Hoistway Door

4.14.1

Preventive Maintenance on Hoistway Door

C2
5
T2
6
7
4
3
2
1
[43402603_019; 10.08.2017]
1 Landing sill
2 Guiding shoe
3 Door panel
4 Main track
5 Main/counter roller
6 Safety contact
7 Landing door
6
5
7
J 43402603 / 01 241/269
