  • Page 1 OPERATOR'S MANUAL Cat. No. 2205-40 2206-40 FORk METERS TO REDUCE THE RISK OF INJURY, USER MUST READ AND UNDERSTAND OPERATOR'S MANUAL.

  • Page 2: Important Safety Instructions

    Disconnect all the cords and cables from the object under test and power off the instrument before opening the battery cover for battery replacement. This tool is designed to be powered by 2-AA batteries properly inserted into the milWaukee Fork Meters. Do not attempt to use with any other voltage or power supply.
  • Page 3 cauTion Set the Rotary Dial to an appropriate position before starting measurement. Firmly insert the test leads. Disconnect the test leads from the instrument for current measurement. Do not expose the instrument directly to the sun, high temperature and humidity or dewfall. Altitude 2000m or less.

  • Page 4: Functional Description

    0.2°F F°:±(1.0% + 18 dgt) Low Input Impedance 400.0V Lo-Z 0.1V/1V ±(2.0% + 3 dgt) AC:45~500Hz (2205-40) 1000V funcTional descripTion assembly Warning To avoid an electrical hazard, turn the Rotary Dial to OFF and disconnect the test leads before opening battery compartment or replacing batteries.
  • Page 5 Lo-Z Low Input Impedance Warning (Cat. No. 2205-40 only) Only use milWaukee test leads with the Automatic voltage detection milWaukee Fork Meters. (AC or DC). Inspect test leads before each use. Use me- Lo-Z 1. Set the Dial to posi- ter to run a continuity test.
  • Page 6 Capacitance danger (Cat. No. 2206-40 only) To reduce the risk of electric shock for 1. Set the Dial to position. Resistance, Continuity, and Capacitance measurements, never use the meter on an 2. Connect the red test lead energized circuit. Make sure a capacitor is to the VΩ...
  • Page 7 For a complete listing of accessories refer to your The meter does use battery power in sleep mode. Milwaukee Electric Tool catalog or go online to Be sure to switch the tool to OFF to conserve bat- www.milwaukeetool.com. To obtain a catalog, con- tery power.

  • Page 8: Limited Warranty

    Milwaukee to be defective in maintenance program. After one year, it is recom- material or workmanship for a period of five (5) mended to return the tool to a Milwaukee service years* after the date of purchase. Return the Test facility for calibration.
