- Page 1 P1/PD Series: B-Mod Service Information Medium Pressure Axial Piston Pumps Bulletin HY28 - 2708 - 02/SVC/EN Effective: July 2019 Replaces: March 29, 2019...
-
Page 2: Table Of Contents
Assembly Tools ..............................47 Rotation Change ..............................51 Test Procedure ..............................53 Test Criteria & Start-up Procedures........................55 Trouble Shooting ..............................56 Conversions and Formulas ........................... 58 Warning ................................. 59 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 3: B-Mod Pump Identification
NOTE: A-mod and B-mod controls are NOT Interchangeable! Adapter block is required to put a B-mod control on an A-mod or an A-mod control on a B-mod pump. See Parts Kits page for adapter block part numbers. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 4: B-Mod Controls Vs A-Mod Controls
Control or Bias Pressure Pmax Tank Control Standard NG6/D03 Pattern Custom Control Pad Pattern NOTE: Bolt pattern & size remains the same. No change to housing casting required. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 5: General Information
27-34 Rc. The key corners must be chamfered 0.032-0.040 in (0.81-1.0 mm) at 45° to clear radii that exist in the keyway. Side Load Capability The P1/PD series is designed for inline-drive. Side loading on the shaft is not recommended. If this is unavoidable consult your nearest Parker representative. Fluid Connections Connect inlet and outlet lines to the port block of the pump. -
Page 6: Typical Characteristics
8.2% per turn (3.7 cc/turn) 0-50% 4.6% per turn (2.76 cc/turn) 075/085 0-45% 4.3% per turn (3.23 cc/turn) 0-45% 3.9% per turn (3.9 cc/turn) 0-25% 3.3% per turn (4.62 cc/turn) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 7: 018, 028 B-Mod Pump Exploded View
12 in-lbs 70 in-lbs 45 ft-lbs 45 ft-lbs 30 in-lbs 30 in-lbs 70 in-lbs 70 in-lbs 16 ft-lbs 45 ft-lbs 14 ft-lbs 14 ft-lbs 70 in-lbs 70 in-lbs Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 8: 045 B-Mod Pump Exploded View
* Clockwise Rotation Shown Item Torque 63 ft-lbs 45 ft-lbs 6 ft-lbs 25 in-lbs 105 ft-lbs 105 ft-lbs 10 ft-lbs 46 ft-lbs 30 in-lbs 70 in-lbs 75 ft-lbs 14 ft-lbs Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 9: 018, 028, 045 B-Mod Pump Parts
Internal retaining ring (housing) * Denotes seal or O-ring is included in the seal kit | *** Contact factory for 045 overcenter "X" port plate part number information Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 10: 060, 075, 085, 100, 140 B-Mod Pump Exploded View
Bulletin HY28-2708-02/SVC/EN | July 2019 P1/PD B-mod Service Information 060, 075, 085, 100, 140 B-mod Pump Exploded View * Counter-clockwise Rotation Shown 18 19 75/85 Item Torque (Measured in ft-lbs) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 11: 060, 075, 085, 100, 140 B-Mod Pump Parts
See separate compensator ordering information. Compensator * Denotes seal or O-ring is included in the seal kit | *** Contact factory for overcenter "X" port plate part number information Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 12: Volume Stop Control
*Min & max rods same for the 45 thru 140, but different on the 18 & 28. See table below for kit part number. Volume Stop Kits Size 075/085 Maximum volume stop kit S2E-19203-5K S2E-19204-5K S2E-19115-5K Minimum volume stop kit S2E-19608-5K S2E-19609-5K S2E-19115-5K Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 13: Thru Drive Couplings And O-Rings
S2E-19409-0 03E-94361-0 03E-93279-0 03E-93279-0 03E-94272-0 03E-93945-0 695-00243-0 SAE C, 14 Tooth 03E-93276-0 03E-93276-0 03E-94271-0 03E-93944-0 695-00251-0 SAE CC, 17 Tooth 03E-94270-0 03E-93943-0 695-00251-0 SAE D&E, 13 Tooth 03E-93942-0 695-00259-0 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 14: C0 B-Mod Control Exploded View
M4 x 5 set screw 108X4V Boss plug & O-ring - SAE 108X8V Boss plug & O-ring Not sold separately Compensator housing *Included in C, L, & AM controls seal kit Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 15: L0 B-Mod Control Exploded View
03E-95572-0 Differential outer cap 340-00063-0 Differential adjustment lock nut 361-08275-0 Differential M6x22 adjustment screw Not sold separately Compensator housing *Included in C, L, & AM controls seal kit Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 16: L2 B-Mod Control Exploded View
03E-95572-0 Differential outer cap 340-00063-0 Differential adjustment lock nut 361-08275-0 Differential M6x22 adjustment screw Not sold separately Compensator housing *Included in C, L, & AM controls seal kit Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 17: Am B-Mod Control Exploded View
03E-95572-0 Differential outer cap 340-00063-0 Differential adjustment lock nut 361-08275-0 Differential M6x22 adjustment screw Not sold separately Compensator housing *Included in C, L, & AM controls seal kit Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 18: C0 To L0 B-Mod Conversion Guide
O-ring Differential inner spring guide O-ring Differential main O-ring Differential outer plug Differential adjustment lock nut Differential adjustment screw Kit #4 S2E-20466-5K Item Description Load sense differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 19: C0 To L2 B-Mod Conversion Guide
Differential main O-ring Differential outer plug Differential adjustment lock nut Differential adjustment screw Kit #4 S2E-20466-5K Item Description M6 x 6 set screw with 0.4mm orifice Load sense differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 20: C0 To Am B-Mod Conversion Guide
O-ring Differential main O-ring Differential outer plug Differential adjustment lock nut Kit #2 S2E-20464-0K Item Description M5 x 6 set screw with 0.8mm orifice AM remote differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 21: L0 / L2 To C0 B-Mod Conversion Guide
Boss plug & O-ring Boss plug & O-ring *Choose SAE, Metric, or BSPP boss plug based on the load sense port type. All three come in Kit #3. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 22: L0 To L2 B-Mod Conversion Guide
P1/PD B-mod Service Information L0 to L2 B-mod Conversion Guide Remove Item Description M6 x 6 set screw Kit #4 S2E-20466-5K Item Description M6 x 6 set screw with 0.4mm orifice Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 23: L2 To L0 B-Mod Conversion Guide
P1/PD B-mod Service Information L2 to L0 B-mod Conversion Guide Remove Item Description M6 x 6 set screw with 0.4mm orifice Kit #2 S2E-20464-0K Item Description M6 x 6 set screw Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 24: L0 To Am B-Mod Conversion Guide
Item Description M5 x 6 set screw Load sense differential spool Kit #2 S2E-20464-0K Item Description M5 x 6 set screw with 0.8mm orifice AM remote differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 25: L2 To Am B-Mod Conversion Guide
M6 x 6 set screw with 0.4mm orifice Load sense differential spool Kit #2 S2E-20464-0K Item Description M5 x 6 set screw with 0.8mm orifice M6 x 6 set screw AM remote differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 26: Am To C0 B-Mod Conversion Guide
Boss plug & O-ring Boss plug & O-ring *Choose SAE, Metric, or BSPP boss plug based on the load sense port type. All three come in Kit #3. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 27: Am To L0 B-Mod Conversion Guide
Item Description M5 x 6 set screw with 0.8mm orifice AM remote differential spool Kit #4 S2E-20466-5K Item Description M5 x 6 set screw Load sense differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 28: Am To L2 B-Mod Conversion Guide
M6 x 6 set screw AM remote differential spool Kit #4 S2E-20466-5K Item Description M5 x 6 set screw M6 x 6 set screw with 0.4mm orifice Load sense differential spool Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 29: 075, 085, 100, 140 Torque Limiter
Turn CCW to increase torque setting and CW to decrease torque setting For counter-clockwise rotation, the torque limiter kit is inserted in this SAE-6 port * Clockwise Rotation Shown Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 30: Electronic Unload Control B-Mod Exploded View
Item 11 ft lbs 40 in lbs 6 ft lbs 22 ft lbs 5 ft lbs 85 ft lbs 70 in lbs 50 ft lbs 50 ft lbs Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... - Page 31 Unload 12VDC cartridge valve coil 517-00174-5 517-00174-5 Unload 24VDC cartridge valve coil B-Mod Unload Control Kits Unload Control Service Kit* S2E-20824-5K Seal Kit S2E-20825-5K *Includes items 6 and 11-28 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 32: Parts Kits
L0 & L2 load sense differential spool Control Adapter Block Assemblies B-mod control on A-mod CW Pump S2E-20301-5 B-mod control on A-mod CCW Pump S2E-20302-5 A-mod control on B-mod Pump (CW or CCW) S2E-20325-5 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 33: Compensator Procedures
Differential Inner Spring 14.9 0.66 Differential Outer Spring 0.66 Reference item numbers on page 13-16. Table 1 - P1/PD B-Mod C, L, & AM Compensator Free Spring Length Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... - Page 34 17. Using bolts (#12), bolt down compensator assembly onto pump housing. Make sure locating pin (#15) is properly aligned to locating pin hole on the compensator mounting pad on the pump housing. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 35: Pump Service Procedures
NOTE: For rotation change, do not disassemble further. See Rotation Change Procedure. For the 60-140cc pumps, remove the tapered roller bearing cone (#18) and shims (#17). Figure 1 Pump Data Tag Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... - Page 36 14. If there is excessive wear on the port block bearing (#18) (bushing for sizes 18, 28 & 45), remove the bearing or bushing from the port block (#3). Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 37: Pump Inspection Procedures
11. Spin the shaft bearing (#32). It should not have any signs of roller spalling, brinelling, or discoloration. It should rotate freely without binding or rough feel. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 38: Component Rework Limits
+/- 0.2mm (± 0.51mm) is 0.0002 in from shoe face when lapping is 0.003 in 0.8 mm minimum (0.0051mm) (0.076mm) allowable surface finish Table 2 - Component Rework Information Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 39: 018, 028, 045 Assembly Procedures
Caution: Make sure snap ring is properly seated in groove prior to removing barrel from press. removing the barrel assembly from the press. Figure 3 Figure 4 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA CHART 2 l a i... - Page 40 Use Loctite Primer Grade “T” or other suitable primer on screws and mating threads in Parker Hannifin Corporation housing. Apply Loctite #242 (use sparingly) to screw threads and install Hydraulic Pump and Power Systems Division orifice screws to hold bearings in place.
- Page 41 Loctite 243 (use sparingly) to the cam bearing screw (#30) threads and install the screws to hold the cam bearings in place. Torque the screws per the torque table on page 7. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
- Page 42 23. Install five O-ring seals and assembled compensator (#41) on the side of the pump housing. Tighten the compensator bolts hand tight, and then torque the bolts per the values in the torque table on page 13. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
- Page 43 10. Remove the port block (#3) from the housing. Then remove the port block bearing cone (#19) and shim (#17) and continue with the rest of the assembly. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
- Page 44 03E-94158-0 03E-93979-0 4.19 mm (.165 in) 4.25 mm (.167 in) 4.16 mm (.1638 in) 03E-93576-0 03E-93864-0 03E-93980-0 Shim Kits: S2E-18591-0K S2E-18640-0K S2E-18527-0K Table 4 - Shim Thickness Selection Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 45: 060, 075, 085, 100, 140 Assembly Procedures
19. Install the large o-ring in the groove on the pump housing. Install the three Teflon o-rings in the pressure communication ports on the pump housing. Parker Hannifin Corporation 20. Install the cam bearings in the cradle area of the housing. The chamfer on Hydraulic Pump and Power Systems Division the back of the bearing must face the outer wall of the housing. - Page 46 26. Install the five O-ring seals and assembled compensator (#41) on the side of the pump housing. Tighten the compensator bolts hand tight, and then torque bolts per torque table on page 13. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 47: Assembly Tools
(2.00 in) (3.53 in) (1.178 in) 25.40 mm (1.00 in) T5 Rear Bushing Installation Tool 101.60 mm (4.00 in) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA 50.80 25.40 19.05 ( 2.00) ( 1.00) ( 0.75) - Page 48 0.146 in 0.772 in 13 mm (3.71 mm) (19.9 mm) (.5 in) 0.157 in 0.85 in (4.00 mm) (21.6 mm) 0.157 in 0.95 in (4.00 mm) (24.1 mm) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
- Page 49 060 / 075 / 085 213-0-004192 12° (71.4 mm) (66.0 mm) 3.623 in 3.390 in 213-0-004204 15° (92.1 mm) (86.1 mm) 3.687 in 3.515 in 213-0-004197 15° (93.7 mm) (89.3 mm) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
- Page 50 060 / 075 / 085 213-0-004193 12° (53.8 mm) (48.7 mm) 2.562 in 2.335 in 213-0-004205 15° (65.1 mm) (59.3 mm) 2.80 in 2.562 in 213-0-004198 15° (71.1 mm) (65.1 mm) Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 51: Rotation Change
Torque the ripple chamber set screw per the torque values in the torque table on page 6 or 7. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... - Page 52 Now the pump can be reassembled per the Assembly Procedures section. Test the pump per the Test Procedure section. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 53: Test Procedure
Test Procedure Pump Test Procedure Test criteria based on hydraulic oil ISO 32 per Parker HF-0 fluid specifications. Operating speed: Do not exceed catalog ratings. Maximum Case pressure: 2 bar (29 psi) absolute or 0.5 bar (7.5 psi) above inlet pressure. - Page 54 62-69 bar 200-207 bar 269-276 bar 900-1000 psi 2900-3000 psi 3900-4000 psi “X” Circuit 1 - Load Sense Test Circuit Diagram Circuit 2 - Remote Compensator Test Circuit Diagram Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 55: Test Criteria & Start-Up Procedures
• Make correct pressure adjustments. • Gradually increase speed. Be alert for trouble as indicated by changes in sounds, system shocks, and air in fluid. • Equipment is operational. Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 56: Trouble Shooting
Compensator Add orifice in load sense line cumulator effects) instability Increase load sense differential pressure Outlet port check valve Relocate check valve further from outlet port Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... - Page 57 Efficiency reduced by mud or scale deposits Intermittent hydraulic fluid flow Too little fluid Improper baffles Reservoir Insulating air blanket that prevents heat rejection Heat pickup from adjacent equipment Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA...
-
Page 58: Conversions And Formulas
(cm /rev) Fluid motor torque pressure(bar) x displacement (cm /rev) x mech. eff. 20� Fluid motor power rpm x (cm /rev) x (bar) x overall eff. 600000 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division Marysville, Ohio USA... -
Page 59: Warning
Parker or its subsidiaries or authorized distributors. To the extent that Parker or its subsidiaries or authorized distributors provide component or system options based upon data or specifications provided by the user, the user is responsible for determining that such data and specifications are suitable and sufficient for all applications and reasonably foreseeable uses of the components or systems. - Page 60 © 2019 Parker Hannifin Corporation, all rights reserved Bulletin HY28-2708-02/SVC/EN Effective: 07-19 Parker Hannifin Corporation Hydraulic Pump and Power Systems Division 14249 Industrial Pkwy Marysville, OH 43040 USA phone 937 644 4435 fax 937 642 3639 www.parker.com/hps...
