FX-DIS Local Controller Display
Technical Bulletin
Document Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Related Documentation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Local Controller Display on the Sensor Actuator (SA) Bus. . . . . . . . . . . . . . . . . . . . 5
Local Controller Display Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Local Controller Display Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Local Controller Display Operation Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Local Controller Display Menu Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Description of Local Controller Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Local Controller Display Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Diagnostic Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Controller Information Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Idle/Favorites Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Password Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Change Password Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Data Refresh Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Detailed Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Entering a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing the Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Displaying Configured Input and Output Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Commanding Configured Input and Output Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Displaying Configured Parameters and Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Commanding Configured Parameters and Setpoints . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Displaying Overridden Points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Viewing and Setting Display Information Preferences. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the Backlight Intensity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
FX-DIS Local Controller Display Technical Bulletin
Code No. LIT-12011666
Issued March 22, 2019
Supersedes April 12, 2011
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FX-DIS1710-0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Johnson Controls FX-DIS1710-0

Summary of Contents for Johnson Controls FX-DIS1710-0

  • Page 1: Table Of Contents

    FX-DIS Local Controller Display Technical Bulletin Code No. LIT-12011666 FX-DIS1710-0 Issued March 22, 2019 Supersedes April 12, 2011 Document Introduction ..........3 Related Documentation.
  • Page 2 Setting the Backlight Timeout ..........23 Selecting a Date Format Preference .

  • Page 3: Document Introduction

    Document Introduction This document describes how to operate and troubleshoot the Facility Explorer Local Controller Display (FX-DIS1710-0). The display module is a local user interface for the Facility Explorer Programmable Variable Air Volume (VAV) Box Controllers (FX-PCVs) and Facility Explorer General Purpose Programmable Controllers (FX-PCGs) that do not have an integral display.

  • Page 4: Related Documentation

    FX-DIS Local Controller Display LIT-12011667 Applications of the FX-DIS1710 Product Bulletin Installation and Specifications FX-DIS Local Controller Display Part No. 24-10240-17 of the FX-DIS1710-0 Installation Instructions Commissioning, Uploading, and Controller Tool Help LIT-12011147 Downloading the FX-DIS1710 Specifications of the Facility...

  • Page 5: Local Controller Display On The Sensor Actuator (Sa) Bus

    Local Controller Display on the Sensor Actuator (SA) Bus The Local Controller Display is an optional accessory to an FX-PCG and FX-PCV that provides a user interface to the device. The display installs on the front door of the panel that houses the controller and is connected to the SA Bus. Figure 1 shows an example network of FX-PC controllers with Local Controller Displays.
  • Page 6 Figure 2 shows the dimensions, and Figure 3 shows the physical features of the Local Controller Display. The same general design features also to apply FX controller models that have a built-in display. Front View Back View 9-1/16 9-3/8 3-3/8 2-1/2 Depth 26 SA Bus...

  • Page 7: Local Controller Display Keypad

    Local Controller Display Keypad The Local Controller Display has six keys that are used to navigate the menu structure (Figure 4): Up/Down Arrows Escape Left/Right Arrows Enter Figure 4: Local Controller Display Keypad • Up/Down Arrows ( ) move the highlighted field up or down on the current display, or within a menu.

  • Page 8: Local Controller Display Configuration

    Local Controller Display Configuration FX-PC controllers with a local display, or controllers with the remote stand-alone display, are configured with CCT. The CCT provides a Configure Display menu option that allows you to: • define which points appear on the display pages (Input/Output View, Parameter/Setpoint View, and Idle View) and in which order •...

  • Page 9: Local Controller Display Menu Structure

    Local Controller Display Menu Structure Figure 5 is a flowchart of the menu structure for the Local Controller Display. The menu selections are described in the sections that follow. Controller Startup Diagnostic Pages Controller Information Page Idle Page Enter/ Password Enter Entry Page Password...

  • Page 10: Description Of Local Controller Display

    Description of Local Controller Display The pages that you access from the display’s Main Menu share a common layout and theme. For example, all pages have a page title and a scroll bar used to navigate the page. In addition, all pages support four lines of text. The common areas of the screens are shown in Figure 6.

  • Page 11: Local Controller Display Pages

    When the controller is powered on, the screen sequences through four pages, as shown in Figure 7. If a problem is detected during startup, the screen indicates the error condition. If the controller is missing an application, the Johnson Controls screen remains showing with the message Application Download Required. If an application is present, the startup sequence completes and the Controller Information page appears (Figure 8).

  • Page 12: Controller Information Page

    Controller Information Page The Controller Information page displays general information about the controller, such as the device name and firmware version (Figure 8). This page appears for about 8 seconds, then the Idle/Favorites Page appears (Figure 9). If the controller has not yet been commissioned by CCT, the display remains on the Controller Information page.

  • Page 13: Password Page

    When more than four points are configured for the Idle page, the points list scrolls vertically down the page one line at a time. You can scroll the page one item at a time by using the up and down arrow keys or scroll the page four items at a time by using the left and right arrow keys.

  • Page 14: Change Password Page

    Change Password Page Once logged on, you can change your password by accessing the Change Password page. The process involves entering, confirming, then saving the new password. The password can be from one to 32 characters in length, all uppercase alphanumeric characters.

  • Page 15: Detailed Procedures

    Detailed Procedures Entering a Password To enter a password: Note: The password entry page is available only if a password was enabled when the Display Configuration was set with CCT. Otherwise, the display menus are accessible without a password entry. 1.
  • Page 16 4. Select the Enter a new password option. The New password entry page appears (Figure 14). Asterisks appear ABCDEFGHI JKLMNOPQRS in place of typed TUVWXYZ 0123456789 characters. Backspace Accept Cancel Figure 14: New Password Page 5. Use the arrow keys to select each character of your new password, and press Enter to submit each character.

  • Page 17: Displaying Configured Input And Output Points

    Note: You can also change your password using CCT. The new password is effective after you download the application to the controller using  CCT. Displaying Configured Input and Output Points To display configured input and output points: 1. Go to the Main Menu. 2.

  • Page 18: Displaying Configured Parameters And Setpoints

    5. Press Enter to display the commands available for this point. Figure 20 shows an example for an analog point. Command Adjust Override Release Figure 20: Command Page 6. Select a Command and press Enter. The Adjust page appears (Figure 21). For analog points, use the left and right arrow keys to position the cursor to a desired digit location.

  • Page 19: Commanding Configured Parameters And Setpoints

    4. For more details on a particular item, select the item and press Enter. The Focus page for the item appears. Figure 23 is an example for the Occupancy Schedule. OCC-SCHEDULE Occupied Reliability Reliable Out of Service False Command Cancel Figure 23: Occupancy Schedule Page 5.

  • Page 20: Displaying Overridden Points

    6. Select a Command and press Enter. The Adjust page appears (Figure 25). For analog points, use the left and right arrow keys to position the cursor to a desired digit location. Then, use the up/down arrow keys to increment and decrement a value.

  • Page 21: Viewing And Setting Display Information Preferences

    4. To display the Focus page for a particular point, select the point and press Enter. The Focus page for the point appears, which also allows you to command the point (for example, release the override). (See Figure 20 for the available commands.) Figure 27 is an example for a zone setpoint in override.
  • Page 22 Table 4: Display Information Preferences (Part 2 of 2) Parameter Description Selections 1 minute, 5 minutes, 15 minutes,  Idle Page Defines how long the Timeout display waits between 30 minutes, 1 hour, No Timeout keyboard interactions before logging off the user. Language Displays the configured (Not configurable)...

  • Page 23: Setting The Backlight Intensity

    Setting the Backlight Intensity To set the backlight intensity: 1. Go to the Main Menu. 2. Scroll down to select the Display Information option and press Enter. 3. Scroll down to select the Backlight Intensity parameter and press Enter. The Modify page appears.

  • Page 24: Selecting A Date Format Preference

    Selecting a Date Format Preference To select a date format preference: 1. Go to the Main Menu. 2. Scroll down to select the Display Information option and press Enter. 3. Scroll down to select the Date Format Pref. parameter and press Enter. The Modify page appears.

  • Page 25: Setting The Display Contrast

    Setting the Display Contrast To set the display contrast: 1. Go to the Main Menu. 2. Scroll down to select the Controller Information option and press Enter. 3. Scroll down to select the Display Contrast parameter and press Enter. The Modify page appears.

  • Page 26: Selecting The Time Format Preference

    Selecting the Time Format Preference To select a time format preference: 1. Go to the Main Menu. 2. Scroll down to select the Display Information option and press Enter. 3. Scroll down to select the Time Format Preference parameter and press Enter. The Modify page appears.

  • Page 27: Displaying Controller Information

    Displaying Controller Information To display controller information: 1. Go to the Main Menu. 2. Scroll down and select the Controller Information option. 3. Scroll down to view each line of controller information. Table 5 lists the type of information available. None of these attributes can be modified from the display, but some are defined when the application is configured using ...

  • Page 28: Technical Specifications

    507 E. Michigan Street, Milwaukee, WI 53202 Metasys® and Johnson Controls® are registered trademarks of Johnson Controls. All other marks herein are the marks of their respective owners. © 2019 Johnson Controls. FX-DIS Local Controller Display Technical Bulletin Published in U.S.A.
