- Page 1 Safetey at doors Assembly instruction GfS e-Bar® GfS – Gesellschaft für Sicherheitstechnik GmbH Tempowerkring 15 ∙ 21079 Hamburg ∙ Fon 040-79 01 95-0 ∙ Fax 040-79 01 95 11 ∙ info@gfs-online.com...
- Page 2 Safety at doors...
-
Page 3: Table Of Contents
6.2.0 Service protocol (installer) ............. . 30 This document has been produced with the utmost care. GfS does not guarantee the accuracy or completeness of the content of this documentation with respect to texts, pictures , references or information contained therein. -
Page 4: Safety Instructions
• the GfS e-Bar® may only be mounted horizontally on doors that open outwards • the GfS e-Bar® may only be used with approved panic locks and fittings (EN 1125) • the GfS e-Bar® should be cut to length as required according to the installation instructions •... -
Page 5: General Functions
Safety at doors 1.2.0 General functions Function GfS e-Bar® GfS e-Bar® GfS e-Bar® GfS e-Bar® mechanic mechanic with mechatronic mechatronic floating contacts with emergency exit switch 700 70* 700 71* 700 73* 700 74* Communicating display accoustic/visual For door leaf left/right Battery-powered (incl. -
Page 6: Local Alarm Types
While slightly pressing the GfS e-Bar® a red flashing light and an accous- Display: red tic alarm (95 dB A/1m) is emitted, which expires as soon as the GfS e- Bar® is released. The moment the pre-alarm turns into a permanent alarm can be adjusted with a little screw (see p. -
Page 7: Operation
By briefly turning the key clockwise the single release mode is triggered. The key needs to be turned by 90° and back. The impulse should be no longer than 1 sec. If a reed contact is installed the GfS e-Bar® will be left alarm secured the moment the door closes. -
Page 8: Mechanical Versions Of Gfs E-Bar
1. GfS e-Bar® mechanic This model is a push bar incl. a picto describing the operation of the GfS e-Bar®. Neither contacts nor electric functions are included. The GfS e-Bar® mechanic will be supplied in three different lengths, which might be shortened individually, in order to adjust the length to the width of the door. -
Page 9: Mechatronic Versions Of Gfs E-Bar
2. GfS e-Bar® with integrated alarm and emergency exit switch for opening electrically locked doors The GfS e-Bar with integrated emergency exit switch is operated at 10−30 V/DC which is either supplied by an external power supply or the FWS-02 (Emergency exit control unit). The integrated emergency exit switch with 2 opening contacts might be connected to the emergency exit control unit with a max. -
Page 10: Assembly
Safety at doors Assembly 2.1.0 Mounting instructions of GfS e-Bar® Countersunk screw M3 x 8 Clamping bolt Cylinder head screw M5 x 20 Lever arm Lever arm Lever arm While pressing the push bar profile 4 remove the cylinder head screw M5 x 20 1 . -
Page 11: Cut To Size With Tool Kit
ATTENTION: Do not use "lubricants and coolants" when shortening the mechatronic versions od the GfS e-Bar®. Metal chips must not stay in the GfS e-Bar®. Danger of short-circuit! After shortening insert the console 7 into the base profile. Place the shims 8 (0,8 mm thickness) between the console and the base profile. -
Page 12: Defining The Correct Length
Order lengths Max. shortening length Rule of thumb for defining the correct length: 970 mm 180 mm door inside width - 2x backset + 2x lockplate thickness + 30mm = GfS e-Bar® length 1130 mm 160 mm 1290 mm 160 mm... -
Page 13: Adjusting Main Alarm
Safety at doors 2.3.0 Adjust pre- and main alarm Screw to adjust alarm setting Hint: Pre-alarm is not adjustable (preset in the factory). tighten screw, alarm starts later loosen screw, alarm starts earlier Siren Dip switch 1– 8 Hall sensor for alarm Hall sensor for pre-alarm... -
Page 14: Changing The Cylinder
Safety at doors 2.4.0 Changing the cylinder Mounting European profile cylinder (PHZ) Mounting Swiss round cylinder (RZ) Use right drill holes Use left drill holes Battery holder Attention: Use European profile cylinder with lockable cam. Remove key, put cam on 180°! -
Page 15: Mounting On Wooden Doors
Safety at doors Mounting on wooden doors 2.5.0 (Metal cover plate 770 013 for wooden doors are not included in shipment) Hinge side Lockside Standard flat steel base plate Cover plate lock side Cover plate hinge side Thickness depending on escutcheon 3 mm, 4 mm, 6 mm) Counter sunk screw M4x8 (respect max. -
Page 16: Mounting On Metal Doors
Safety at doors 2.5.1 Mounting on metal doors Image A Drillings for suitable riveting nuts M5 Cylinder head screw M5 x12 Image B Detail X Attention: When assembling pay attention to the orientation of the socket. Cam has to show downwards shoulder bolt M4 x 4... -
Page 17: Mounting In Combination With Security Escutcheon (4Mm)
Counter sunk screw M4x8 (respect max. length of screw) Ø 1 Cylinder head screw wood screw ø 5 x 25 Drillings for suitable riveting nuts M5 Escutcheon for GfS e-Bar® Ø 1 Cylinder head screw M5 x 25 Escutcheon for GfS e-Bar®... -
Page 18: Battery Operation/Mains Supply - Wiring Of Gfs E-Bar
Safety at doors 2.6.0 Battery operation/mains supply – wiring of GfS e-Bar® Installation without cables Installation with cables Cable must be fixed with cable tie Plug with jumper. Only necessary for battery operation. Remove plug when mains supply. Connection cable 12-wires with tie GfS Art. -
Page 19: Assembly Of Gfs E-Bar
Safety at doors 2.7.0 Assembly of GfS e-Bar® Clamping bolts Lever arm Cylinder head screw M5 x 20 Lever arm Lock side hinge side Soft counter pressure Sunk screw M3 x 8 Lift the lever arms 1 up to its maximum. Hold the lever arm with one hand and pull the push bar profile 2 from the hinge side on the clamping bolt 3 until the push bar profile is engaged. -
Page 20: Placing The Stickers
Placing the stickers left right IN CASE OF EMERGENCY EMERGENCY EXIT – ALARM PROTECTED PUSH TO OPEN www.gfs-online.com IN CASE OF EMERGENCY IN CASE OF EMERGENCY EMERGENCY EXIT – ALARM PROTECTED EMERGENCY EXIT – ALARM PROTECTED PUSH TO OPEN PUSH TO OPEN www.gfs-online.com... -
Page 21: Electrical Connection
Safety at doors Electrical connection 3.1.0 Terminal board GfS e-Bar® 700 71x Clamp Signal Wire colour Function Relay 1: Pre-alarm Relay 1: Pre-alarm Relay 1: Pre-alarm Relay 2: Main-alarm Relay 2: Main-alarm Relay 2: Main-alarm 17/18 External key switch message out... -
Page 22: Terminal Board Gfs E-Bar® 700 73X
Safety at doors 3.1.1 Terminal board GfS e-Bar® 700 73x Clamp Signal Color Function white External door reed contact, recommended otherwise jumper (1-2) black Mains supply GND brown DIP 8 OFF: DIMM at 10% luminiscence (prgrammable see page) DIP 8 ON: Radar triggered pre-alarm... -
Page 23: Terminal Board Gfs E-Bar® 700 74X
Safety at doors 3.1.2 Terminal board GfS e-Bar® 700 74x... -
Page 24: Wiring Diagram Gfs E-Bar® 700 71X
Safety at doors 3.2.0 Wiring diagram GfS e-Bar® 700 71x Cable with 6 wires LIYY 6 x 0,14 External key switch 17/18 Key switch message (out) 19/20 Key switch wiring (in) Connection Pre- and Main-alarm GfS e-Bar® 70071x Floating contact... -
Page 25: Wiring Diagram Gfs E-Bar® 700 73X
Safety at doors 3.2.1 Wiring diagram GfS e-Bar® 700 73x Important: All input contacts are 0V shortcut to ground without reed contact put jumper on 1–2 black GND – Mains supply GND 10–30 V/DC + Mains supply (plus terminal) 10 – 30 V/DC... -
Page 26: Wiring Diagram Gfs E-Bar® 700 74X
Safety at doors 3.2.2 Wiring diagram GfS e-Bar® 700 74x without reed contact Important: All input contacts are 0 V shortcut to ground put jumper on 1–2 black GND – Mains supply GND 10–30 V/DC + Mains supply (plus terminal) 10 – 30 V/DC... -
Page 27: Gfs E-Bar® Settings
4.1.3 Switching color green/red When working with mains supply it is up to the operator/dealer to define the color code of the GfS e-Bar®. The following steps have to be taken: • Switch-off the power supply of the GfS e-Bar® and remove the battery. Wait for 10 sec. -
Page 28: Technical Data
2 m cable, Reed contact surface or flush mounted (Art-No. 930 110/930 210) External connection cable for GfS e-Bar® GfS e-Bar® 70071x/70073x 12 wires, 12 x 0,14 LIYY (Art. No. 770 719) GfS e-Bar® 700 74x... -
Page 29: Documentation
Safety at doors Documentation 6.1.0 Service protocol (operator) GfS e-Bar® ______________________________________________________________________________________________ Building ________________________________________________________________________________________________ Manufacturer of lock/lock type ______________________________________________________________________________ Panic function E-SV B-SV The installation was done properly. Lock, lock plate and door hardware form a system acc. to EN 1125 The system has been tested and works properly The door can be unlocked with little effort (<... -
Page 30: Service Protocol (Installer)
Safety at doors Documentation 6.1.0 Service protocol (installer) GfS e-Bar® ______________________________________________________________________________________________ Building ________________________________________________________________________________________________ Manufacturer of lock/lock type ______________________________________________________________________________ Panic function E-SV B-SV The installer has informed the operator of the following: Function and use Resetting the alarm Special functions Possibility to transmit the alarm to a central display... - Page 31 Safety at doors...
