- Page 1 TECHNICAL DIVING COMPONENT □ 30lbf AIR CELL (Item no.: JT-30) □ 50lbf AIR CELL (Item no.: JT-50) □ 65lbf EXP. AIR CELL (Item no.: JT-65) EN1809:1997 0120 Printed in Taiwan Ver. E991007H...
- Page 2 Repair or maintenance task of any part or any disassembly of the air cell and power inflator / corrugated hose assembly must only be performed by an authorised IST dealer. Unauthorised service will render the warranty void and may cause this product to malfunction.
- Page 3 For JT-30 single tank and JT-50 twin tank (right) air cells, each has a single inner bladder and comes with a single 16” inflator with standard technical elbow connection and an over-pressure exhaust valve to the front lower left side (when wearing). They have 1 pair of grommets at industry standard 11” apart. JT-65 is like JT-30 and JT-50 but packed with redundancy features * and more.
- Page 4 Inflator with recreational style shoulder dump valve is available separately and comes in either 14” or 16” long assembly – please contact your local IST dealer for more information. All power inflator’s recommended working pressure is 7.6BAR (110psi) ~ 11BAR (160psi) and the ideal pressure is between 9.5BAR (138psi) ~ 10BAR (145psi).
- Page 5 Power inflator Depending on the model purchased, your air cell may come with 1 or 2 inflators. They all operate in the same manner: Deflation / oral inflation button: Use index Inflator button: Use thumb to press the inflation finger to press the button to: button to inflate the BCD.
- Page 6 Make sure this o-ring us present in the male end of the low pressure BC hose Screw the hose into a low pressure port in your regulator’s first stage. Pull back the quick disconnect sleeve in the female end of the low pressure BC hose and connect it to the power inflator’s quick disconnect nipple.
- Page 7 Do not put your air cell away until it is completely dry! - Store the air cell slightly inflated in a cool, shaded place. - Have an IST authorised dealer to inspect your air cell at least once a year to ensure proper and safe functioning of all parts.
- Page 8 – intentional or unintentional or any modification of this BCD part. If a problem has developed with this product, please contact your nearest IST authorised dealer or IST distributor for return authorisation. Please properly package this product and send with your proof of purchase and postage prepaid.
