Summary of Contents for GNATUS COBRA CONTRA ANGLE INTRA 32 CA
-
Page 2: Presentation Of Manual
• CONTRA ANGLE INTRA 32 CA PB • CONTRA ANGLE INTRA 32 CA PB SPRAY • CONTRA ANGLE INTRA SL 30 • CONTRA ANGLE INTRA SL 30 PB Brand: GNATUS Manufacturer/ Distribuitor: Alliage S/A Indústrias Médico Odontológica C.N.P.J. 55.979.736/0001-45 - Insc. Est. 582.002.897.114 Rod. -
Page 3: Table Of Contents
INDEX 02 PRESENTATION OF MANUAL 04 IDENTIFICATION OF EQUIPMENT 04 Indication of Equipment 04 Purpose of the equipment 05 Description of the Equipment 06 MODULES, ACCESSORIES, OPTIONS AND MATERIALS OF CONSUMPTION 08 TECHNICAL SPECIFICATIONS 08 General features 09 Dimensions 10 Packing symbols 10 Product symbols 10 Abbreviations 11 OPERATION OF EQUIPMENT... -
Page 4: Identification Of Equipment
IDENTIFICATION OF EQUIPMENT Dear Customer Congratulations. You have made a good choice when you decided to buy a GNATUS product comparable to the best products available in the World. This manual is a general presentation of your product and it will give you important details to help you to solve possible problems. - Page 5 Coupling via the INTRA system and rotation of 360º. The GNATUS handpieces have been planned to offer maximum performance in the most severe clinical procedures. With a design which caters for ergonomics, torque, sensitivity and lightness. Produced with technology (MADE IN BRAZIL) and material of the utmost durability.
-
Page 6: Modules, Accessories, Options And Materials Of Consumption
MODULES, ACCESSORIES, OPTIONS AND MATERIALS OF CONSUMPTION The contents of this page are of an informative nature, the equipment being able to differ from that illustrated. So, upon acquiring the product check the technical compatibilty between equipment, coupling and accessories. Fastening system Fastening system Internal Spray... - Page 7 MODULES, ACCESSORIES, OPTIONS AND MATERIALS OF CONSUMPTION Attention -The use of any part, accessory or material not specified or foreseen in these instructions for use is entirely the user’s responsibility. 01 - Cooling kit (external spray adapter) 02 - Adapter for lubrication 03 - Lubricant Lubs Optional...
-
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS General features Transmission System Intra rotary Maximum rotation 20.000 rpm Bur fastening system Plate locks Push Button Bur type FG Standard Sterilization Autoclavable up to 135ºC As per DIN EN ISO 1797.1:1992 and made of steel or hard metal. Standard Burs Type Type 1 rod... -
Page 9: Dimensions
TECHNICAL SPECIFICATIONS Dimensions (mm) 32 CA / SL 30 32 CA PB / 32 CA PB SPRAY / SL 30 PB... -
Page 10: Packing Symbols
TECHNICAL SPECIFICATIONS Packing symbols It determines the maximum Packing to be transported and / quantity of boxes which can be or stored avoiding humidity, rains stacked during transportation and and wet floor. storage “as per packaging”. The packing must be stored and Packing to be transported and / transported away from direct sun or stored with the harrows up. -
Page 11: Operation Of Equipment
OPERATION OF EQUIPMENT Coupling to the micromotor Ensure that the connection of the instrument is compatible with that of the equipment. In order to couple it, press the instrument on the coupling of the micromotor until it is fastened (fig. a). To uncouple, by means of pressure, pull out the Handpiece. -
Page 12: Precautions, Restrictions And Warnings
PRECAUTIONS, RESTRICTIONS AND WARNINGS Recommendations for preserving the equipment Your GNATUS equipment has been designed and developed according to the standards of modern techology. Similarly to other kinds of equipment, it requires special care, which is many times neglected due to several reasons and circunstances. Therefore, here are some important reminders for your daily routine. -
Page 13: Sensibility To Predictable Environmental Conditions In Regular Use Conditions
- Before the first use and/or after long interruptions from work such as vacations, clean and disinfect the equipment. - If any maintenance should be required, only use services of the GNATUS Authorized Technical Assistance. - Owing to its delicate components, this handpiece must not be dropped or undergo impacts. -
Page 14: Corrective And Preventive Maintenance And Preservation
CORRECTIVE AND PREVENTIVE MAINTENANCE AND PRESERVATION Additional procedures for reuse The equipment can be reused in undetermined, i.e. unlimited, quantities, only needing to be cleaned and disinfected. Cleaning and Disinfection These processes should be used in the handpieces. Uncouple the piece from the INTRA fit terminal. Remove the diamond tip or bur. -
Page 15: Sterilization
Only sterilize clean and lubricated handpieces. Clean, grease and remove the overflow oil in the apparatus according to the previous indicate, put it in the surgical grade paper (not provided by GNATUS) and sterilize it in autoclave until 135°C (275°F) through a cycle. -
Page 16: Unforeseen Events – Solution Of Problems
Among the care you have to take with your equipment, the most important is regarding of the spare parts replacement. To ensure the lifetime of your device, only replace original spare parts from GNATUS. They have the assurance of the standards and technical specifications required by the GNATUS representative.
