CONTENTS Brief introduction ..................1 Main specifications ..................1 Main configuration ...................1 Products constitution ..................1 Assemble processes ...................2 Adjustment s teps..................3 Saf tey precautions ..................5 Charging method and cautions ..............6 Caution and Notice for Li-po batter y .............6 Caution and notice for ESC ..............7 Spare par ts ....................8... -
Page 3: Brief Introduction
Brief introduction Thank you for purchasing the "FW-190" remote control model airplanes from Top RC, and we hope this plane will bring endless joy to you after you choose it. ★With the EPO foam materials, it is very light and strong. -
Page 4: Assemble Processes
Assemble processes 1. Install main wings Take of the main wings and screw and screwdriver from the box.Use the big screw to lock the mian wings to the fuselage, open the cabin cover and connect the servo wire to the right channel on the receiver; 2. -
Page 5: Adjustment Steps
Assemble processes 4.Finished the assembly of FW-190. Adjustment steps 1.Turn on the transmitter , and please make sure that there is enough power for the transmitter.Push the joystick for throttle and throttle trim switch to the lowest position,and other trim switch should be in the neutral position. - Page 6 Adjustment steps 3.Hold the model in the sky amd push the 6 channel on the transmitter, it will release the landing gear, then put the model on the ground. 3.Please catch the back part of the fuselage and push the throttle slowly to make sure that the motor can work normally.
-
Page 7: Saftey Precautions
5.Check the center of gravity and make sure that the CG of the plane should be within the range as indicated by the arrows. 280-290mm 6.Finished the adjustment for FW-190. Saftey precautions 1.If you have the simulator, we suggest that you can practise your skill by the simulator before you fly this model,which will bring some help for you. -
Page 8: Charging Method And Cautions
Charging method and cautions Li-Po battery(balance changer) specifications Specifications: Input voltage: DC 10V~15V Output voltage:2S-3S Li-Po battery Charging current: 1.0A Indicator state: Green: Charge complete & no battery Red: Charging The batteries are inspected separately. When the voltage reaches 4.20V, the charging process stops. Operating Then plug cigarette into its socket in car (Adapter should be connected if charge at home: connect the adapter to home power... -
Page 9: Caution And Notice For Esc
6. Do not drive a nail into the battery, strike it by hammer or tread it. 7. Do not impact or toss the battery. 8. Do not use the battery with conspicuous damage or deformation. 9. Do not charge a warm battery. Allow it to cool completely before attempting to charge. 10. -
Page 10: Spare Parts
Spare parts top00101 top00102 top00103 Fuselage A Main wings A Horizontal wings A top00104 top00112 top00113 Propeller spinner A Fuselage B Main wings B top00114 top00115 top00107 Horizontal wings Propeller spinner B Propellor set top00105 top00106 top204 40A Brushless ESC Landing gear electronic retractable landing gear top507... - Page 11 Spare parts top30202 top30203 top00109 9g servo （2 5 0 mm） 9g servo （200m m） LED lights top00111 top601 top00110 PCB board for cabin and Balance charger and adaptor Y wire set retractable landing gear...
