Specifications; Ce - Declaration Of Conformity - Wavemaster BASE User Manual

Specifications

2 channel 2-way stereo sound system
•
2 built-in amplifier channels
•
Bluetooth® Audio System for wireless digital signal transmission (BT 2.1 or above)
•
25mm (1") mylar balanced dome tweeter, 11.5cm (4.3") coated cellulose cone woofer
•
ON/STANDBY/VOLUME level and BASS/TREBLE tone controls at the right side panel
•
INPUT SELECTOR for Line and Bluetooth® sources
•
LINE input with RCA sockets, HEADPHONE output with 3.5mm mini phono socket
•
MAINS POWER SWITCH on the back
•
Connections by audio cables or wireless by Bluetooth® Audio System
•
Frequency range: 50 - 22,000 Hz, S/N >95 dBA,
•
Amplifier output power (RMS): 2x 15W
•
Mains tension: 100-240 Volt ~ 50/60 Hz, 0.5A max., Standby Power <0.5 W (230V)
•
Dimensions (WxHxD): each Box 160 x 220 x 185 mm
•
System requirements: analogue stereo source with RCA or mini phono terminals or Bluetooth®
•
Audio System
We herewith declare, that the wavemaster BASE active speaker system
EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55035: 2017
Draft ETSI EN 301 489-1 v 2.2.0: 2017, Draft ETSI EN 301 489-17 v 3.2.0: 2017
ETSI EN 300 328 V2.1.1: 2016, EN 62479: 2010, EN 62368-1: 2014+A11: 2017
This statement is based on the test reports of an EMC laboratory.
All texts and illustrations were produced with greatest care. wavemaster cannot however accept any
legal or other responsibility for any remaining incorrect information and its consequences.
Subject to change without further notice.
In case there is audible noise, possibly caused by strong radio waves (e.g. by mobile phones)
we recommend to turn down the volume control of the unit.
If you have special questions to the product and cannot find a solution in this introduction, you can
look for more informations at our homepage. Thank you!
The device may not be disposed of with household rubbish. This
appliance is labelled in accordance with European Directive
2002/96/EG concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE).
The guideline determines the framework for the return and recycling
of used appliances as applicable throughout the EU. To return your
used device, please use the return and collection systems available
to you.

CE - Declaration of conformity

complies with the following standards or normative documents:
RED directive 2014/35/EU
ErP directive 2009/125/EC
(EC) No 1275/2008, (EU) No 801/2013, EN50564: 2011
English
www.wavemaster.eu
4
