Toyota Scion tC 2005 Wiring Diagram page 182

System Outline
When the ignition SW is turned to ACC position the current from the ACC fuse flows to TERMINAL 6 of the shift lock control
ECU. When the ignition SW is turned to ON position, the current from the ECU–IG fuse flows to TERMINAL 1 of the shift lock
control ECU.
1. Shift Lock Mechanism
If the brake pedal is depressed with the ignition SW set at ON (The stop light SW is on), the shift lock control ECU is
activated, allowing the driver to change the shift lever to a position other than the P position.
2. Key Interlock Mechanism
With the ignition SW at ON or ACC position, when the shift lever is put in P position, the current flowing from TERMINAL 12
of the shift lock control ECU to key interlock solenoid is cut off. This causes the key interlock solenoid to turn off (Lock lever
disengages from LOCK position) and the ignition key can be turned from ACC to LOCK position.
Service Hints
S6 Shift Lock Control ECU
6–Ground : Approx. 12 volts with the ignition SW at ACC or ON position
1–Ground : Approx. 12 volts with the ignition SW at ON position
8–Ground : Always continuity
7–Ground : Approx. 12 volts with the brake pedal depressed
: Parts Location
Code See Page
J1 A 35
J2 B 35
J6 35
: Junction Block and Wire Harness Connector
Code See Page
1B 24
1D 24
1S 25
: Ground Points
Code See Page
IF 40
IH 40
Code
J9
S6
S8
Junction Block and Wire Harness (Connector Location)
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel) Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
Ground Points Location
Cowl Brace LH
Cowl Brace RH
2005 SCION tC (EWD572U)
See Page
35
35
35
Code See Page
U1 35
121
