E-SL 450BD Series
INSTRUCTION MANUAL
*Estate Swing's unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your
feedback.
Advertisement
Table of Contents
Related Manuals for Estate Slide E-SL 450BD Series
Summary of Contents for Estate Slide E-SL 450BD Series
- Page 1 Exercise caution at all times and stay clear of the system support@estateswing.com during operation. E-SL 450BD Series INSTRUCTION MANUAL *Estate Swing’s unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your...
- Page 2 Estate Slide Summary of Functions The Estate Slide is only to be used for vehicular Slide gates in a Class I setting. Class I: A vehicular gate opener (or system) intended for use in a home of one-to-four single family dwelling, or a garage or parking area associated therewith.
- Page 3 Gate Leaf Max Weight (lbs.) Up to 450 Type of Limit Switch Magnetic Estate Swing Parts Included: A) Two Remotes E) Belt B) Transformer F) Motor C) two Limit G)Control box Magnet H)control board D) Release Keys E-SL 450BD Series Instruction Manual...
-
Page 4: Important Preliminary Checks
The system display below is a recommended standard system. Other approved accessories can be in- stalled. Photo sensors and a flashing light indicating gate movement is recommended for safety purposes. 1) Estate Slide Operator 2) Photocells (not included) 3) Key operated pushbutton (not included) 4) Flashing lamp (not included) 5) Radio receiver (optional) NOTES:... -
Page 5: Tools Needed For Installation
• Depending on the current base, you may need cement to form a level mounting pad. • A voltage meter may be necessary to run diagnostic checks. • A digital camera will come in handy with technicians if any support is needed. E-SL 450BD Series Instruction Manual... -
Page 6: Manual Operation
2. Lift the lever to disengage the gears. 3. The motor will not run again until the motor is relocked. There is a magnetic sensor that allows the motor to operate, be sure the magnet is lined up with the sensor. E-SL 450BD Series Instruction Manual... - Page 7 Concrete Slab Tips: Creating a wood rectangle with no top is a good way to form a slab. After the cement dries the wood can be knocked away. The slab must be secured to the ground below. Having rebar pass into the slab works well. E-SL 450BD Series Instruction Manual...
- Page 8 Feed any wires up through the opener while installing the opener to the base. E-SL 450BD Series Instruction Manual...
-
Page 9: Installation Of Motor
The flat side with a single hole should be facing in toward the center of the gate. On one side of the gate lay the belt into the belt attachment bracket so the teeth of the belt mesh the teeth of the bracket. E-SL 450BD Series Instruction Manual... - Page 10 Make your final tightening adjustments on the belt. The belt should not have excessive sag in it (no more than 2 inch variance from furthest bracket to opener). To tighten the belt after mounting, move the nuts on the belt attach- ment bolt. E-SL 450BD Series Instruction Manual...
- Page 11 Example: In the photo the gate is picket style, in this case we would use self tapping metal screws to attach the bar to the pickets. Then we would paint the flat bar black. E-SL 450BD Series Instruction Manual...
- Page 12 Wiring operator magnet magnet E-SL 450BD Series Instruction Manual...
- Page 13 Two 12V DC batteries (min 5 a/h per battery) may be run in series as backup to the 24V transformer power. When you install new batteries - manually open the gate and allow the batteries to charge for 24 hours through the system before using the gate opener. E-SL 450BD Series Instruction Manual...
- Page 14 IMPORTANT: We recommend before turning the gate opener on for the first time to have dip switch 1 OFF. If the dip switch is set to on, the gate will auto-reclose after turning it on without any intentional activation on your part. E-SL 450BD Series Instruction Manual...
-
Page 15: First Run
Manually unlock the gate, then move it half-way and re-engage. Activate using Push 1 button (as shown above) The gate should run open. Press Push 1 again and it should run closed. The gate is now set up for regular usage. E-SL 450BD Series Instruction Manual... - Page 16 LED shows P6: P6 is the delay for automatic re-close from the open position – this op-tion needs to be turned on using the dip switch on the board. The options are 0-99 sec-onds. E-SL 450BD Series Instruction Manual...
- Page 17 Press and hold one of the four buttons on the remote until the light on the receiver will turn off. Once the light turns off the remote and receiver are now synced. E-SL 450BD Series Instruction Manual...
-
Page 18: Control Board Overview
When closing - momentary contact will stop the gate. When stopped mid cycle - momentary contact will open the gate. When open with auto-reclose off - momentary contact will have no effect. When closing - momentary contact will re-open the gate. E-SL 450BD Series Instruction Manual... - Page 19 When closing - momentary contact will re-open the gate. PUSH 1 and PUSH 2 – these terminals can hold as many normally open connections as needed, they will be wired in parallel. They are used for keypads, push buttons, universal receivers, etc. E-SL 450BD Series Instruction Manual...
- Page 20 E_Lock: Solenoid lock output - 12VDC (4 Amp max) A = Positive B = Negative Fuses: F1 = 8A 250V, protects motor 1 F2 = 8A 250V, protects motor 2 F3 = 2A 250V, protects accessory output +24V E-SL 450BD Series Instruction Manual...
- Page 21 If the gate(s) obstructs 3 times in a row the gate(s) will go into a hard shutdown mode and a buzzer alarm will sound. At this point no accessories or remotes will be able to activate the gate opener until the gate opener is reset by disconnecting primary power bat-tery. E-SL 450BD Series Instruction Manual...
- Page 22 Below is an example of a control board picture that we will be looking for: E-SL 450BD Series Instruction Manual...
-
Page 23: Accessories Wiring
24V Power positive (+) or (24V) or (PWR) of exit device = +24V terminal of PHOTO block on gate opener control board. 24V Power Negative (-) or (GND) or (PWR) or Shield wire of exit device = GND terminal of PHOTO block on gate opener control board. E-SL 450BD Series Instruction Manual... - Page 24 Connect positive lead of the power supply directly to the positive lead of the mag lock. Connect negative lead of the power supply to the N/C terminal of the relay. Connect the COM terminal of the relay to the negative lead of the mag lock. 2.0.0 9.19 E-SL 450BD Series Instruction Manual...
