Golvo™ 9000
mobile lift
Service Manual
Product No.
2000045
Golvo™ 9000
2000049
Golvo™ 9000 LowBase
Golvo™ 9000 mobile lift
3EN400405 Rev. 2
ENGLISH
Golvo™ 9000 LowBase mobile lift

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Golvo 9000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Liko Golvo 9000

  • Page 1 Golvo™ 9000 mobile lift Service Manual Product No. 2000045 Golvo™ 9000 2000049 Golvo™ 9000 LowBase Golvo™ 9000 mobile lift Golvo™ 9000 LowBase mobile lift 3EN400405 Rev. 2 ENGLISH...
  • Page 2 Components (manufacturing parts) are not available after last manufacturing date. Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. For information regarding Service and Maintenance education, contact your Hill-Rom representative. For contact information please visit our website: www.hill-rom.com...
  • Page 3: Table Of Contents

    Table of Contents Golvo™ 9000 mobile lift Page Technical Data 1.1 Dimensions ............ 4 1.2 Technical Data ..........5 2.0 Troubleshooting ............. 6 3.0 Spare Parts Positions ............. 7 4.0 Spare Parts Assembly information ........ 8 Spare Parts List .............. 9 Service, Control Unit Jumbo Care ........ 14 7.0 Periodic Inspection Information ........
  • Page 4: Dimensions

    Model L max L min Model L max L min max. min. max. min. max. min. max. min. max. min. max. min. Golvo 9000 2090 1455 1185 1020 1100 1816 Golvo 9000 2090 1455 1185 1020 1100 1860 Golvo 9000...
  • Page 5: Technical Data

    Rear: 75 mm (3 in) twin wheels with brakes. Battery charger: Internal charger, 100-240 V AC, 50-60 Hz, Turning diameter Golvo 9000: 1330 mm (52 in) max 400 mA. Golvo 9000 LowBase: 1330 mm (52 in) Lift motor: 24 V, 7.5 A...
  • Page 6: Troubleshooting

    Delay! A delay to indicators for current battery power at the control box and hand control occurs if the Follow information to the right. emergency stop function is activated and restored Service Manual Golvo™ 9000 • 3EN400405 Rev. 2 www.liko.com www.hill-rom.com mobile lift...
  • Page 7: Spare Parts Positions

    3.0 Spare Parts positions, Golvo™ 9000 mobile lift Spare Parts Positions Golvo™ 9000 mobile lift Spare Parts PROD. NO. PRODUCT 2000045 Golvo 9000 2000049 Golvo 9000 LowBase kg/lbs Service Manual Golvo™ 9000 • 3EN400405 Rev. 2 www.liko.com www.hill-rom.com mobile lift...
  • Page 8: Spare Parts Assembly Information

    - Make sure the spare part is mounted according to the assembly instruction. Document Number - Check all functions related to the changed spare part. - Repairs and maintenance may only be performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. 3EN650203 Rev. 5 ENGLISH www.hill-rom.com...
  • Page 9: Spare Parts List

    5.0 Spare Parts List Spare Parts Golvo™ 9000 mobile lift (G7=Golvo 7000, G77=Golvo 7007, G8=Golvo 8000, G88=Golvo 8008, G9=Golvo 9000) PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR. Golvo LiftStrap 20090048 Lift Strap G77 / G88 / G9 3EN650272 20090106...
  • Page 10 5.0 Spare Parts List Spare Parts Golvo™ 9000 mobile lift (G7=Golvo 7000, G77=Golvo 7007, G8=Golvo 8000, G88=Golvo 8008, G9=Golvo 9000) PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR. 20090096 Gear Rack set 3EN690273 20090041 Spring Magazine 3EN630214 2006106 139 Battery Lead Acid...
  • Page 11 5.0 Spare Parts List Spare Parts Golvo™ 9000 mobile lift (G7=Golvo 7000, G77=Golvo 7007, G8=Golvo 8000, G88=Golvo 8008, G9=Golvo 9000) PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR. 20090064 279 Roll Frame Attachment Golvo, grey 3EN630269 20090065 280 Base Motor Cover, grey...
  • Page 12 5.0 Spare Parts List Spare Parts Golvo™ 9000 mobile lift (G7=Golvo 7000, G77=Golvo 7007, G8=Golvo 8000, G88=Golvo 8008, G9=Golvo 9000) PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR. 20090078 423 Actuator G8 / G88 / G9 3SE630263 21090028 425 Grease SHC460, 30g...
  • Page 13 5.0 Spare Parts List Spare Parts Golvo™ 9000 mobile lift (G7=Golvo 7000, G77=Golvo 7007, G8=Golvo 8000, G88=Golvo 8008, G9=Golvo 9000) PROD. NO. POS. NO. NAME UNIT ASSEMBLY INSTR. 20090098 550 Hand Control 6 button, LED 3EN690283 kg/lbs 20090099 551 Limit Switch Box, Jumbo Care...
  • Page 14: Service, Control Unit Jumbo Care

    Press the “fast speed” up and down buttons on the hand control or kg/lbs up and down buttons on the control box for 5 seconds. An audio signal will confirm the resetting. Service Manual Golvo™ 9000 • 3EN400405 Rev. 2 www.liko.com www.hill-rom.com mobile lift...
  • Page 15: Periodic Inspection Information

    According to ISO 10535:2006 Annex B, Periodic Inspection of medical device Liko™ Mobile Lift should be performed at least once a year. For Liko™ mobile lifts Periodic Inspection Liko Mobile lifts (3EN371001) is available in Agile and on the Partner Web.
  • Page 16: Preventive Maintenance

    Periodic Inspection and Preventive Maintenance is performed by personnel authorized by Hill-Rom and using original Liko™ spare parts. However certain parts have a shorter life cycle and will need to be replaced in order for the mobile lift to meet its expected life time.
  • Page 17: Product Changes

    9.0 Product Changes, Golvo™ 9000 mobile lift Prod. No. 2000045 Golvo 9000 2000049 Golvo 9000 LowBase Changes Model Model Project 2000045 2000049 From S/N From S/N 2017 Start of production Golvo™ 9000 equipped with Jumbo Care Control Box (CBJ-C) and Hand...
  • Page 18 I www.liko.com Liko AB Nedre vägen 100 SE-975 92 Luleå , Sweden...
