GFS e-Bar 700 71 Series Assembly Instruction Manual
Safe emergency exit
Hide thumbs
Also See for e-Bar 700 71 Series:
- Assembly instruction manual (20 pages) ,
- Assembly instruction manual (32 pages)
Related Manuals for GFS e-Bar 700 71 Series
Summary of Contents for GFS e-Bar 700 71 Series
- Page 1 Safety at doors Assembly instruction GfS e-Bar® GfS – Gesellschaft für Sicherheitstechnik GmbH Tempowerkring 15 ∙ 21079 Hamburg ∙ Fon 040-79 01 95-0 ∙ Fax 040-79 01 95 11 ∙ info@gfs-online.com...
-
Page 3: Table Of Contents
1.3.0 Functions of GfS e-Bar® 730 73x/700 74x – Local alarm types ...... -
Page 4: Safety Information
1.1.0 Safety information The GfS e-Bar® is certified according to EN 1125 and EN 1634 and meets highest quality and safety standards. In order to keep the GfS e-Bar® operational the door must be in a perfect state during and after installation. -
Page 5: General Functions
Integrated emergency exit switch Changing display to green/red GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 6: Functions Of Gfs E-Bar® 730 73X/700 74X - Local Alarm Types
As soon as the door is closed the alarm expires. GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 7: Functions Of Gfs E-Bar® 730 73X/700 74X - Operation
2. GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 8: Versions Of Gfs E-Bar® - Mechanical
This model is a push-.bar with floating contacts to generate information on the usage of the push bar. The items will be delivered with a picto describing the operation of the GfS e-Bar®. The GfS e-Bar® mechanic will be supplied in three different lengths, which might be shortened individually, in order to adjust the length to the width of the door. -
Page 9: Versions Of Gfs E-Bar® Mechatronic
The battery control function checks every 10 hours the voltage. If the voltage drops below 7V, all 60 seconds an acoustic alarm is emitted. The battery has to be exchanged. When battery operated the GfS e-Bar® works in an energy saving mode which basically means that the green LEDs of the display are switched off. -
Page 10: Assembly
4 from the clamping bolt in opposite direction 7a . GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 11: Cut To Size With Tool Kit
ATTENTION: Do not employ "lubricants and ccolants" when shortening the mechatronic versions od the GfS e-Bar®. Metal chips must not stay in the GfS e-Bar®. Danger of short-circuit! After shortening insert the console 7 into the base profile. Place the shims 8 (0,8mm thickness) between the console and the base profile. -
Page 12: Defining The Correct Length
Forend plate length Distance Front plate shape Backset GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 13: Adjust Pre- And Main Alarm
3 minutes till reset is done GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 14: Change The Cylinder
Just remove key, put cam on 180°! GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 15: Mounting On Wooden Door With Escutecheon Furniture
Cam has to show downwards Shoulder bolt M4 x 4 GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 16: Mounting On Metal Door
Cam has to show downwards shoulder bolt M4 x 4 GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 17: Mounting In Combination With Security Escutcheon (4Mm)
Cylinder head screw M5 x 25 Escutcheon for GfS e-Bar® GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 18: Battery Operation/Mains Supply Wiring Of Gfs E-Bar
Connection cable 12-wires with tie GfS Art.-No.: 770 719 GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 19: Assembly Of Gfs E-Bar
Mechanic versions: Fix cover hoods with M5x8 cylinder head screws (like lock side). GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 20: Placing The Stickers
PUSH TO OPEN PUSH TO OPEN www.gfs-online.com www.gfs-online.com GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 21: Electrical Connection
Input contact contact Closed- COMMON circuit contact GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 22: Mechatronic
1 2 3 4 5 6 7 8 9 10 11 12 Incoming Opener Connection COMMON Shutter GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 23: Mechatronic With Emergency Exit Switch
FWS 02 operation with GfS e-Bar® 700 74x GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 24: Gfs E-Bar® 700 71X
(see page 21) 30 V/300 mA Main-alarm GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 25: Gfs E-Bar® 700 73X
(only GfS e-Bar® 700 74x) GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 26: Gfs E-Bar® 700 74X For Electrically Locked Emergency Exits
(only GfS e-Bar® 700 74x) GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 27: Switching Color To Green Or Red
Switching color codes of GfS e-Bar® When working with mains supply it is up to the operator/dealer to define the color code of the GfS e-Bar®. The following steps have to be taken: • Switch-off the power supply of the GfS e-Bar® and remove the battery. Wait for 10 sec. -
Page 28: Technical Data
Alarm activation delay in EECU mode Attention: The code switch has to be positioned on “0”. When releasing the GfS e-Bar® with a key switch, a signal is sent to the EECU, which releases the magnet. After 15 sec. the magnet will be activated again (or when closing the door again). Therefore another external reed contact on the door is required. -
Page 29: Service Protocol (Operator)
The system has been verified and approved City, Date Company (stamp) Signature GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... -
Page 31: Service Protocol (Installer)
– Visual check (at least 1 per month) City, Date Company (stamp) Signature GfS – Gesellschaft für Sicherheitstechnik mbH · Tempowerkring 15 · 21079 Hamburg Tel. +49 40 - 79 01 95 0 · Fax +49 40 - 79 01 95 11 · info@gfs-online.com · www.gfs-online.com... - Page 32 Safety at doors GfS – Gesellschaft für Sicherheitstechnik GmbH Tempowerkring 15 ∙ 21079 Hamburg ∙ Fon 040-79 01 95-0 ∙ Fax 040-79 01 95 11 ∙ info@gfs-online.com...
