Summary of Contents for Viega Eco Plus 8169.2
- Page 1 Viega Eco Plus fixing element Instructions for Use for a barrier-free pre-wall installation Model Year built: 8169.2 from 07/2011 en_INT...
- Page 2 Viega Eco Plus fixing element 2 from 10...
-
Page 3: Table Of Contents
Labelling of notes About this translated version Product information Intended use 2.1.1 Areas of use Product description 2.2.1 Overview Handling Assembly information 3.1.1 Installation dimensions 3.1.2 Required tools Assembly 3.2.1 Mounting fixing element Disposal Viega Eco Plus fixing element 3 from 10... -
Page 4: About These Instructions For Use
This restriction does not extend to possible operating instructions. The installation of Viega products must take place in accordance with the general rules of engineering and the Viega instructions for use. -
Page 5: About This Translated Version
German/European guidelines in this manual: The information is not binding for other countries and territories and should, as mentioned, be considered as support. Viega Eco Plus fixing element 5 from 10... -
Page 6: Product Information
Product information 2 Product information Intended use 2.1.1 Areas of use The Viega Eco Plus fixing element is used for fixing supporting handles onto the following Viega Eco Plus WC elements: Model 8108.1 Model 8161.18 Model 8161.2 Model 8161.21 Model 8161.95 Product description 2.2.1... - Page 7 Product information 7 - fixing screws, short 8 - grub screws 9 - Frame fixing Viega Eco Plus fixing element 7 from 10...
-
Page 8: Handling
Installation dimensions Fig. 2: Dimensions model 8169.2 3.1.2 Required tools The following tools are required for mounting: drill with 10 mm drill bit fork or ring spanner: 17 mm Allen key: 6 mm Viega Eco Plus fixing element 8 from 10... -
Page 9: Assembly
Push the screwed end into the upper fixing hole. Push the fixing element as far as it will go against the WC element. Screw in and tighten fixing screw at the top and grub screw at the bottom. Viega Eco Plus fixing element 9 from 10... -
Page 10: Disposal
Repeat mounting steps for the left-hand side. Disposal Separate the product and packaging materials (e. g. paper, metal, plastic or non-ferrous metals) and dispose of in accordance with valid national legal requirements. Viega Eco Plus fixing element 10 from 10...
