middle button is for STOP, and
the bottom button is for DOWN. Ensure transmitter matches for the motor.
15. Ensure that the lifting straps and the rotating arms are in alignment when the rotating
arms are operating.
.
Add the cotter pin to secure the motor in the left
to the predrilled mounting holes at the end of each
