Estate Slide E-SL 450BD Series Instruction Manual

Hide thumbs Also See for E-SL 450BD Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
USER DRIVEN MANUAL*
—WARNING—
Read all instructions before beginning installation or use of
Any feedback, changes, or advice we are
this gate opener. This operator exerts a high level of force.
glad to hear it. Please contact us at
Exercise caution at all times and stay clear of the system
support@estateswing.com
during operation.
E-SL 450BD Series
INSTRUCTION MANUAL
*Estate Swing's unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your
feedback.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-SL 450BD Series and is the answer not in the manual?

Questions and answers

Related Manuals for Estate Slide E-SL 450BD Series

Summary of Contents for Estate Slide E-SL 450BD Series

  • Page 1 Exercise caution at all times and stay clear of the system support@estateswing.com during operation. E-SL 450BD Series INSTRUCTION MANUAL *Estate Swing’s unique user driven manuals are constantly updated by installers and homeowners like yourself. We improve by hearing and applying your...
  • Page 2 Estate Slide Summary of Functions The Estate Slide is only to be used for vehicular Slide gates in a Class I setting. Class I: A vehicular gate opener (or system) intended for use in a home of one-to-four single family dwelling, or a garage or parking area associated therewith.
  • Page 3 Up to 14 Gate Leaf Max Weight (lbs.) Up to 450 Type of Limit Switch Magnetic Estate Swing Parts Included: A) Two Remotes E) Battery B) Transformer F) Belt C) Limit Magnet G) Motor D) Release Keys E-SL 450BD Series Instruction Manual...

  • Page 4: Important Preliminary Checks

    The system display below is a recommended standard system. Other approved accessories can be in- stalled. Photo sensors and a flashing light indicating gate movement is recommended for safety purposes. 1) Estate Slide Operator 2) Photocells (not included) 3) Key operated pushbutton (not included) 4) Flashing lamp (not included) 5) Radio receiver (optional) NOTES:...

  • Page 5: Tools Needed For Installation

    • Depending on the current base, you may need cement to form a level mounting pad. • A voltage meter may be necessary to run diagnostic checks. • A digital camera will come in handy with technicians if any support is needed. E-SL 450BD Series Instruction Manual...

  • Page 6: Manual Operation

    2. Lift the lever to disengage the gears. 3. The motor will not run again until the motor is relocked. There is a magnetic sensor that allows the motor to operate, be sure the magnet is lined up with the sensor. E-SL 450BD Series Instruction Manual...
  • Page 7 Concrete Slab Tips: Creating a wood rectangle with no top is a good way to form a slab. After the cement dries the wood can be knocked away. The slab must be secured to the ground below. Having rebar pass into the slab works well. E-SL 450BD Series Instruction Manual...
  • Page 8 Feed any wires up through the opener while installing the opener to the base. E-SL 450BD Series Instruction Manual...

  • Page 9: Installation Of Motor

    The flat side with a single hole should be facing in toward the center of the gate. On one side of the gate lay the belt into the belt attachment bracket so the teeth of the belt mesh the teeth of the bracket. E-SL 450BD Series Instruction Manual...
  • Page 10 Make your final tightening adjustments on the belt. The belt should not have excessive sag in it (no more than 2 inch variance from furthest bracket to opener). To tighten the belt after mounting, move the nuts on the belt attach- ment bolt. E-SL 450BD Series Instruction Manual...
  • Page 11 Example: In the photo the gate is picket style, in this case we would use self tapping metal screws to attach the bar to the pickets. Then we would paint the flat bar black. E-SL 450BD Series Instruction Manual...
  • Page 12 (OFF). If auto reclose is on from the chart above adjust the time on the potentiometer (seen below) Clockwise is a longer pause time. E-SL 450BD Series Instruction Manual...
  • Page 13 Contact between the two lead wires, even for a second, will destroy the transformer. Transformers are only warranted if the internal fuse is not blown. If the fuse is blown an outside factor (shorting, surge, water, etc) has caused the transformer not to function. E-SL 450BD Series Instruction Manual...

  • Page 14: Temporary Safety Jumpers

    If the gate will only open and will not close - the safety jumper is not making a con- nection between the two terminals. Even with a jumper in place, sometimes metal or wire loses its conductivity for various reasons. Please try to replace this jumper and see if the problem is resolved. E-SL 450BD Series Instruction Manual...
  • Page 15 Note: If your gate moves further closed instead of open: the motor side is incorrect. • Remove battery and transformer power. • Change dip switch number 3 to the opposite position it is currently on. • Reapply power and begin programming again. E-SL 450BD Series Instruction Manual...
  • Page 16 3. Press and hold the button you have chosen for Full Open / Close on a remote until the LEARN LED light goes out. 4. Repeat with other remotes. Erasing All Transmitters: Press and hold LEARN button until the LEARN LED flashes. You will then have to repro- gram all remotes back in. E-SL 450BD Series Instruction Manual...

  • Page 17: Control Board Overview

    • OPEN/CLOSE/GND: OPEN and GRD is used for normally open devices you would like to only open the gate from the closed position. CLOSE and GND is used for normally open devices you would like to only close the gate from the open position. Continue on next Page E-SL 450BD Series Instruction Manual...
  • Page 18 • +24V: This terminal puts out a constant 24V DC current for the receiver. • PUSH BUTTON: Opens and Closes the gate. • OPEN BUTTON: Opens the gate from the closed position. • CLOSED BUTTON: Used for programming and testing. • LEARN BUTTON: Used for programming remotes. E-SL 450BD Series Instruction Manual...
  • Page 19 Below is an example of a control board picture that we will be looking for: E-SL 450BD Series Instruction Manual...

  • Page 20: Accessories Wiring

    24V Power positive (+) or (24V) or (PWR) of exit device = +24V terminal of gate opener control board. 24V Power Negative (-) or (GND) or (PWR) or Shield wire of exit device = GND terminal of gate opener control board. E-SL 450BD Series Instruction Manual...
  • Page 21 Connect positive lead of the power supply directly to the positive lead of the mag lock. Connect negative lead of the power supply to the N/C terminal of the relay. Connect the COM terminal of the relay to the negative lead of the mag lock. E-SL 450BD Series Instruction Manual...
