Thank you for purchasing this Panasonic product.
Please read these instructions carefully before using this product, and save this
manual for future use.
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
POWER
LINK
RESET
SETUP
Panasonic Corporation
http://www.panasonic.com
CZ-CAPWFC1
Model No.
Contents
Safety Precautions ...................................... 2
System Overview ......................................... 5
Parts Identification ...................................... 6
Parts.............................................................. 7
Dimensions .................................................. 7
WLAN Adaptor Installation ......................... 8
Connecting Network .................................. 11
Firmware Update Function ....................... 29
Software License Information .................. 29
Specifications ............................................ 36
USER'S MANUAL
WLAN Adaptor
F1218-11218
ACXF60-34441
Advertisement
Table of Contents
Related Manuals for Panasonic CZ-CAPWFC1
Summary of Contents for Panasonic CZ-CAPWFC1
-
Page 1: Table Of Contents
Parts.............. 7 Dimensions ..........7 WLAN Adaptor Installation ......8 Connecting Network ........11 Use the “Panasonic Comfort Cloud” ..18 WLAN Adaptor Q & A ........ 27 Firmware Update Function ....... 29 Software License Information ....29 Specifications ..........36 Thank you for purchasing this Panasonic product. -
Page 2: Safety Precautions
Select an installation location which is rigid and strong enough to support or hold the WLAN Adaptor, and select a location for easy maintenance. z Use only the parts specified by Panasonic as supplied accessories. z Ensure cables are installed properly so that external forces cannot affect them. - Page 3 WARNING z The WLAN Adaptor must be installed by the sales dealer or installer. z When installing the WLAN Adaptor, use appropriate protective equipment and tools for safety. z The WLAN Adaptor should be securely installed in accordance with the USER’S MANUAL. z Electric work must be performed by authorised personnel in accordance with the local regulations and the instructions detailed in the USER’S MANUAL.
- Page 4 CAUTION z Ground yourself to discharge static electricity before performing any wiring. z Do not install the WLAN Adaptor in places with direct sunlight or where the ambient temperature is 55 ˚C or more or is 0 ˚C or less. z The connecting cable must not touch piping directly.
-
Page 5: System Overview
● Panasonic WLAN Adaptor is designed for communication to the “Panasonic Comfort Cloud”. ● Third party WLAN interfaces cannot be connected to the “Panasonic Comfort Cloud”. ● Updates to the service may mean there are changes to the design of the “Panasonic Comfort Cloud”... -
Page 6: Parts Identification
Parts Identification POWER LINK RESET SETUP Item Description Indicates that the WLAN Adaptor is being supplied with POWER LED power. (green) : Power being supplied : No power being supplied Indicates the communication status of the WLAN Adaptor to the router. : Not connected to router Blinks : In the process of connecting with router : Connected to router... -
Page 7: Parts
* Initialising the WLAN Adaptor Press and hold the SETUP button (30 to 35 seconds). After this, press the RESET button within 5 seconds to initialise. Parts Adaptor Unit (1) Screw (2) (CZ-CAPWFC1) POWER LINK RESET M3.8 x 16 SETUP Clamper (3) USER’S MANUAL (1) -
Page 8: Wlan Adaptor Installation
WLAN Adaptor Installation Basic Wiring Diagram Irrespective of the number of indoor units, the WLAN Adaptor must be used together with a remote controller. A remote controller must be connected and it should be set as the “main unit” in the main-sub remote controller settings. - Page 9 „ When there are multiple indoor units T10 connector Example Indoor unit Indoor unit Indoor unit Terminals for remote controller wiring Remote controller wiring Communication lines (field supply) (1.9 m total length) CN03 ● No polarity Wired remote controller (main unit) WLAN Adaptor Example of standard installation Connect the communication lines to the indoor unit.
- Page 10 Remove the top case. Use a fl at head screwdriver or similar Top case tool to push in the catch on the bottom case and remove the top case. Take care not to break the catch when pushing with the screwdriver. Bottom case Catch When attaching the bottom...
-
Page 11: Connecting Network
Create New Panasonic ID Use “Panasonic Comfort Cloud” app as an option to control the air conditioner. ● For new user, select Create new Panasonic ID to register. Password must be 8-16 characters with letters and numbers. You can input the following characters. (As of January 2019) - Page 12 ● Smartphone and air conditioner should be connected to the same wireless LAN. ● Ensure Wireless LAN is broadcasting SSID. Add new air conditioner device ● The air conditioner needs to be registered before using “Panasonic Comfort Cloud” app. At My Home screen, tap “+” to add Tap “Start”...
- Page 13 Select the preferred router support Setting connection network connectivity mode. Tap “Next” after confi rming the POWER LED of the WLAN Adaptor is ON. Select the option that matches the status of LINK LED. Connection network using WPS mode (method 1) Press the “WPS”...
- Page 14 Press and hold the “SETUP” button Connection network using AP on the WLAN Adaptor for 5 seconds. mode (method 2) Release the “SETUP” button on the Press and hold the “SETUP” button WLAN Adaptor when the LINK LED on the WLAN Adaptor for 10 seconds. blinks once.
- Page 15 The smartphone will connect to the wireless router. WLAN Adaptor. SSID : Panasonic-CZ-C-wirelessAP Password : Cac8pswa A window will prompt, tap “Copy password and next” to proceed to smartphone wireless network setting. Connect to “Panasonic-CZ-C- wirelessAP” network. Once connected, continue with setup in the application.
- Page 16 When the connection of WLAN Select the air conditioner and Adaptor to router is successful, the set the password LINK LED changes from blinking to Select the air conditioner model to register the device. * It may take up to few minutes before Press the “SETUP”...
- Page 17 ● By registering the new name of air conditioner, the function of “Panasonic Comfort Cloud” app is ready to be used. <Note> ● Keep the password for future use with additional user registrations.
-
Page 18: Use The "Panasonic Comfort Cloud
Use the “Panasonic Comfort Cloud” User’s manual can be found under Menu tab. The “Panasonic Comfort Cloud” is connected to the WLAN Adaptor and ready for use. Login Panasonic ID Password Reset Panasonic ID / Password Register for new Panasonic ID Start a demonstration „... - Page 19 Change the language of the app User’s manual Terms of use Privacy notice Copyright Logout from current Panasonic ID „ User List Edit the name of the user Enable control of user Edit / delete the user control User’s control rights...
- Page 20 „ Change of Device Password Input old password Input new password Retype new password „ Replace the Device Select “Replace device” from the menu Tap Start Follow the step by step instruction from app „ Change the Router Settings Select “Change router settings”...
- Page 21 „ Device List Edit the device information and setting Edit device name Change device group Time zone selection Features selection (Features vary dependent on air conditioner model) Delete the device...
- Page 22 „ Group List Edit the group name Delete the group Add new group Input new group name...
- Page 23 Main Device Screen Status for all air conditioners in the same group Back (Page 24) Information Advanced settings Indoor air temperature (Page 24) * Subject to model compatibility Operating mode (Page 24) Outdoor ambient Change set temperature temperature (dial) Set temperature Switch between (Features vary connected devices...
- Page 24 „ Air Conditioner Status Individual off / on toggle Air conditioners status (Off / On, mode and set temperature) All off / on „ Advanced settings (Features vary dependent on air conditioner model) Change fan speed Auto fan toggle Change swing position Auto air swing toggle Additional features off / on „...
- Page 25 „ Statistics Selection of type Chart Outdoor temperature Energy consumption Indoor temperature Comparison of selected dates Date selection Information for the selection date * Estimated energy consumption may not be supported by certain models. Comparison Date selection Week selection Information of the selected comparison dates Month selection Year selection...
- Page 26 „ Weekly Timer Edit timer Off / On timer toggle Add new timer Edit timer Copy timer Add New Timer Select mode Select temperature Off / On Set time Set conditions...
-
Page 27: Wlan Adaptor Q & A
It is recommended to name each of the registered air “Panasonic Comfort conditioner units to distinguish them easily. Cloud” app. Register additional Download “Panasonic Comfort Cloud” app and create new user to control the Panasonic ID. air conditioner. Follow initial setting. Once the air conditioner is registered, input the preset device password (set by first user). - Page 28 Others Change of Ensure the smartphone compatibility. Install “Panasonic smartphone’s Comfort Cloud” app and login using your Panasonic login ID model. and password. Complete by initial connection setup. Change of WLAN Change the WLAN Adaptor and then, use “Panasonic Comfort Adaptor.
-
Page 29: Firmware Update Function
Firmware Update Function This product has functionality for connecting to the Panasonic firmware update server over the Internet to automatically update the device firmware to the latest version. To update the firmware, the device will do check, once per day, whether its firmware is the latest version after power up. - Page 30 “Software License” menu on this product. “Object” form shall mean any form resulting from mechanical At least three (3) years from delivery of this product, Panasonic will transformation or translation of a Source form, including but not...
- Page 31 Copyright Copyright2 Contributor that are necessarily infringed by their Contribution(s) acts) or agreed to in writing, shall any Contributor be liable to You alone or by combination of their Contribution(s) with the Work to for damages, including any direct, indirect, special, incidental, or which such Contribution(s) was submitted.
- Page 32 Copyright Copyright2 The FreeRTOS GPL Exception Text: For example, if you distribute copies of such a program, whether Any FreeRTOS source code, whether modifi ed or in it’s original gratis or for a fee, you must give the recipients all the rights that you release form, or whether in whole or in part, can only be distributed have.
- Page 33 Copyright Copyright3 These requirements apply to the modifi ed work as a whole. If 5. You are not required to accept this License, since you have identifi able sections of that work are not derived from the Program, not signed it. However, nothing else grants you permission to and can be reasonably considered independent and separate works modify or distribute the Program or its derivative works.
- Page 34 Copyright Copyright3 NO WARRANTY You should also get your employer (if you work as a programmer) or 11. BECAUSE THE PROGRAM IS LICENSED FREE OF your school, if any, to sign a “copyright disclaimer” for the program, if CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO necessary.
- Page 35 Declaration of Conformity (DOC) Hereby, “Panasonic Corporation” declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU The full text of the EU declaration of conformity is available at the following internet address: http://www.ptc.panasonic.eu/...
-
Page 36: Specifications
Maximum radio-frequency power transmitted in the frequency bands Type of wireless Frequency band Max EIRP (dBm) WLAN 2412-2472 MHz 20 dBm Authorized representative in EU Panasonic Testing Centre Panasonic Marketing Europe GmbH © Panasonic Corporation 2018 Winsbergring 15, 22525 Hamburg, Germany Printed in Japan...
