Visa Lighting Linesse CV2424 Installation Instructions Manual

Linear luminaire
Hide thumbs

Advertisement

Quick Links

Download this manual
Linesse Linear Luminaire
3" Recessed
Installation Instructions
LINESSE LINEAR LUMINAIRE
Page 2: Warnings
Page 3: Mounting Types and Dimensions
Page 4: T-Grid and Joining Fixtures
Page 5: Hard Ceiling and Joining Fixtures
Page 7: Corners
Page 8: Corners – T-Grid and Joining Fixtures
Page 9: Corners – Hard Ceiling and Joining Fixtures
Page 10: Power Feed
!
When using electrical equipment, basic safety precautions should always be followed, including the following:
•Read all instructions carefully before installing and save for future use.
•Make sure all connections are in accordance with the National Electrical Code and local regulations.
•To avoid possible electric shock, be sure the power supply is turned off before servicing or installing the fixture
•Service should be performed by qualified personnel.
•These instructions may not cover all details or variations. If additional information is needed, please contact Visa Lighting.
3" RECESSED
CV2424
1717 W Civic Drive, Milwaukee, WI 53209
414-354-6600
Design Modification Rights Reserved
© 2018 Visa Lighting
1
