Toro 22442 Installation Instructions

IMPORTANT: Before using this product, read the
safety section in your traction unit operator's manual,
and follow all precautions listed there.
Safety Decals
1
# 100–4664
Figure 1
1. Tipping hazard—do not
exceed the maximum load
Specifications:
Note: Specifications and design are subject to change
without notice.
Overall width
Overall length
Weight
Maximum dry concrete
load
The Toro Company
– 1999
8111 Lyndale Ave. South
Bloomington, MN 55420–1196
For use with the Siteworks Systems Auger Drive Head
Model 22442
2
2. Maximum load
25.15 inches (64 cm)
18.25 inches (46 cm)
75 lbs (34 Kg)
200 lbs (90.7 Kg)
Cement Mixer Bowl
Stability Ratings
To determine the degree of slope you can traverse with the
cement bowl installed on a traction unit, find the stability
rating for the hill position you want to travel in the
appropriate table on the following page, then find the
degree of slope for the same rating and hill position in the
Stability Data section of the traction unit operator's
manual.
IMPORTANT: If your traction unit has a rear
operator's platform, the counterweight must be used
on the platform while using the cement bowl, or the
traction unit will become unstable.
POTENTIAL HAZARD
Exceeding the maximum recommended slope
can cause the traction unit to tip.
WHAT CAN HAPPEN
If the traction unit tips, you or bystanders could
be crushed.
HOW TO AVOID THE HAZARD
Do not drive the traction unit on a slope steeper
than the maximum recommended slope, as
determined in the following tables and the
traction unit operator's manual.
