CONTENTS Brief introduction ..................1 Main specifications ..................1 Main configuration...................1 Products constitution..................2 Assemble processes...................2 Adjustment steps..................4 Safety precautions..................6 Charging method and cautions..............6 Caution and Notice for Li-po batter y .............7 Caution and notice for ESC ..............7 Spare parts......................8 Statement: 1.Please read this manual carefully and follow the instruction of the manual before you use this products;... -
Page 3: Brief Introduction
★ Blazer is configured with two main wings. One main wings is suitable for the beginner, and the other one is suitable for the middle class or experienced pilot, which can achieve the effect of one airplane in two different flying way. -
Page 4: Products Constitution
Product constitution RTF version Fuselage, Trainer Main Wings, Sport Main Wings, Horizontal Wing, Vertical Wing, Main Landing Gear, Front Landing Gear, Propeller, Battery, Charger, Radio, Accessory Bag. ARF version Kits without radio PNP version Kits without radio, charger and battery KIT version Without any electronic parts Assemble processes... - Page 5 Assemble processes 2.Assembly of the main landing gear Take of the aluminum alloy main landing gear and insert it to the assembling groove at the underpart of the fuselage. Please make sure that the square hole in the landing gear is aligned with the square hole in the plastic mount. 3.Assembly of the power system Take of the assembled power system and pull the ESC wires from the top of the fuselage( Notice: The cowling is detachable),please connect the motor with ESC plug (black wire of the motor should be connected to black wire of...
-
Page 6: Adjustment Steps
). 6.Finished the assembly of "Blazer". Adjustment steps 1.Turn on the transmitter and please make sure that there is enough power for the transmitter. Push the joystick... - Page 7 Adjustment steps 2.Please connect the battery to the ESC plug, and put the battery into the battery case well, then close the battery cover. 3.Please catch the back part of the fuselage and push the throttle slowly, which can check whether the motor can work or not.
-
Page 8: Safety Precautions
Adjustment steps 6.Finished the adjustment for “Blazer” Safety precautions 1.If you have the simulator, we suggest that you can practise your skill by the simulator before you fly this model, which will bring some help for you. 2.Please climb the plane above the 50 meters with half throttle to fly it when you fly it for your first time, then you will be familiar with the performance of this plane. -
Page 9: Caution And Notice For Li-Po Batter Y
Notice 1. While charging is in process, please do not make it near flammable materials. 2.Expect Li poly battery, this charger is not allowed for other kinds of battery. 3. While charging, please keep it out of the reach of Children. 4. -
Page 10: Spare Parts
Spare parts top 01901 top01902 top01903 Trainer main wings Sports main wings Fuselage top01904 top01905 top01906 Horizontal wing Spinner Vertical wing top01009 top01907 top 01908 Propeller Main landing gear Front landing gear top 01909 top01910 top01911 Cowling Main wings securing parts Connecting rod top01912 top01913... - Page 11 Spare parts top30201 top30204 top507 9g Servo（400mm） 9g Servo（150mm） Battery（11.1V,2200mah) top40202 Motor(TOP3511-750KV)
