General
Model
OFRB7 6 Fin, Thermostat,
The radiator is designed for operation on an AC electricity supply,
and is suitable for use in domestic dwellings and similar indoor
locations.
Always ensure that the appliance is stood on a firm, level base
near to, but not directly beneath, a suitable fixed socket outlet.
The heater is fitted with integrated carry handles for ease of
movement and an adjustable thermostat enabling the room
temperature to be controlled accordingly. It is supplied with a cord
and plug ready for use.
Warning – The heater complies with stringent safety standards but
to ensure efficient operation SURFACES OF THE HEATER WILL
BECOME HOT AND CONTACT WITH THESE AREAS SHOULD
BE AVOIDED, particularly between the fins on the top and sides.
The control panel area is designed to be at a far lower temperature
to allow the safe operation of the controls at any time.
Electrical
WARNING – THIS APPLIANCE MUST BE EARTHED
If the socket outlets in your home are not of the 13 amp BS1363
type they will not accept the plug connected to this heater,
therefore cut off the plug. When cut off this plug can constitute
a shock hazard if inserted into a socket outlet. It must therefore
be disposed of safely.
Before wiring the appropriate plug please note that the wires in this
mains lead are coloured in accordance with the following code:
GREEN/YELLOW : EARTH
BLUE :
BROWN :
Connect the Green/Yellow wire to the terminal marked E or the
earth symbol or coloured Green or Green/Yellow.
Connect the Brown wire to the terminal marked L or coloured Red.
Connect the Blue wire to the terminal marked N or coloured Black.
DO NOT connect the Brown (Live) or the Blue (Neutral) wires to the
Earth terminal of your 13 amp plug. If the terminals of the plug are
unmarked or you are in any doubt, consult a qualified electrician.
Positioning the Heater
Select the position for the radiator ensuring there is clearance
from any furniture and fittings of at least 450mm above the heater
and 150mm each side. The radiator should only be operated on
a flat stable surface.
Operation
IMPORTANT – Objects or clothing must not be placed on this
heater. Before using the heater ensure that all warnings and
instructions have been read carefully.
To use, insert the plug in the socket and switch to "On"
Figs.3).
OFRB7 includes a neon indicator which illuminates when the
appliance is switched on.
Description
NEUTRAL
LIVE
Controls
Thermostat (see Fig.2)
Watts
The Thermostat (see Fig.2) controls the heat output according
700
to the room temperature. This ensures that the heater will not
produce heat unnecessarily when the room is warm. To set the
temperature you require, turn the thermostat knob clockwise
until the required setting is reached. Alternatively to heat a cold
room quickly, turn the thermostat knob up fully. When the room
has reached the desired temperature, turn the thermostat knob
anti-clockwise until the thermostat just clicks off. The heater will
now automatically operate at this temperature. The thermostat
also has a frost protection setting marked '
useful in areas such as garages, to prevent frost damage. If the
thermostat is set to its minimum setting '
on and off to maintain a temperature of approximately 5° to help
protect against frost.
Note – Should the heater fail to come on when the thermostat is
at a low setting, this may be due to the room temperature being
higher than the thermostat setting.
Storage
If the radiator is not required for long periods, for example during
the summer, it should be stored in a dry place and preferably
covered to prevent the accumulation of dirt and dust.
Cleaning
WARNING - ALWAYS DISCONNECT THE POWER SUPPLY
BEFORE CLEANING THE HEATER.
Do not use detergents, abrasive cleaning powder or polish of any
kind on the body of the heater.
Allow the heater to cool, then wipe with a dry cloth to remove dust
and a damp cloth (not wet) to clean off stains. Be careful not to
allow moisture in to the heater.
Recycling
For electrical products sold within the European Com-
munity.
At the end of the electrical products useful life it should
not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice in your country.
(see
'. This setting is
', the heater will cycle
