Summary of Contents for Gude GSZ 500/1000
- Page 1 GSZ 500/1000 #01709 English GB Translation of original Operating Instructions ELECTRIC CABLE WINCH Please read carefully the Operating Instructions before using the electric winch © Güde GmbH & Co. KG - Birkichstrasse 6 - D-74549 Wolpertshausen - Deutschland...
- Page 3 Use as designated Warning/attention Keep safety distance GSZ 500/1000 Electric Cable Winch The cable winch given below has been exclusively designed for lifting fixed loads up to 990 kg (including guide pulley) and can be used for any housework or in free time.
- Page 4 • After you finish working with the appliance, pull the Appliance description (pic. 1 and 2) plug out of socket and check if the appliance is not damaged. Fixing clamp • If the appliance is not used store it to a dry place Hex screw inaccessible to children.
- Page 5 capacity specified by the producer in technical data must be professionally repaired or replaced in a and on the type label of the cable reel. customer service centre unless provided otherwise in • the Operating Instructions. Damaged switches must be Burdens fixed in conflict with regulations that could fall replaced in a customer service centre.
- Page 6 Burden lifting with a haul-back block Assembly and preparation Installation The limit switch does not work when the cable reel • When unpacking your cable reel, make sure the supply is operated with a haul-back block! Make sure the haul- includes all parts and check the state of the reel and back block does not arrive to the cable reel nearer than accessories if not faulty.
-
Page 7: Eu Declaration Of Conformity
(c)). with us the Declaration expires. 3. If the steel cable (m) is damaged (broken or tattered, see Marking of appliances: GSZ 500/1000 electric cable reel pic. 3) then replace it with an original spare cable. When Order No.:... - Page 8 Check List Dear Customer To prevent injuries and any material damage, the cable reel operator is obliged to keep the appliance in a working and proper state. The following Check List should be used as a basis for regular checks at intervals determined by the operator and also as documentation.
