Summary of Contents for Vision TM-1200

  • Page 1 TM-1200 OWNERS MANUAL www.visionaudiovisual.com/techmount/tm-1200 TM-1200_manual_en_v1...
  • Page 2 ENSURE POWER CABLE IS NOT TWISTED, SQUEEZED, OR SHEARED! All products are designed and imported into the EU by ‘Vision’ who is wholly owned by ‘Azlan Logistics Ltd.’, Registered in England Nr. 04625566 at Lion House, 4 Pioneer Business Park, Clifton Moor, York, YO30 4GH.
  • Page 3 CONTENTS 1 x 1.1m pole (Q235) 1 x Ceiling plate (SPCC) 1 x Top tilting mechanism (Q335) 1 x Pole Spigot (Q235) 1 x Pole Trim Disk 1 x Spanner 1 x Fall-arrest safety cable 4 x ST8x50 bolts (strength grade: 4.8) 4 x RT Expansion plugs 6.5x45 (HDPE) 1 x Hex Key (zinc plated) 4 x M8x8 Pin Hex Bolts (strength grade: 4.8)
  • Page 4 ALTERNATIVE ASSEMBLY CONFIGURATIONS OPTION A OPTION B OPTION C Standard configuration Sloped ceiling fitting Close-coupled installed INSTALLATION INSTRUCTIONS Ensure the correct fixtures are used to attach the projector Techmount to the wall or ceiling depending on the surface you are attaching to. The fixtures provided are ST8x50 bolts with 10mm plastic inserts for attachment to masonry.
  • Page 5 ASSEMBLY FOR STANDARD / SLOPED CEILING CONFIGURATION: Hold pole in place and mark length. The lens of projector should be around a foot above the axis with top of screen. Cut pole to length. Drill new holes in the end of the pole: a.
  • Page 6 Attach top coupler and/or tilting mechanism to ceiling yoke. Fix to ceiling. Fix pole. Attach projector to the spider/bottom yoke fitting to the projector, and attach all to the pole. Thread the input and power cables through the bracket’s cable management system. TM-1200_manual_en_v1...
  • Page 7 If you have a false ceiling, fit the included trim disk. Fix fall-arrest cable to pole and projector. Turn the projector on to calibrate image and adjust tilt. Lock off bottom yoke bolts. ASSEMBLY FOR CLOSE-COUPLED CONFIGURATION: Fix top yoke to the ceiling. Attach the projector to the spider/bottom yoke fitting to the projector, and attach all to the top piece of the tilting mechanism.
  • Page 8 WARRANTY This product comes with a 2-year return to base warranty, effective from the date of purchase. This warranty applies only to the original purchaser and is not transferable. For the avoidance of doubt, this will be taken from the information held by the appointed national distributor at the point of sale.
