- Page 1 Qmini M Series Industrial GIS Data Collector Manual Qmini M Series Industrial GIS Data Collector Manual...
- Page 2 Qmini M Series Industrial GIS Data Collector Manual Handbook revision situation Revision date Revision number Introduction March 2012 Qmini M series industrial GIS data collector instructions version 1.0...
-
Page 3: Table Of Contents
Use and the matters needing attention ..................6 Chapter 2 ............................7 The introduction of Qmini M series industrial GIS data collector ........... 7 The front of Qmini M series industrial data collector .............. 8 The back of Qmini M series industrial data collector .............. 9 Interfac ............................ - Page 4 Qmini M Series Industrial GIS Data Collector Manual Technology parameters ......................27 Technology parameters...................... 27...
- Page 5 GIS data collector. Brief introduction of manual Qmini M series industrial GIS data collector is a new GPS/GIS data collector, even if you have used other types of industrial GIS data collector, please also carefully read the manual before use .
- Page 6 Related information You can find the instructions through the following methods: 1 Purchased products from the Hi-Target will with a CD, open the CD and you can find the instruction; 2 Land the official website of the Hi-Target, through "downloaded zone"—" product specifications "—"...
- Page 7 Qmini M Series Industrial GIS Data Collector Manual complaint" edition , your feedback will help to improve the quality of the introduction greatly .
-
Page 8: Chapter 1
Qmini M Series Industrial GIS Data Collector Manual C H A P T E R Chapter 1 Products overview This chapter introduces: ■ Product introduction ■ Product features ■Matters needing attention in use... -
Page 9: Product Introduction
Qmini M series industrial GIS data collector is integrated designed, and it is equipped with functions such as collection of GPS, embedded Windows Mobile 6.5 system, digital camera, microphone, 3 G communications, bluetooth communication, large storage, USB port, SD card expansion ,etc. -
Page 10: Use And The Matters Needing Attention
Qmini M Series Industrial GIS Data Collector Manual ◊ Integrated industrial 3 G wireless communication. Realizing the communication between management center and mobile GPS terminal, the function is applicable to Qmini3 / Qmini3P and QminiH3 / QminiHP model. Use and the matters needing attention... -
Page 11: Chapter 2
Qmini M Series Industrial GIS Data Collector Manual Chapter 2 C H A P T E R The introduction of Qmini M series industrial GIS data collector The introduction of this chapter: ■the front of Qmini series industrial GIS data collector ■the back of Qmini series industrial GIS data collector... -
Page 12: The Front Of Qmini M Series Industrial Data Collector
Qmini M Series Industrial GIS Data Collector Manual The front of Qmini M series industrial data collector The front of Qmini series industrial GIS data collector，including the touch screen, keyboard, a microphone，protection set ,etc. ◊ Touch screen: 3.7 inch vertical screen can do click operation directly, support inputting in both Chinese and English ◊... -
Page 13: The Back Of Qmini M Series Industrial Data Collector
Qmini M Series Industrial GIS Data Collector Manual The back of Qmini M series industrial data collector The back of Qmini series industrial GIS data collector, including the camera, battery, the belt hole, horn, etc. Camera (with flashfunction) Horn The belt hole ◊... -
Page 14: Interfac
Interface Qmini M series industrial GIS data collector interface position was identified, its main function is charging and data transmission, installing SIM card and SD card, etc. Picture2-3 ◇... -
Page 15: Touching Pen
Touching pen Qmini M series industrial GIS data collector touching pen is equipped with standard configuration, located in Qmini M series industrial GIS data collector belt . Picture2-4 Battery This illustration shows the standard 3100 mAh lithium battery appearance figure. - Page 16 Qmini M Series Industrial GIS Data Collector Manual Picture2-5 Notice: In order to protect the environment, when the lithium battery failure, do not throw them away, please return to Hi-Target or professional battery recycling units processing.
-
Page 17: Data Cable
Qmini M Series Industrial GIS Data Collector Manual Data cable Picture2-6 ◇Industrial GIS data collector interface: used in connection Qmini series industrial GIS data collector. ◇USB interface: to connect computer USB port , used for data download. Warning: when the cable is not in use, it should be packed in where the place is not easy to squeeze to prevent damage to the plug. -
Page 18: Chapter 3
Qmini M Series Industrial GIS Data Collector Manual C H A P T E R Chapter 3 Basic operation The introduction of this section: keyboard ▇ Touching pen ▇ 3G card ▇ MicroSD card ▇ Power supply system ▇ Switch machine operation ▇... -
Page 19: Keyboard
Qmini M Series Industrial GIS Data Collector Manual Most of the Hi-Target Qmini series GIS data collector setting and operation can be completed by touching pen , the common operation can be completed by the keyboard . Now we will introduce the appearance and function of the keyboard simply. -
Page 20: 3G Card
Qmini M Series Industrial GIS Data Collector Manual seconds to turns on/off it. On boot-up state, hold the button for 1 second, switch on or off the backlight . Navigation button: move the cursor, to choice the options content. Notice: when Qmini series industrial GIS data collector is not in work temporarily, please close a backlight to save electricity, to extend industrial GIS data collector work time. -
Page 21: Microsd Card
Qmini M Series Industrial GIS Data Collector Manual Figure 3-2 Figure 3-3 To install a 3 G card, as the picture directs, open it along the OPEN buckle, put the 3 G card in, and lock the 3G card along the direction . -
Page 22: Power Supply System
◊ The battery installation and removal Install the battery, contact the battery with a metal connector on one end with Qmini M series data collector battery slot copper point, pressed the battery according to the left lower red arrows figure direction. -
Page 23: Charge
Take out the battery, pull out the battery according to the upper right sign of the red direction arrow ◊ Qmini M series industrial GIS data collector battery, charger model Table 3-1 Qmini M series industrial GIS data collector battery, charger model name model 3100 mAh lithium batteries... -
Page 24: Switch Machine Operation
Qmini M Series Industrial GIS Data Collector Manual Figure 3-8 Warning: 1The battery and charger manufacturer configuration are only permitted, do not put it into the fire or metal electrodes with short circuit. 2 If you find the battery has fever, deformation, discharge, smell or other abnormal phenomenon when the battery is in use 、in charge or in storage, please replace... - Page 25 Qmini M Series Industrial GIS Data Collector Manual Figure 3-9 shutdown ◊ On state, long press 3 seconds, it will tip you to confirm shutdown, click on the "shut down". Figure3-10...
-
Page 26: Data Obtain
Figure3-11 2 The hardware connection First，opened Qmini M series industrial GIS data collector, enter the Windows system, it is no need to open applications. Connect the USB port which with a smaller cable line with the industrial GIS data collector, connect the other end USB plug with your PC. As shown in figure 3- 12 . - Page 27 Qmini M Series Industrial GIS Data Collector Manual If you have connected them but the computer can't identify, please take the following method to solve: a:close the USB charging in the power setting model press to the homepage, select ”setting”→”power”→”USB charging”, close the control switch of the USB charging.(figure3-15)
- Page 28 Qmini M Series Industrial GIS Data Collector Manual Figure3-15 B:To install the driver Selects "computer" in the computer, choice "management" with the right button, open the "device manager" — " network Adapter ", right-click to uninstall "Microsoft Windows Mobile Remote Adapter". If your system is Windows 7, please don't check "delete this device driver...
- Page 29 Qmini M Series Industrial GIS Data Collector Manual Figure3-16 Figure3-17 Figure3-18 Qmini M series industrial GIS data collector with pc again, if there is a "Windows Connect the Mobile member center" registered tip , please choose "not registered". 3 Software connection When the cable is connected ,the Microsoft ActiveSync in the computer will tips you "whether...
-
Page 30: Application Functions
Application functions Qmini M series industrial GIS data collector is equipde with PPP technology (the technology used in Qmini MP model), built-in GPS navigation and positioning, digital camera, microphone, 3 G communications (this function is optional), and other functions, but it must be installed with the corresponding software. -
Page 31: Chapter 4
Technology parameters Technology parameters This chapter will introduces you related parameters of Qmini M series industrial GIS data collector, the product function will vary according to the different models. When you refer to this chapter, please refer to corresponding technical parameters according to the equipment you purchased. - Page 32 Qmini M Series Industrial GIS Data Collector Manual Screen: 3.7 inches color touch screen, 640 x 480 resolution √ √ √ √ √ GPS characteristics High sensitivity GPS positioning √ √ √ √ √ technology GPS+GLONASS binary star positioning technology Support SBAS（WAAS，EGNOS，MSAS）...
- Page 33 Qmini M Series Industrial GIS Data Collector Manual The built-in bar code scanner √ Data communication Bluetooth:bluetooth √ √ √ √ √ Interface: Mini USB interface √ √ √ √ √ WIFI: 802.11b/gWireless local area √ √ √ √ √...
- Page 34 Qmini M Series Industrial GIS Data Collector Manual Dustproof waterproof:IP67 √ √ √ √ Shockproof: Resistance to 1.5 m free √ √ √ √ fall...
