WARNING – if motor is
mounted too low it is
possible to damage the
unit when setting the
the UP limit as too
much leverage will be
gained
Motor
mounted
TOO low!
Approx
1.5 to 3 in.
front
Motor with
Tube
Fig. 3
Lifting Strap
Approx
4 to 8
in.
Wireless
switch location
Left hand side view
Motor with Tube
Motor Cord
back
Patent Pending
11
