MATCHMASTER POWDER SCALE/DISPENSER (#98941)
QUICK START GUIDE
Congratulations on the purchase of your new RCBS MatchMaster Powder Dispenser!
CAUTION: Read the Full Instruction Manual Before Using Your MatchMaster Powder Dispenser
This short guide is only intended to help get you started setting up and using the product. It does not cover all
features, specs or other aspects of the product, and does not include important safety information and warnings
found in the full instruction manual.
1. Deactivate Transportation Mechanism -
CAUTION: The transportation protection mechanism (located at the side of the unit) must be
deactivated before using the MatchMaster to prevent potential damage. To deactivate it:
Connect MatchMaster to power, switch it on and press [ZERO] key while counting down. Unstable
numbers will show on the display. Turn the M4x8 transportation protection screw clockwise (Photo 1)
until numbers on the display stabilize. If the last two numbers are still moving slightly the scale is still
stable. When nished, the screw will be recessed 1~2mm from the surface (Photo 2). Do not exceed a
torque of 8 in-lbs (10 kg-cm) as this may damage the mechanism.
2. Level - Adjust feet to ensure the MatchMaster is level.
3. Warm Up - With unit powered on, allow to warm up for 15-20 minutes prior to calibration and use.
4. Check Powder Drain - Ensure powder drain is closed. If it is not closed, the display will ash "Drain".
5. Calibration - After 15-20 min warm up, calibrate scale prior to use. Refer to full manual (pg. 7) for calibration steps.
6. Select Powder - The MatchMaster will not dispense until a powder speed setting is selected. Select a dispense
speed based on your powder type (1-4) and press the "Powder" key to select the appropriate powder speed.
See "POWDER" on opposite side of this page for more detailed information or page 6 of the full manual.
7. Powder - Add Powder to hopper.
8. Select Mode - Two Modes are available, Standard (+/-0.1gn Accuracy) or Match (+/-0.04gn Accuracy). Depress
mode button and use keys [2] or [8] to toggle to "MAtCh" press [GO] key to enter in submenu, use [4] or [6] keys to
select "on" or "oFF". If "oFF" is selected MatchMaster will be in Standard mode. If "on", unit will be in Match Mode.
Note: The scale is extremely sensitive to wind, vibration, and even static while dispensing in Match Mode.
See full manual for more detailed information.
9. Auto/Manual Dispense - The unit is in "Auto" dispense mode from factory. Powder charges will automatically
dispense from the unit once an empty scale pan is placed onto the unit and the scale is stable. If leaving the unit
in default "Auto" dispense mode, follow Step 10 (Dispense) below. To change to Manual dispensing mode if desired:
• Press [MODE] key and "Auto" will display. Press [GO] to enter setting. Use [4] or [6] to choose "oFF" and press
[GO] to set as manual dispense mode and display shows "Manual".
10. Dispense - Place scale pan on platen, depress zero button and use number keys to enter desired charge weight.
Depress the [GO] key and begin dispensing. Refer to the full manual for additional details.
Happy Reloading!!
MatchMaster owners ! Download the free RCBS App for your mobile device from the App Store
(Apple® iPhone/iPad) or Google Play (Android™). This provides wireless remote control of 4 functions:
Dispense Powder, Calibrate, Con gurations, and Load Log. See the full manual for more details.
iPhone® is a registered trademark of Apple Inc.
Android™ is a trademark of Google Inc.
RCBS
605 Oro Dam Blvd East
Oroville, California, 95965
1-800-533-5000 (US or Canada)
E-mail: rcbs.tech@vistaoutdoor.com Website: www.rcbs.com
Photo 1
Photo 2
